Instructions for
Deluxe Prep - Center
20 -110
Please read before use.
General Information p. 2
Set Up p. 5
Parts & Pricing p. 9
Wiring Diagram p.11
Notes p.12
1
Model #
Serial #
Form # ADP-20-110
7-16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Deluxe Prep-Center 20-110 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mytee Deluxe Prep-Center 20-110

  • Page 1 Instructions for Deluxe Prep - Center 20 -110 ™ Please read before use. Model # General Information p. 2 Set Up p. 5 Serial # Parts & Pricing p. 9 Form # ADP-20-110 Wiring Diagram p.11 Notes p.12 7-16...
  • Page 2: General Information

    If damage is evident, save the shipping carton so that it can and we at Mytee Products Inc. strive to keep you on the cutting edge with superior be inspected by the carrier that delivered it. Contact the carrier immediately to file a quality and technology.
  • Page 3: Operation

    4. Filters clogged, remove filters and rinse clean with water. and refill solution tank. 5. Heater is blocked; flush out with Mytee’s system maintainer. 5. After cleaning, relieve water pressure from tool before disconnecting hose 6. If brass check valve is stuck replace valve.
  • Page 4: Machine Specifications

    GENERAL INFORMATION Vacuum motor does not work properly. 1. If switch on switch plate is bad, replace switch. 2. Connect hose tightly if hose is not connected tightly to upholstery tool or machine. 3. Clean upholstery tool if upholstery tool is clogged with hair, carpet fibers and/or debris.
  • Page 5 20-110 DELUXE PREP CENTER™ FRONT BACK 1. On Board Chemical Storage 7. On Board Tool Storage 2. Control Panel 8. Shop Air Hook Up 3. Chemical Dispensers (x4) 9. Tank Access Panel 4. Chemical Bottle Access Panel 10. 12” Rear Wheels 5.
  • Page 6: Vacuum Motor

    20-110 DELUXE PREP CENTER™ PUMP HEATER Release tool trigger. Turn on heater. Wait 8 – 10 minutes After the machine has been plugged into a 20 amp for unit to pre-heat. Once heated, squeeze cleaning tool grounded outlet. Turn on pump. Squeeze cleaning tool trigger again until hot water begins flowing.
  • Page 7 20-110 DELUXE PREP CENTER™ COMPRESSED AIR INLET TANKS 1. Vacuum recovery tank – empty when full, keep filter Inlet for shop air connection. Unit will regulate shop air to and ball float clean. proper PSI. 2. Solution tank – fill with fresh water and cleaning solution.
  • Page 8: Air Outlet

    20-110 DELUXE PREP CENTER™ AIR OUTLET BLOWER OUTLET Pneumatic compressed air quick connect, 40 PSI max Hook up blower hose for vehicle drying. outlet pressure. TOP TRAY On board tool and chemical storage.
  • Page 9: Parts & Pricing

    20-110 DELUXE PREP CENTER™ PARTS & PRICING Part prices are subject to change.
  • Page 10 20-110 DELUXE PREP CENTER™ PARTS & PRICING...
  • Page 11: Wiring Diagram

    20-110 DELUXE PREP CENTER™ WIRING DIAGRAM...
  • Page 12: Notes

    NOTES...
