Summary of Contents for Infinite Peripherals AMP 100
- Page 1 User Manual AMP 100 Standalone Android™ Payment Device...
-
Page 2: Legal Notice
Android Open Source Project. Compatible Devices Made for Android™ Trademarks Infinite Peripherals, Mobilize Your Enterprise, Linea Pro, Infinea, Infinea Tab, and Infinea Omni are trademarks of Infinite Peripherals, Inc. All other trademarks are the property of their respective owners. -
Page 3: Table Of Contents
User Manual — AMP 100 Table of Contents Legal Notice Software Versions Compatible Devices Charge Your AMP 100 Trademarks Insert or Remove the SIM Card Getting Started Turn on the AMP 100 Features Smart Card Reader Accessories Magnetic Stripe Reader (MSR) -
Page 4: Getting Started
Getting Started The AMP 100 provides wireless POS functionality in a 127mm (5”) colorful display and capacitive touch screen. The sleek ergonomic design offers power and performance with a smart card reader, Bluetooth module, Wifi, 4G wireless mobile, and magnetic stripe reader-integrated PIN-entry devices (PED) that fits in your hand. -
Page 5: Technical Specifications
User Manual — AMP 100 Technical Specifications Physical Dimensions Connectivity Buttons Apple 9-pin connector On/Off button Two buttons for the barcode scanner Indicators Weight 4 LEDs for battery status 210g (7.41oz) Electromagnetic buzzer Port Dimensions USB-C port 146mm (l) x 84.5mm (w) x 15.4mm (h) ( in x in x in.) -
Page 6: Box Contents
Getting Started The AMP 100 allows you to scan barcodes and capture magnetic stripe data to pass into compatible applications. Ensure the battery is fully charged before first use. The following helps you get the AMP 100 ready for use:... -
Page 7: Product Description
User Manual — AMP 100 Product Description Barcode reader Reset button opening Power button Magnetic Card Reader Left scan button Charging pads/Serial Communication for docking stations SIM card tray Chip chard reader LCD Display with touch screen Contactless card Right scan button... -
Page 8: Set-Up Your Amp 100
User Manual — AMP 100 Set–up Your AMP 100 Two USB communication mode are available based on which USB cable is connected: USB-A to USB-C (USB AM 4PIN to Type C SYI-0108B) communicates to Android’s application processor to select: •... -
Page 9: Charge Your Amp 100
The rechargeable Li-Po battery is charged by the • USB power adapter connected to the USB port, • Via the device attached to a docking station. Note: The battery cannot be removed. If you have any issues with the battery, contact your Infinite Peripherals account representative. -
Page 10: Insert Or Remove The Sim Card
User Manual — AMP 100 Insert or Remove the SIM Card To enable the smart card features of your AMP 100, insert a Nano SIM card into the SIM tray. Note: The SIM tray supports only Nano-size cards. Use a paper clip or ejection tool to open the tray on the side of the unit. -
Page 11: Turn On The Amp 100
Press the button a second time to activate the scanner for normal barcode scanner. Note: If the AMP 100 is idling for an extended period of time, the power turns off automatically to preserve the charge on the internal battery pack. When turned off, the unit goes to sleep immediately. -
Page 12: Magnetic Stripe Reader (Msr)
The built-in magnetic stripe reader incorporates a 3-track, bi-directional, encryption-capable read head. A single swipe reads data from all three tracks. Note: The MSR functions as an unencrypted MSR until an encryption key is injected into the MSR head by a designated Infinite Peripherals key injection facility. Refer to https://ipcmobile.com/support/technical-services#key-injection for details. -
Page 13: Reset The Amp 100
Maintenance Battery Replacement Do not attempt to open the AMP 100 or replace the battery. If the battery is not charging properly or the unit is not turning on, contact your Infinite Peripherals account representative or technical support at https://ipcmobile.com/support. -
Page 14: Troubleshooting
Warranty Infinite Peripherals does not warrant, and is not responsible for, any damage to the AMP 100 (“Product”) or the assembled device as a result of liquid or solid particle intrusion into the Product, or damaged caused by dropping the Product with the assembled device. If a material or workmanship defect arises with regard to any Infinite Peripherals product, and a valid claim is received within the Warranty Period, Infinite Peripherals (at our sole discretion) will repair the Product using new or refurbished parts, or replace the Product with a new or refurbished Product. -
Page 15: Disclaimer
Infinite Peripherals, Inc does not assume any product liability arising out of or in connection with the application or use of any product or application described herein. -
Page 16: Federal Communications Commission
User Manual — AMP 100...
