Hardware Guide
WiFi
Version 2013.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WiFi and is the answer not in the manual?

Questions and answers

Summary of Contents for IRTrans WiFi

  • Page 1 Hardware Guide WiFi Version 2013.02...
  • Page 2 Hardware Guide WiFi EG Declaration of Conformity The following produtc IRTrans WiFi Is confirmed to comply with DIN EN 55024: 1998 + A1: 2001 + A2: 2003. ©2012 IRTrans GmbH...
  • Page 3: Table Of Contents

    Hardware Guide WiFi Contents 1. IRTrans WiFi / WLAN ..............4 1.1 Connections ..................4 1.2 Power supply ..................4 1.3 USB connection / installing drivers ........... 5 1.4 Settings / startup ................5 1.5 Web Interface ................... 6 1.6 Jumpers .................... 7 2.
  • Page 4: Irtrans Wifi / Wlan

    WLAN Status LED  1st output The left 3,5mm jack is present on all IRTrans devices but not active unless a se- cond output (2X option) or bidirectional RS232 option is installed. 1.2 Power supply The IRTrans Ethernet is powered by an external power supply. It must deliver 8- 16V and 300mA per IRTrans device.
  • Page 5: Usb Connection / Installing Drivers

    Hardware Guide WiFi 1.3 USB connection / installing drivers The IRTrans WiFi is equipped with a mini USB connector for configuration and firmware updates. IPAssign does not work with IRTrans WiFi. Use USB for configuration. Before connecting the IRTrans to the PC the software / drivers must be installed.
  • Page 6: Web Interface

    IR- Trans servers device status dialogue as well. To access the web interface simply type the IP adress of the IRTrans in an inter- net browser: http://192.168.0.32...
  • Page 7: Jumpers

    For a detailed description refer to the software hand- book. 1.6 Jumpers Inside the IRTrans WiFi there are several jumper for configuration purposes. The- se will be set by factory and must not be altered. Changing jumper settings inside the IRTrans will not activate additional features.
  • Page 8 192.168.0.x. An entry 192.168.0.1 / 255.255.255.255 allows only one client to use the IRTrans LAN. The access rights are active for all TCP and UDP functions. To avoid a complete lock-out it is always possible to access the web front end from within the local network of the device –...
  • Page 9 – otherwise the irserver will not receive IR codes from this IRTrans module. The UDP Broadcast fields are only used for modules with integrated IR Data- base.
  • Page 10: External Ir Transmitters

    (455kHz). The high frequency trans- mitters can be recognised by clear LEDs. High power transmitters can be connected to all of the IRTrans devices. Cables should not be extended beyond standard length (1,8m~6ft). Longer cables lead to distorted IR signals.
  • Page 11: Devices With 2X Option

    IRTrans modules with 2X option offer a second independent output for external transmitters. This is normally done by the 2nd (left) 3,5mm jack. If the IRTrans is equipped with a RS232 interface the RS232 interface will use the leth jack and the 2nd IR output is available by stereo plug on the first (right) jack.
