Product Specification - ASL INTERCOM VAR8-ACU Product Description

9

Product Specification

General
Supply Voltage Range.............................................................................................................. 18 to 40 V DC
Current Consumption ...........................................500 mA @ 24 V DC supply, backlight off and sounder off
Auxiliary DC supply for external equipment ..........................................................18 to 36 V DC @ 200 mA
Fault Log........................................................................................................................................ 200 events
Real Time Clock (RTC) ........................................................................... Built-in (externally synchronisable)
Format ...............................................................................................................19-inch rack mounting frame
Field Connections..............................................................................................................Screw-in terminals
Colour .................................................................................................................. Black with silver annotation
Audio Input
Number of Balanced Audio Inputs............................................................................................................. 8
Number of Unbalanced Audio Input ..............................................................................................................1
Input Overload Margin ........................................................................................................................... 40 dB
Input Attenuator Range ................................................................................................................ 0 to –63 dB
Equalisation ...................................................................................................................... 3 band plus LF Cut
Surveillance Tone......................................................................20 to 30 Hz / Required Level 0 to –40 dBFS
Network Output
Outputs ..................................................................................................................................... Outputs 1 to 3
Level .................................................................................................................................................. +20 dBu
Graphic Equalisation .......................................................±12 dB @ 125, 250, 500, 1 k, 2 k, 4 k, 8 k, 16 kHz
Surveillance Tone..............................................................................................................10 dBu to –30 dBu
Gain Control Range.................................................................................................................0 dB to −63 dB
DVA
Number of Digital Messages (DVA) ......................................................................... 2x50-second messages
DVA Bandwidth .....................................................................................................................100 Hz to 8 kHz
2
Inputs 1 and 2: Hardwire bypass Fire Microphone inputs.
Support Fire Microphone, Zoned Fire Microphone, Paging Microphone, Single Button Microphone, or
Miscellaneous Input.
Support up to 30 microphone buttons.
3
Inputs 3 to 8: Support Paging Microphone, Single Button Microphone, or Miscellaneous Input.
Support up to 20 microphone buttons.
VAR8-ACU and Variants - Product Description
610 mA @ 24 V DC supply, backlight on and sounder on
Sensitivity and Impedance: −20 dBu (77 mV) @ Z ≥20 kΩ
Sensitivity and Impedance: Suits 1–2 V RMS units Z ≥5 kΩ
Issue: 02 complete, approved
Page 37 of 44
2,3
30 Hz Continuous
2x66-second messages
