Navigation Basics
SEL
ENTER
Other Uses
for Arc Assist
48
2. Press SEL. Choose another waypoint using the
LARGE and SMALL knobs.
VOR CVO
CORVALLIS
facil
3. Select the Arc direction with the SMALL knob.
Left Arc dtk 171
ref: CVO
Rad 005° 14.0nm·
Rght Arc dtk 351
ref: CVO
Rad 005° 14.0nm
4. Press ENTER to accept the selections and start
navigating.
The DTK on the Arc Assist page is the
no-wind heading to hold the distance
shown. It is a tangent to the current radial.
You can select the reference waypoint for the Arc
Assist feature and it can be used at any time, not just
during approach or terminal operations. It can also
be used for difficult operations such as conducting an
over water search. By establishing a user waypoint at
the center of such a search area and selecting that
waypoint as a DME Arc reference point, you can fly
circles about that waypoint at known distances. By
gradually increasing the arc distance each time you
pass a specific radial, you can expand the search area.
The Arc Assist feature of the Apollo GX can make
this much easier.
OR USA
vor
vor
Note
