Model Information
Index
Front Panel
Rear Panel
Remote Control
Warranty
Reset Procedure
Accessories
Protection History
Display Mode
Upgrades/Updates
Product Specifications
I/R Codes
NOTE:
This edition is missing the FAQ's content (pages 12 and 13) .................................................................9/30/2015
This edition is missing the link to the IR Codes.....................................................................................9/30/2015
Model Information
INTEGRATED NETWORK AV RECEIVER
This function is
not available on
this model
MODEL:
AVR-1312
1
MI093015E3-1

Advertisement

Table of Contents
loading

Related Manuals for Denon AVR-1312

Summary of Contents for Denon AVR-1312

  • Page 1 MODEL: AVR-1312 Model Information Index Model Information Front Panel INTEGRATED NETWORK AV RECEIVER Rear Panel Remote Control Warranty Reset Procedure Accessories Protection History This function is not available on Display Mode this model Upgrades/Updates Product Specifications I/R Codes NOTE: This edition is missing the FAQ’s content (pages 12 and 13) ………………………………………………………..9/30/2015 This edition is missing the link to the IR Codes………………………………………………………………………..9/30/2015...

  • Page 2: Front Panel

    Front Panel  Power operation button  PORTABLE IN jack (ON/STANDBY)  Remote control sensor Turns power to this unit on and off (standby).  V.AUX INPUT connectors   Tuner Preset channel buttons Remove the cap covering the connectors Power indicator when you want to use them.
  • Page 3 Display   Decoder indicators Surround back indicator These light when the respective decoders are operating. This lights when audio signals are being output from the surround back speakers (vpage 86).  Input signal indicators  Input mode indicators  Information display Set the audio input modes for the different input sources The input source name, surround mode, setting values and other...

  • Page 4: Rear Panel

    Rear Panel  PRE OUT connectors  Power cord  Speaker terminals  Digital audio connectors  DOCK CONTROL jack  HDMI connectors  S-VIDEO connector  Analog audio connectors  VIDEO connectors  FM/AM antenna terminals HOME REMOTE CONTROL 1 DISPLAY...

  • Page 5: Remote Control (1 Of 2)

    Remote Control (1 of 2)  Power buttons (ON, STANDBY)  Sleep timer button (SLEEP)  DIMMER button  Input source select buttons  QUICK SELECT buttons  MENU button  Cursor buttons ()  ENTER button  Channel level button (CH LEVEL) ...

  • Page 6: Remote Control (2 Of 2)

    Remote Control (2 of 2)  Remote control signal transmitter  SEARCH button  STATUS button  MEMORY button  BAND button  MODE button  SHIFT button  TUNING buttons ()  Channel buttons (CH +, –)  AUDIO ADJUST button ...

  • Page 7: Denon Limited Warranty (1 Of 2)

    Length of Non-Transferable Warranty This warranty on your DENON product which is distributed and warranted by DENON ELECTRONICS (USA), LLC remains in effect for the following periods from the date of the original consumer purchase from an AUTHORIZED DENON ELECTRONICS (USA), LLC DEALER.
  • Page 8 Except as specified below, this Warranty covers all defects in material and workmanship in this product occurring during the above warranty periods. The following are not covered by the Warranty: (1) Any product which is not distributed in the U.S.A. by DENON ELECTRONICS (USA), LLC. (2) Any product which is not purchased in the U.S.A.
  • Page 9 Reset Power/Standby button Reset procedure: With the power off, press and hold the “, “” buttons, and “POWER” button simultaneously on the AVR for a few seconds until the display starts flashing at intervals of about 1 second. “” button “”...
  • Page 10 Accessories Sound Remote Control Sound Calibration (RC1158) Calibration Microphone Microphone Stand (ACM1HB) 307010089008D $24.99 AM Loop FM Indoor Power Cord) Antenna Antenna 943116009500S $4.51 90M-ZA000230R $7.79 External CD ROM Safety Antennas For Owner’s Instructions Bluetooth/Wire Manual less Connectivity Notes on Radio Quick Start Warranty Guide...
  • Page 11 FAQ’s ( 1 of 2) HOME ACCESSORIES FAQ’s 2...
  • Page 12 FAQ’s (2 of 2) HOME FAQ’s 1 UPGRADE...
  • Page 13 Upgrades/Updates No update available for this unit HOME FAQs 2 Specifications – Audio Section...
  • Page 14 Specifications – Audio Section Audio section 75 W + 75 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.05 % T.H.D.) Front 110 W + 110 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.) 75 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.05 % T.H.D.) Rated output Center 110 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)

  • Page 15: Specifications - Video Section, Tuner Section, General Section

    Specifications - Video section, Tuner Section, General Section Video section Input/output level and impedance 1 Vp-p, 75 Ω/ohms Standard video connectors Frequency response 5 Hz -10MHz, 0, - 3dB Tuner section (ANTENNA input – MEDIA PLAYER OUT) Note: µV at 75 Ω/ohms, 0 dBf = 1x10 Reception frequency range 87.5 MHz - 107.9 MHz 520 KHz - 1710 KHz...

  • Page 16: Specifications - Dimensions, Weight

    Specifications – Dimensions, Weight Dimensions section (Unit : inch/mm) Weight: 19 lbs 13.5 oz (9 kg) HOME SPECIFICATIONS - SPECIFICATIONS VIDEO SPECIFICATIONS - AUDIO - TUNER - GENERAL DIMENSIONS - WEIGHT...
  • Page 17 The End NOTE: This edition is missing the FAQ’s content (pages 12 and 13) ………………………………………………………..9/30/2015 This edition is missing the link to the IR Codes………………………………………………………………………..9/30/2015 HOME...
