T&S B-7245 Series Installation And Maintenance Instructions Manual

Epoxy powder coated steel reel

Advertisement

Limited One Year Warranty
T&S warrants to the original purchaser (other
than for purposes of resale) that such product is
free from defects in material and workmanship
for a period of one (1) year from the date of
purchase. During this one-year warranty period,
if the product is found to be defective, T&S shall,
at its options, repair and/or replace it. To obtain
warranty service, products must be returned
to...
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other
transportation charges of the product to T&S
and the return of repaired or replaced product
to the purchaser are the responsibility of the
purchaser. Repair and/or replacement shall be
made within a reasonable time after receipt by
T&S of the returned product. This warranty does
not cover Items which have received secondary
fi nishing or have been altered or modifi ed after
purchase, or for defects caused by physical
abuse to or misuse of the product, or shipment
of the products.
Any express warranty not provided herein, and
any remedy for Breach of Contract which might
arise, is hereby excluded and disclaimed. Any
implied warranties of merchantability or fi tness
for a particular purpose are limited to one year in
duration. Under no circumstances shall T&S be
liable for loss of use or any special consequential
costs, expenses or damages.
Some states do not allow limitations on how
long and implied warranty lasts or the exclusion
or limitation of incidental or consequential dam-
ages, so the above limitations or exclusions may
not apply to you. Specifi c rights under this war-
ranty and other rights vary from state to state.
P/N: 098-014920-45 Rev 0
Date: 03-25-04
Drawn: TEH
Checked: KG 08-22-04
Approved: MVW 08-25-04
Installation and
Maintenance
Instructions
B-7245-SERIES
EPOXY POWDER
COATED
STEEL REEL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-7245 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for T&S B-7245 Series

  • Page 1 Installation and Maintenance Instructions Limited One Year Warranty T&S warrants to the original purchaser (other than for purposes of resale) that such product is free from defects in material and workmanship for a period of one (1) year from the date of purchase.
  • Page 2: Exploded View

    Exploded View...
  • Page 3: Part Number Guide

    Part Number Guide...
  • Page 4: Important Safety Instructions

    General Instructions General Instructions Important Safety Instructions DANGER: Immediate hazards which will result in severe personal in- jury or death. WARNING: Hazards or unsafe practices which could result in severe personal injury or death. CAUTION: Hazards or unsafe practices which may result in minor per- sonal injury or product or property damage.
  • Page 5: General Instructions

    General Instructions • Qualifi ed personnel must evaluate wall or Fig. 4 ceiling fastening. Mounting through the (4) 1/2” dia. holes on the base may vary due to surface materials. A possible method for concrete, brick and cement block is a sleeve anchor type stud fastener (fi...
  • Page 6: Tension Adjustment

    General Instructions TENSION ADJUSTMENT CAUTION: Always leave at least 1-2 turns between full extension and when the spring is wound tight. If entire hose cannot be pulled out, decrease tension until full extension is possible. Failure to test for adequate spring revolutions can cause damage to reel. Hazards or unsafe practices may result in minor personal injury or product or property damage.
  • Page 7 General Instructions RATCHET LOCK REPLACEMENT/REMOVAL NOTE: Ratchet spring alone may be replaced without dissembling reel. Use needle-nose pliers to remove old Fig. 9 spring and to assist in installing new one. To replace or remove ratchet: • Turn off air/fl uid supply and disconnect supply hose •...
  • Page 8: O-Ring Replacement

    General Instructions SWIVEL REPLACEMENT Fig. 12 To replace swivel: • Turn off or lockout air/fl uid supply to reel and disconnect supply hose from inlet on shaft • Remove reel from mounting and relocate to bench-top • Remove tension from reel (see Tension Adjustment) •...
  • Page 9 General Instructions Preventative Maintenance HOSE • Check wear near hose-stop and end fi tting. If barb fi tting or hose is dam- aged cut off hose end and reattach new barb fi tting and clamp. • Check wear along entire hose length. Replace if needed. SWIVEL •...
  • Page 10 MOUNTING DIAGRAM SCALE 1:2 9 3/4” 1/2” DIA. HOLES TYP . 4 PLACES 7”...
  • Page 11 RELATED T&S BRASS PRODUCT LINE T&S BRASS AND BRONZE WORKS, INC. A fi rm commitment to application-engineered plumbing products 2 Saddleback Cove, P.O. Box 1088, T & S Brass-Europe Travelers Rest, SC 29690 ‘De Veenhoeve’ Phone: (864) 834-4102 Oude Nieuwveenseweg 84 Fax: (864) 834-3518 2441 CW Nieuwveen...
