- Page 1 PURE INSTRUCTION MANUAL FOR USE www.iconeway.com...
- Page 3 Bicycles with Assisted Pedaling on public roads (see the Highway Code). ICONE Assisted Pedal Bikes comply with the provisions of Art. 50 of the Highway Code: Bicycles are vehicles with two wheels or more wheels operating exclusively muscular propulsion, by means of pedals or similar devices, operated by the persons who are on the vehicle;...
-
Page 4: Table Of Contents
CONTENTS 1. Important information 2. Checks before the first hike 3. Driving 4. Folding and methods of use 5. Use of your e-Bike ICONE 6. Recharging and protecting the battery 7. Maintenance and repair 8. Issues requiring attention 9. Maintenance 10. - Page 5 ICONE e-Bike was made with parts that have been developed and produced with precision. In this manual you will find a collection of tips on the use of the ICONE e-Bike, as well as important information about its construction features, care and maintenance.
- Page 6 SAFETY AND BEHAVIOR The driver must be at least 16 years old. The driver must be able to ride a bike, must have basic knowledge of the use of a bike, and be equipped with the sense of balance necessary to drive and control a Pedal Assisted bicycle. The driver must be able to get on and off safely when stationary.
-
Page 7: Important Information
We ask for your cooperation in the case of any differences or non-compliance with the manual. Please read the warnings and precautions contained in this manual before using the ICONE e-Bike. If you lend your electric bicycle to others for use, let users carefully read the instructions in order to minimize the possibility of accidents. - Page 9 CHECKS BEFORE THE FIRST EXCURSION CAREFULLY CHECK THE STATE OF THE BICYCLE BEFORE USE: • Carefully check the brakes, wheels and tires, the foldable connection and the quick disassembly parts, to ensure that the bicycle is in good condition. • Check that the battery charge is sufficient to support the mileage you intend to drive. •...
- Page 10 RIDING POWER ON: Turn on the switch (turn the key to ON) the display will light up when connected. EPAC/PEDELEC: Just like normal bicycles, position the bike and get onto the saddle, place one foot on the pedal and start pedaling after ensuring that everything is OK. Once the speed is reached during the ride, the engine will automatically activate and start working and moving your e-Bike.
-
Page 11: Use Of Your E-Bike Icone
USE OF YOUR E-BIKE If you do not use the electric bike for more than 5 minutes, the display will turn off automatically. Adjust the speed as necessary and with the + and - buttons. It is recommended to start slowly and then increase according to road conditions and traffic. - Page 12 CHARGING AND PROTECTION OF THE BATTERY Use the charger that corresponds to your e-Bike (never use the charger of a different model). Before charging, set the switch to OFF and remove the key. Keep the charger in a dry and ventilated place when not in use.
- Page 13 After charging, first remove the plug from the electrical outlet and then from the e-Bike battery. Do not leave the connector plugged into the battery and the outlet for a long time, as it may damage the battery and/or cause a fire. When charging, keep out of reach of children.
-
Page 15: Maintenance And Repair
MAINTENANCE AND REPAIR The front and rear wheels of the vehicle must be in the center of the front fork and the frame. The tension of each spoke of the rim must be similar, maintaining the rim with a normal shape, without breaking or bending. - Page 16 MATTERS THAT REQUIRE ATTENTION Every time you ride your bike, you need to check the distance, strength, and efficiency of the brakes. Attention: if the brakes work abnormally, the motor may stop working. • Respect traffic laws and regulations, never reverse if not in absolute safe or secure to do so.
-
Page 17: Maintenance
MAINTENANCE WARNING! Before carrying out any type of maintenance, switch off and remove the key. If the poles of the battery are dirty, clean the poles so as to not to reduce the efficiency of the battery or burn the poles themselves. -
Page 18: Technical Data
TECHNICAL DATA Weels 20” KENDA / CST** Mechanical disc brake fr. / rr. Suspension fork Rear SHIMANO 6 speed Crank in steel Bolts in steel Light a LED operated display on Foldable and height adjustable handlebar Foldable saddle for battery extraction Motor 250W Brushless Max weight capacity 115 kg Easel rear... -
Page 19: Information On The Assistance Service
INFORMATION ON THE ASSISTANCE SERVICE Users must operate according to this product manual, in case of production defects, according to the provisions of the law, the company fulfills its warranty obligations. After the warranty period has expired on the main components, all services will be subject to payment. - Page 20 Brake lever front wheel brake front wheel brake assignment rear wheel brake rear wheel brake of the levers Stamp and signature of the ICONE specialist dealer GUARANTEE CARD Customer Surname, Name Address Post code / Localion Tel / Fax E-mail Model Please keep this card handy.
-
Page 21: Delivery Report
DELIVERY REPORT The delivery of the above-mentioned ICONE e-Bike to the customer, after the final assembly, should be in running condition. Verification of the regular operation of the points indicated below (the further necessary operations are shown in brackets). Lighting... - Page 22 NOTES...
- Page 23 Photograph the QR code with a smartphone or tablet and discover the ICONE world. Connection costs based on the mobile phone contract.
- Page 24 #iconeway www.iconeway.com © 2019 ICON.E | All rights reserved.
