- Page 1 Check the Bair Hugger therapy website to ensure you have the most recent version of this document. www.bairhugger.com reorder #201031A Bair Hugger Model 500/OR Temperature Management Unit Operator’sManual...
-
Page 2: Table Of Contents
English Bair Hugger Model 500/OR Temperature Management Unit Operator’s Manual Table of Contents Introduction Description of the Total Temperature Management* System Indications for Use Contraindications Warnings Precautions Important Information Read Before Servicing Equipment Setup and Operation Temperature Management Units Control Panel Features of the Model 500/OR Temperature Management Unit Isolation Switch Optional Features: IV Pole, Blanket Dispenser, Hose Assemblies General Maintenance... -
Page 3: Introduction
English Bair Hugger Model 500/OR Temperature Management Unit Operator’s Manual Introduction Description of the Total Temperature Management System The Bair Hugger brand Total Temperature Management system consists of a Bair Hugger forced-air temperature management unit (with available rolling stand and sheet clip) and Bair Hugger dispos- able components, including forced-air blankets and the 241* blood/fluid warming set. -
Page 4: Read Before Servicing Equipment
(described in the Service Manual), the Over Heat Alarm system, as well as a leakage current test. PROPER USE AND MAINTENANCE Arizant Healthcare Inc. assumes no responsibility for the reliability, performance, or safety of the equipment if: • Modifications or repairs are performed by unauthorized personnel. -
Page 5: Temperature Management Units
English Bair Hugger Model 500/OR Temperature Management Unit Operator’s Manual 3) Connect the unit to a properly grounded power source. 4) Turn the Isolation Switch to the ON position (see the section titled Isolation Switch). 5) Press the System ON/OFF button to turn the unit ON and select the appropriate temperature setting. -
Page 6: Control Panel Features Of The Model 500/Or Temperature Management Unit
English Bair Hugger Model 500/OR Temperature Management Unit Operator’s Manual ® Figure C. Control panel of the Model 500/OR temperature management unit Control Panel Features of the Model 500/OR Temperature Management Unit OVER HEAT INDICATOR The Over Heat Indicator illuminates and an audible alarm sounds when an over-temperature condition is detected. -
Page 7: Isolation Switch
Optional Features This section discusses optional features for Bair Hugger temperature management units. For more details about these features, please call Arizant Healthcare Inc. or your local distributor. IV pole Figure E. Temperature management unit with IV pole option... -
Page 8: General Maintenance
English Bair Hugger Model 500/OR Temperature Management Unit Operator’s Manual BLANKET DISPENSER The blanket dispenser is available for use on the Series 500 units. This dispenser attaches to the unit and can store several Bair Hugger blankets. See the package instructions for details. Standard length without swivel option (replacement only) Standard length with swivel option... -
Page 9: Technical Service And Order Placement
English Bair Hugger Model 500/OR Temperature Management Unit Operator’s Manual Technical Service and Order Placement WORLDWIDE TEL: 1-952-947-1200 FAX: 1-952-947-1400 1-800-733-7775 WITHIN EUROPE TEL: +49-4154-9934-0 FAX: +49-4154-9934-20 0800-100-1236 (Toll-free in Germany) 0800-100-1324 (Toll-free in Germany) In-Warranty Repair and Exchange Replacement parts to correct a problem are delivered at no charge. To return a device to Arizant Healthcare Inc. -
Page 10: Specifications
OPERATING TEMPERATURES lower than the listed temperatures. Average temperatures at the end of the hose, assuming the back pressure of a Bair Hugger warming blanket, or an Arizant Healthcare temperature test unit: HIGH: 43° ± 3°C 109.4° ± 5.4°F MED: 38°... - Page 11 English Bair Hugger Model 500/OR Temperature Management Unit Operator’s Manual Electrical Characteristics Operating speed: 2650 rpm BLOWER MOTOR Airflow: 28-30 cfm Peak: 1000W Average: 500W POWER CONSUMPTION <100µA LEAKAGE CURRENT 850W Resistive HEATING ELEMENT 15-foot, SJT, 3 cond., 10A POWER CORD 4.6 meter, HAR, 3 cond., 10A 110-120 VAC, 60 Hz, 9.5 Amperes, or DEVICE RATINGS...
-
Page 12: Definition Of Symbols
English Bair Hugger Model 500/OR Temperature Management Unit Operator’s Manual Definition of Symbols ON/STANDBY ON (used on isolation switch) OFF (used on isolation switch) ON/OFF push button switch Temperature Control Equipotentiality plug (Ground) Fuse Attention (see appropriate documents) Non Explosion-Proof Dangerous Voltage Type BF Equipment (patient applied) Voltage, Alternating Current (AC) - Page 13 *Arizant, Arizant Healthcare, bright ideas that work, Bair Hugger, 241, Total Temperature Management, and the Bair Hugger and Arizant logos are trade- marks of Arizant Healthcare Inc., registered or pending in the U.S. Patent & Trademark Office and in other countries.
