- Page 1 LRS Instruction Manual Quick Set-up CAUTION – CAUTION – CAUTION Fine Tuning Specifications Revised 3/16/2019 Page...
- Page 2 3. The LRS uses a unique high-current connector (See Figure 1). Strip approximately 1/4-inch of insulation from the speaker cable end and insert it into the connector and tighten the set screw with the Allen wrench provided.
-
Page 3: Fine Tuning
CAUTION – CAUTION – CAUTION 1. FUSING: The speaker terminal plate indicates a maximum fuse value of 4 amps — Type 3AG (“normal” or “fast blow”). As a precaution, your speakers have been shipped with 3 amp fuses installed. Never bypass, increase the value beyond 4 amps, or use “slow blow”... - Page 4 1. Recordings typically in the “pop” or “rock” vein often exhibit a pronounced rise in the treble region. 2. The Magneplanar Quasi ribbon tweeter is very efficient in it’s total energy dispersion. If the surrounding walls are exceptionally reflective, the overall perceived acoustical balance can be tipped toward a “hot”...
-
Page 5: Specifications
Specifications Description Two-way Quasi Ribbon Frequency Response 50Hz to 22Hz Sensitivity 86dB, 2.83 Volts, 500Hz @1 Meter Impedance 4 Ohms Dimensions 14-1/2" X 48" X 1-1/4” Shipping Weight 40 lbs./pair Revised 3/16/2019 Page...
