- Page 1 OWNER’S MANUAL SUPPLEMENT AIRBAG DEPLOYMENT ZONES FOR 2019 FULL SIZE VANS (CHEVROLET EXPRESS/GMC SAVANA)
- Page 2 Note to User: As part of our mission to provide an up-to-date website that includes detailed Body Builder Manuals, Technical Bulletins, and Best Practice Manuals, we are now using sectional excerpts directly from the General Motors Service Information publications for our Electrical Body Builder Manuals.
- Page 3 Contents Introduction ..... . 2 Seats and Restraints ... . 3 Index .
- Page 4 General This supplement contains Motors of Canada Company for information specific to the unique Chevrolet or GMC Motor Division components of the vehicle. It does wherever it appears in this manual. not explain everything you need to Keep this manual in the vehicle for know about the vehicle.
-
Page 5: Airbag System
Seats and Restraints Seats and Airbag System Warning Restraints Questions and Answers Airbags inflate with great force, faster than the blink of an eye. No About Airbags and objects, such as shotguns, should Specialty Law Airbag System be placed over or near the airbag Questions and Answers About Enforcement Vehicles covers. - Page 6 Seats and Restraints zones for your specialty vehicle. bumpers that have been Warning (Continued) Before doing any service work, installed on current model GM including the installation of any police vehicles with airbags. Do not attach anything to the equipment, consult the See Adding Equipment to the steering wheel hub or mount any appropriate service manual.
- Page 7 Seats and Restraints Warning (Continued) Caution Do not mount a security barrier GM approved service procedures such that the ends of the barrier must be followed to remove and or brackets are within the roof-rail reinstall the instrument panel to airbag deployment zones.
- Page 8 Seats and Restraints Airbag Deployment Diagrams Top View of Instrument Panel and Approximate Deployment Area of the Airbag Zone...
- Page 9 Seats and Restraints 1. Instrument Panel 2. Passenger Side Airbag Deployment Door 3. Passenger Side Airbag Deployment Zone 4. Driver Side Airbag Deployment Zone See Customer-Installed Equipment 0 4.
- Page 10 Seats and Restraints Rear View of the Instrument Panel and Approximate Deployment Area of the Airbag Zone...
- Page 11 Seats and Restraints 1. Diameter of Driver Side Airbag 2. Driver Side Airbag Deployment Zone 3. Passenger Side Airbag Deployment Zone 4. Top of Instrument Panel 5. Bottom of Passenger Side Airbag Door 6. Instrument Panel See Customer-Installed Equipment 0 4. Roof-Rail and Seat-Mounted Side Impact Airbag Deployment Zones Passenger Side Shown, Driver Side Similar (Passenger Van) 1.
- Page 12 Seats and Restraints Roof-Rail Side Impact Airbag Deployment Zones Passenger Side Shown, Driver Side Similar (Cargo Van and Cutaway Models) 1. Back of B-Pillar 2. Zone B 3. Zone B Roof-rail Inflator Location 4. Upper Corner of Windshield 5. Front of Door Mirror Patch Roof-Rail Side Impact Airbags, Driver and Passenger Deployment Zones View from Rear Cargo Area (Passenger, Cargo Vans, and Cutaway 6.
- Page 13 Seats and Restraints 3. Edge of Headliner 4. Inner Pillar Trim 5. Inner Front Door Trim 6. Front Seatback Side Deployment Zone (520 mm (20.5 in) Above Seat Cushion) (180 mm (7.1 in) From Door Trim) 7. Front Seatback and Headrest 8.
- Page 14 Index Index Airbags Vehicle Deployment Diagrams ... 6 Canadian Owners ....2 Questions and Answers About Airbags and Specialty Law Enforcement Vehicles .
