Operation Instructions
·Built-in Arm Rest Remote
Function Button
On/off Press this button to turn the chair on or off.
Auto
Press one time to switch to the next auto massage function.
modes
Press and hold this button to slowly lower the backrest and
Dual
lift the leg rest. Release the button to stop.
Recline
Press and hold this button to slowly lift the backrest and
Dual
lower the leg rest. Release the button to stop.
Incline
Zero
Press one time to switch to the next of the three zero gravity
Gravity
position.
Charge your smart phone or tablet on the convenient USB
USB
charger.
3.Turn off power and stop massage.
1) Press the power button during your massage to stop all functions immediately.
The backrest and foot rest will return to their original positions automatically. After
your set massage time is up, all massage functions will be complete; however,
the backrest and footrest won't return to the original position. Meanwhile, you can
save your completed massage to your memory programs if you wish to do so.
• Memory Save Function: Select your manual massage settings (i.e., speed,
technique, air intensity, etc.). Let the massage run for a moment, then press the
power button to turn it off (or you can wait until the end of your manual program,
at which point the chair shuts down automatically). After a moment, the word
"Memory" will blink on the remote screen. This gives you the option to save the
massage mode before the chair fully turns off. Press the memory function
buttons "M1" or "M2" as you like to store the massage mode.
2) Turn off power for the whole massage chair.
Figure (Switch power off)
FUSE: T5AL 250V CONTROLLER JACK
POWER INPUT
Diagram of the power switch position
Description
Unplug the power cord
10

Assembly Instructions

1. Installing the Arm Rests
• Find the coupling plug from the seat frame base that fits the plug on the
corresponding arm rest. Pull them up through the middle of the seat frame.
• Connect each plug according to the marks on each wire. (Figure 2)
Figure 1
• After securely connecting each plug and air hose from the chair to the
corresponding plugs on the arm rest, gently rest the arm rest beside the chair.
(Figure 3)
• Tuck the wires back in the seat frame base along with the metal tube, then put on
the cloth cover. Avoid folding the air hose. (Figure 4)
Figure 3
• Use two hands to hold the ends of the arm rest and align the connections on the
rear of the arm rest with the connections on the chair. Screw in to secure. (Figure 5)
• Attach the decorative cover. (Figure 6)
Figure 5
Figure 2
Put in the bottom
of the seat frame
Figure 4
Figure 6
