container cushion and put it in the center of the top surface
of the container. Then push the container platform onto
the clamping plate. Hang the container spring onto the
container handle and close the door (see Figure 6.1 and
Figure 6.2). (If the shaker is equipped with extractable plate,
the rubber cushion shall be located in the center of plate. Then
choose a foam cushion on the top of the can, then push it to the loading plate via the extractable
plate.)
3) Choose shaking time by pressing corresponding button(s). LCD displays "Clamping" while
clamping plate moves down slowly. After the container is clamped well, shaking begins. LCD
displays "shaking" and counting-down of time.
4) The machine stops working after the set time is finished. LCD shows "Wait Please" and the
clamping plate rises to release paint container and stops after reaching a proper height.
5) Open the viewing door. Pull out the container platform and take the container out. LCD
displays " Ready" for another round of shaking. (Take out the paint container if there is no
extractable plate).
6) The clamping plate, loading plate, container platform and the two side screws should be
cleaned every day.
7) The big rubber cushion and thick/thin top container cushions are available (Fig. 6.4). As for
the big container which is at least 15L, the big rubber cushion could be located on the roller,
and put the container in the center of the cushion. Then choose a top container cushion
according to the height of the container edge (Fig. 6.4). The top container cushion shall be of
the similar height of the container edge. The bottom edge of the container shall contact with
the step surface (Fig. 6.5) of the big rubber cushion. Or the bottom of the container might be
deformed/destroyed during the operation. Then push the container into the center of the
clamping plate (Fig. 6.2). As for the small container which is 5L, you may located it in the
recess of the big rubber cushion. No need to add a top container cushion(Fig. 6.4). As for the
containers which are less than 5L, no need to add any cushion. They shall be located in the
center of the clamping plate.
Automatic Shaker
Santint
V1.0
Hanging Spring
Fig. 6.2
