ALPINE HALO9 9-INCH AUDIO/VIDEO RECEIVER
• OWNER'S MANUAL
Please read before using this equipment.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by
registering your product now at the following address: www.alpine-usa.com/registration.
You will be informed of product and software updates (if applicable), special promotions, news
about Alpine.
Merci d'avoir acheté ce produit Alpine. Nous vous invitons à consacrer un moment à la protection
de votre achat en enregistrant votre produit dès maintenant à l'adresse suivante :
www.alpine-usa.com/registration.
Vous serez tenu informé des mises à jour des produits et des logiciels (le cas échéant), des
promotions spéciales et de l'actualité d'Alpine.
Gracias por adquirir este producto Alpine. Con solo unos pocos pasos podrá proteger su producto,
registrándolo a través de la siguiente dirección: www.alpine-usa.com/registration.
Recibirá información sobre nuevos productos y software, promociones especiales y novedades
sobre Alpine.
ALPINE ELECTRONICS OF AMERICA, INC.
1500 Atlantic Blvd,
Auburn Hills, Michigan 48326, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
iLX-F259
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
EN
FR
ES
Designed by ALPINE Japan

Advertisement

Table of Contents
loading

Related Manuals for Alpine iLX-F259

Summary of Contents for Alpine iLX-F259

  • Page 1 • MODE D’EMPLOI Veuillez lire avant d’utiliser cet appareil. Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by registering your product now at the following address: www.alpine-usa.com/registration. You will be informed of product and software updates (if applicable), special promotions, news about Alpine.

  • Page 2: Table Of Contents

    Night .............. 14 WARNING Clock Setup ............15 Display Off Setting ..........15 Points to Observe for Safe Usage ......5 About iLX-F259 ..........15 WARNING ............5 Displaying the Product Information .... 15 CAUTION ............6 Displaying Warranty/Copyright NOTICE ............7 Information ..........
  • Page 3 Setting the Subwoofer ........19 USB Photo Graphic Equalizer Curve Settings Playback ..............28 (Graphic EQ) ........... 19 Slide Show ............28 Time Correction Settings ........20 Setting a Wallpaper with a Photo ..... 28 Crossover Settings (X-Over) ......20 Volume Setup ............
  • Page 4 Searching in the Phone Book ......36 Synchronizing the Phone Book ..... 36 Deleting the Phone Book Entries ....37 Setting contacts as Favorites (Shortcut Dialing) ........... 37 Bluetooth Audio Playback ..............38 Repeat Play ............38 Shuffle Play ............38 Connecting a Bluetooth Device ......

  • Page 5: Operating Instructions

    They contain instructions on how to use this product NOISES WHILE DRIVING. in a safe and effective manner. Alpine cannot be responsible for problems resulting from failure to observe the instructions in this Excessive volume levels that obscure sounds such as emergency manual.

  • Page 6: Caution

    Failure to do so may cause personal injury or damage to the Doing so may cause heat to build up inside and may result in fire. product. Return it to your authorized Alpine dealer or the nearest Alpine Service Center for repairing.

  • Page 7: Notice

    NOTICE CAUTION Alpine accepts no responsibility for lost data, etc., even if data, etc., is Product Cleaning lost while using this product. Use a soft dry cloth for periodic cleaning of the product. For more severe stains, please dampen the cloth with water only. Anything On Handling USB Flash drive else has the chance of dissolving the paint or damaging the plastic.
  • Page 8 • The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Alpine Electronics, Inc. is under license. • MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson. Supply of this product only...

  • Page 9: Getting Started

    Getting Started Turning Power On or Off When the ignition key is turned to ACC or ON, the opening screen will be automatically displayed. Location of Controls Turn the ignition key to the ACC or ON position. The unit turns on. •...

  • Page 10: Lowering Volume Quickly

    Lowering Volume Quickly Switching Sources Audio Mute function instantly lowers the volume level to 0. Touch the (HOME) button. The HOME screen is displayed. Touch the (MUTE) button to activate MUTE mode. The audio level will be 0. Touch the (MUTE) button again to bring the audio back to previous volume level.

  • Page 11: About The Home Screen

    Adding a widget About the HOME Screen Drag and drop a widget from the additional candidate widgets area to the desired position of the HOME screen image area. In the HOME screen, select a widget to perform various settings and •...

  • Page 12: Setup

    General Setup Setup [General] is selected on the Settings menu screen. General Setup Menu screen Setup Operation To display the Setup Menu screen: Your vehicle must be parked with the ignition key in the ACC or ON position. To do this, follow the procedures below. 1 Bring your vehicle to a complete stop at a safe location.

  • Page 13: Setting The Tuner (Fm) Frequency Step

    Use the keypad to enter the current (old) 4-digit Setting the TUNER (FM) Frequency Step passcode, and then touch [OK]. The initial passcode is set to “0000. ” During manual tuning, you can select the frequency step for FM analog •...

  • Page 14: Wallpaper Setup

    Wallpaper Setup Screen/LED Customize Setup [Wallpaper And Theme] is selected on the General Setup Menu screen. [Screen/LED Customize] is selected on the General Setup Menu screen. You can change the wallpaper of the display screen from 4 different colored default images or your image. Setting item: Dimmer / Screen Dimmer Level / Key Illumination Level Setting a Wallpaper using a default image...

  • Page 15: Clock Setup

    You can view the version information of this product. Make note of this [Clock] is selected on the General Setup Menu screen. information and refer to it whenever you contact Alpine Tech Support You can set the current time and the clock display type, 12-hour or 24- or an Alpine-authorized dealer.

  • Page 16: Connection (Bluetooth) Setup

    • If a 6 character Passkey appears on this device, make sure the same Connection (Bluetooth) Setup passkey is displayed on the Bluetooth compatible device and touch [OK]. • If all 5 devices have been registered, you cannot register a 6th device. To [Connection] is selected on the Setup menu screen.

  • Page 17: Camera Setup

    Camera Setup Rear Camera Guide Settings [Camera] is selected on the Setup Menu screen. [Parking Guide Adjust] is selected on the Camera Setup Menu screen. You can set up items related to the Camera. You can adjust the camera guide position. Setting item: Camera Setup Menu screen Parking Guide Adjust...

  • Page 18: Camera Picture Quality Setup

    Sound Setup Camera Picture Quality Setup [Visual Adjust] is selected on the Camera Setup Menu screen. [Sound] is selected on the Settings menu screen. You can set up items related to the sound quality. You can adjust the picture quality for the primary and secondary cameras.

  • Page 19: Equalizer Settings

    Adjusting the Bass/Treble Equalizer Settings Touch [ ] or [ ] for each item to be adjusted. [EQ Presets] is selected on the Sound Setup Menu screen. Setting item: 10 typical equalizer settings are preset at the factory for a variety of Bass, Treble musical source material.

  • Page 20: Time Correction Settings

    To store the adjusted setting value, touch and hold Crossover Settings (X-Over) [Preset 1], [Preset 2], or [Preset 3] for at least 2 seconds. • Settings exceeding the frequency of adjacent bands are not available. [X-Over] is selected on the Sound Setup Menu screen. •...

  • Page 21: Volume Setup

    Setting the Volume for Apple CarPlay Volume Setup When an iPhone 5s or later is connected, touch [Apple CarPlay [Volume] is selected on the Sound Setup menu screen. Volume] to set the volume for Apple CarPlay mode. Setting item: Entertainment / Notification / Ringtone / Phone Calls Setting contents: 0 to 11 (Initial setting: 5) Adjusting the Volume for Phone...

  • Page 22: About The Crossover

    Adjusting to a frequency range speakers. outside that recommended may cause damage to the speakers. For the recommended crossover frequencies of Alpine speakers, refer to the respective Owner’s Manual. We are not responsible for damage or malfunction of speakers caused by...
  • Page 23 Example 2. Listening Position: All Seats Adjust the time correction level of each speaker to almost the same level. Sit in the listening position (driver’s seat, etc.) and measure the distance (in meters) between your head and the various speakers. Calculate the difference between the distance correction value to the farthest speaker and the other speakers.

  • Page 24: Apple Carplay (Optional)

    Apple CarPlay Android Auto (Optional) (Optional) Apple CarPlay is a smarter, safer way to use your iPhone in the car. Apple CarPlay takes the things you want to do with your iPhone while What is Android Auto driving and puts them right on the unit. You can get directions, make calls, send and receive messages, and listen to music, all in a way that Android Auto is designed to make it easier to use apps from your phone allows you to stay focused on the road.

  • Page 25: Radio

    Radio Presetting Stations Manually There are 3 types of [Radio] widgets for the HOME screen. Tune in a desired radio station you wish to store in the preset memory by manual or automatic seek tuning. Radio main screen example Touch and hold the Preset number you want to store for at least 1 second.

  • Page 26: Usb Flash Drive (Optional)

    USB Flash drive Playback (Optional) Touch the (HOME) button and select USB Audio mode. The display shows the USB Audio mode screen. You can play back music files (MP3/WMA/AAC/FLAC/WAV), video files (MP4/AVI/WMV/MOV) and photo files (JPG/PNG/BMP) stored Touch [ ] or [ ] to select the desired track (file). in a USB flash drive on the internal player of this system.

  • Page 27: Shuffle Play

    For the basic operations on USB Video mode, refer to “Playback” Shuffle Play (page 26), “Fast-forwarding/Fast-reversing” (page 26) and “Searching for a Desired Song” (page 27). Select “USB Video mode” instead for “USB Audio mode. ” Touch [ ] to select Shuffle Play mode. •...

  • Page 28: Usb Photo

    USB Photo Slide Show The Slide Show shows photos that change every 3 seconds. USB Photo mode Preview screen Touch [Play]. • To stop the Slide Show, touch the screen. Setting the Effect for Playback You can set the playback effect how switches to the photo for Slide Show. Touch [Effect], and then select the desired effect.

  • Page 29: Ipod Mode On Iphone (Optional)

    iPod mode on Playback iPhone (Optional) Touch the (HOME) button and select iPod mode. The display shows the iPod mode screen. Touch [ ] or [ ] or to select the desired track (file). A separately sold Lightning to USB cable (KCU-471i), etc., is required. •...

  • Page 30: Searching For A Music File

    Searching for a Music File Shuffle Play An iPhone can contain thousands of songs. For this reason, this unit Touch [ ] to select Shuffle Play mode. can make various searches using the search function as shown below. Songs Song shuffle randomly plays back songs within a Using the Playlist/Artist/Album/Podcast/Audiobook/Genre/ selected category (playlist, album, etc.).

  • Page 31: Siriusxm Satellite Radio Operation (Optional)

    SiriusXM Satellite Receiving Channels with the SiriusXM Tuner About SiriusXM Satellite Radio Radio Operation Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 channels, including commercial-free music plus the (Optional) best sports, news, talk, comedy and entertainment.

  • Page 32: Changing The Display

    No./Song Title Channel No./Content Info Channel No./Channel Changing the Display Name Searching by Channel Text information, such as the channel name, artist name/feature, and song/program title, is available with SiriusXM. The unit can display this Touch [All Channels]. text information as explained below. All Channels will be displayed in a list.

  • Page 33: Bluetooth Operation

    About Bluetooth then connect that Bluetooth compatible device to this unit. The device name of this unit is “iLX-F259” and the initial number of the passcode Bluetooth is a wireless technology allowing communication between a is “0000. ” Also refer to the Owner’s Manual of the connected device(s).

  • Page 34: Answering A Call

    Phone Book* Calling You can make a phone call from the Phone Book, or edit the Phone Book. Redial Making a phone call using the Phone Menu Dials to the last called number. * If the Hands-Free Phone is not connected, the Bluetooth Setup screen will be displayed.

  • Page 35: Using Voice Recognition Function

    Touch [ ] (Call). Voice Dial Function A confirmation message of the phone number appears. You can make a telephone call by using voice operation. Touch [Call]. • Connect your smartphone to the unit via Bluetooth, then set to “Hands- The phone call is started.

  • Page 36: Phone Operation Screen

    Phone Operation Screen Phone Book Function Phone Book screen example Name and phone number • If it is registered with a Group, the Group Name is also displayed. Searching in the Phone Book Although, depending on the connected mobile phone, it may not be displayed.

  • Page 37: Deleting The Phone Book Entries

    Deleting the Phone Book Entries Bluetooth Audio Deleting One Entry from the Phone Book If a Bluetooth compatible mobile phone, portable player, etc. is Touch [ ] of the contact name (or phone number) you want connected by wireless, you can play back a song (operation is to delete.

  • Page 38: Playback

    Playback Connecting a Bluetooth Device Registering a Bluetooth device in the unit enables automatic connection. Touch the (HOME) button and select Bluetooth If it does not connect automatically, run through the connection Audio mode. procedure again. The display shows the Bluetooth Audio mode screen. Touch [Reconnect] on the Bluetooth Audio screen.

  • Page 39: Camera Operation (Optional)

    Camera Operation About the Rear Camera Guide To display the guide, set “Turning the Rear Camera Guide On/Off ” (Optional) (page 17) to On. Also, to adjust the guide, see “Rear Camera Guide Settings” (page 17). When an optional camera is connected, the view video of camera can be Indication mark meaning output to the monitor.
  • Page 40 Distance guidance mark <Situation of the car> Actual distances The distance guides represent the ground level distance from the rear bumper. It is difficult to accurately estimate the distance to objects above ground level. In the following example, the distance to A is 0.5 m and the distance to B is 1 m.

  • Page 41: Product Software Update

    MP3: “mp3” This product use software that can be updated through a USB flash WMA: “wma” AAC: “m4a” drive. Download the software from the Alpine website and update the FLAC: “flac”/”fla” product using the USB flash drive. WAV: “wav” WMA is not supported for the following files, Windows Media Audio...
  • Page 42 Corresponding File Systems Terminology This device supports FAT 16/32. Bit rate The maximum nested folder depth is 8 (including the root This is the “sound” compression rate specified for encoding. The higher directory). File names are limited to 256 characters (including the the bit rate, the higher the sound quality, but also the larger the files.

  • Page 43: In Case Of Difficulty

    • If the area you are in is a primary signal area, the antenna may properly connected, or then consult your authorized not be grounded and connected properly. Alpine dealer. - Check your antenna connections; make sure the antenna is properly grounded at its mounting location.

  • Page 44: If This Message Appears

    Bluetooth If this Message Appears No Bluetooth • The Bluetooth audio device was not connected correctly. Various messages are displayed on the screen during operation. In - Check the settings for the unit and the Bluetooth audio device addition to the messages telling you the current status or providing and reconnect.

  • Page 45: Specifications

    Bluetooth SECTION Specifications Bluetooth Specification Bluetooth V4.1 Output Power +4 dBm Ave. (Power class 2) MONITOR SECTION Profile HFP (Hands-Free Profile) PBAP (Phone Book Access Profile) Screen Size 9” A2DP (Advanced Audio LCD Type Transparent type TN LCD Distribution Profile) Operation System TFT active matrix AVRCP (Audio/Video Remote...

  • Page 46: Limited Warranty

    ALPINE ELECTRONICS OF AMERICA, INC. (“Alpine”), is dedicated to quality craftsmanship and is pleased to offer this Warranty. We suggest that you read it thoroughly. Should you have any questions, please contact your Dealer or contact Alpine at one of the telephone numbers listed below.
  • Page 47 N’oubliez pas de consacrer un moment à la protection de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante : www.alpine-usa.com/registration. Recuerde que con solo unos pocos pasos podrá proteger su producto, registrándolo a través de la siguiente...
