Easyguard EC002 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
▶Contact us
Zhongshan Easyguard Electronics Co.,ltd
Add: 2nd floor, building 3, No 77 caihong Road, West district,
Zhongshan city, Guangdong, China
Phone: 86-760-22113597
Web: www.ieasyguard.com
Email: sales@ieasyguard.com
Important: This device can improve the vehicle safety level, but could not prevent the vehicle from
stolen or the occurrence of unexpected accidents. EASYGUARD Electronics will not be liable for any
User Manual of EC002
resulting from the damage of this product cause by direct or indirect losses.
V2.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EC002 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Easyguard EC002 Series

Summary of Contents for Easyguard EC002 Series

  • Page 1 Email: sales@ieasyguard.com Important: This device can improve the vehicle safety level, but could not prevent the vehicle from stolen or the occurrence of unexpected accidents. EASYGUARD Electronics will not be liable for any User Manual of EC002 resulting from the damage of this product cause by direct or indirect losses.

  • Page 2: Table Of Contents

    Key FOB buttons introduction & function description ------------------------------------------------------------------17-19 Manual for releasing the steering lock -------------------------------------------------------------------------------------20-21 Installation for chip immobilizer ----------------------------------------------------------------------------------------------21-22 Programming method --------------------------------------------------------------------------------------------------------------22 Central door locking wire connection---------------------------------------------------------------------------------------23-30 Wiring diagram of Easyguard EC002 --------------------------------------------------------------------------------------31-32 Function description 1.Push button start/stop -------------------------------------------------------------------------------------------------------33-34 2.PKE-passive keyless entry -----------------------------------------------------------------------------------------------------34 3.Manual arm/lock-------------------------------------------------------------------------------------------------------------------34 4.Manual disarm/unlock -----------------------------------------------------------------------------------------------------------34...

  • Page 3: Safety Warning

    (2) Never remote start the vehicle with the keys in the ignition. If the vehicle starts in gear, cease remote start Thank you for purchasing our EASYGUARD EC002 series PKE car alarm with push start stop button. This operation immediately and consult with the user to fix the problem immediately.

  • Page 4: Dip Switch Setting On Control Module

    6 pin ignition wire harness to cut off power of the device b.Press down or up the DIP switch you want to re-set Red connector 3pin c.Re-plug the 6 pin ignition wire harness to re-power the device -03- -04- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.
  • Page 5 Note: On vehicle with fiberglass bodies or convertibles, the PKE induction range will be increased. Vertical range Horizontal range As the PKE antenna is a directional antenna, the PKE induction range will be affected by the antenna placement/mounting position. -05- -06- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 6: Making Your Wiring Connections

    Use good-quality electrical tape or heat shrink. Never twist-and-tape the wires together without soldering. Never use “fuse taps”, as they can damage fuse box terminals. -07- -08- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.
  • Page 7 The 1st row 10 pin wires Turn signal light/parking light(+) Brown L E D Turn signal light/parking light(+) Brown See central door locking installation Yellow/black 3 color GWR wire Shock sensor -09- -10- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.
  • Page 8 For the purple trunk positive/negative selection wire, if your trunk is positive trigger(+), please connect this wire with constant +12V wire; if your trunk is negative(-) trigger, this wire connect with chassis ground. Factory bolt chassis ground wire -11- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 9: Engine Start Button Introduction

    Note:You can also use a SPDT relay to have a GWR wire and wiring method is the same but no need to connect 87a on SPDT relay. -13- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.
  • Page 10 P7n style engine start button Ø 38mm 47mm Ø 38mm Ø 27.5mm Ø 27.5mm 47mm The ring is detachable Ø 27.5mm The ring is detachable Ø 27.5mm -15- -16- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 11: Key Fob Buttons Introduction & Function Description

    6.Remote trunk release: Continue to press start button twice. Arm/Panic mode Trunk release/start button 7.Spare key( default is without, and we recommend you to equip one for future emergency usage) -17- -18- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 12: Manual For Releasing The Steering Lock

    2.Don’t dismantle the remote control. The users can’t inspect the components inside. to release the steering lock every 3.To avoid strong strike or heavy crash. time you start the car. -19- -20- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 13: Installation For Chip Immobilizer

    Then need to add a coin or other metal pad underneath the chip to enlarge the signal of it (see above drawing) The key fob is programmed with the control module already before out of the factory and no need to program them again. -21- -22- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 14: Central Door Locking Wire Connection

    D wiring section. Here is the EC002 series central door lock wire harness principle: IMPORTANT: Depending on the type of the door lock system, there may be additional wires in the door lock harness and they are not required used in wiring the door locks.
  • Page 15 Motor interrupt central locking:Two wires resting at ground, one pulse 12V for lock, the other pluses 12V for unlock. EC002 output Direct-wired reversing-polarity switches. The switches are wired directly to the motors. This type of system has no factory relays. -25- -26- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.
  • Page 16 This type of door lock system usually requires a negative pulse to unlock, and cutting the wires to lock the door.( for some vehicles, these are reversed). 4.Once the resistor value(s) is determined, refer to the wring diagram for proper wiring. -27- -28- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.
  • Page 17 4.Once the resistor value(s) is determined, refer to the wring diagram for proper wiring. -29- -30- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 18: Wiring Diagram Of Easyguard Ec002

    2.Once you finish all wire connection, test the function first and remember to use the electrical tapes or strips to connect with chassis ground(GND) tighten all the wire connection to avoid any poor connection between the control module & wire harness. -31- -32- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 19: Function Description

    Press the lock button once again will stop. Siren will not beep when the alarm is in mute alarm first then press the push button to start the vehicle. status. -33- -34- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 20: To Enable Or Disable Pke Feature(Pke On/Off Setting)

    20 pin wire harness with the door trigger wire in your vehicle (4). EASYGUARD electronics will not bear any responsibility for the loss caused by the running of the vehicle b.Un-plug the 6 pin ignition wire harness to cut off power of the device first after remote engine start.

  • Page 21: Anti-Hijacking

    And please try again after 1 hour. If user approach the vehicle with remote control when PKE function is turn on, the system will automatically unlock the vehicle door. -37- -38- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 22: Power Off Memory

    If you forget the password, you need to re-set the password to default password first, operation is as below: avoid any injury. -39- -40- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.

  • Page 23: Vibration Alarm(Optional)

    24.GPS tracker( optional) time is back to default starting time 0.8 second. The alarm is with GPS tracker output and can add a GPS tracker on it (only compatible with Easyguard GPS 5. Exit the parameter setting tracker). User can track the vehicle via smartphone (only compatible with IOS & Android system smartphone) or online tracking and more function via the smartphone.
  • Page 24 Any incorrect operation / installation / using lead Please refer to Note 8 in the user manual. the product was failed to work is not in cover of free repair or replacement service. -43- -44- © EASYGUARD Electronics. All right reserved. © EASYGUARD Electronics. All right reserved.
  • Page 25 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
