Battery Status Indicators - Infinite Peripherals Imperea Quick Start Manual

Quick Start Guide | Imperea
Charge Imperea with a Single Charging
Station
For the single charging station to perform effectively, use the power
adapter included.
1. Plug the USB-A end of the charging cable into the provided adapter. The
top LED flashes green.
Note:
To prevent damage to the unit, do not plug the cable into a USB port on a
computer or other adapter.
2. Place the unit on a single station charger, lining up the bump on the base of
the charger with the bottom notch on the Imperea.
3. Ensure the unit is centered on the charger, and then wait to hear the
charging beep, which signals the Qi charging is begun.
4. The LED light on the single charging station blinks green when the unit is
being charged.

Battery Status Indicators

On the back of the unit, four LEDs will illuminate based on the battery
status when the battery status button is pressed.
Status Description
4 100% charged
3 75% charged
2 50% charged
1 25% charged
Programmable Buttons
The three blue buttons can be configured in the application that uses our
SDK to perform specific functionality.
Using Your Imperea
Do the following to operate your Imperea.
1. Remove the tape on the battery contacts before first use.
2. Turn on the Imperea.
3. If the battery indicator on the upper right-hand corner of the iPhone
screen is not green with a lightning bolt, then press and hold the battery
status button on the back of the unit for 5 seconds.
4. This also enables a back-up charge to the iPhone.
Mute Ringer and Volume Control
Turn the Imperea to the side to locate the ringer and
volume controls.
• Mute ringer, press the knob above the volume button.
• Change volume, press the volume button.
