- Page 1 The First Quiet High Power VACUUM BLENDER User Guide for vacuum blender that makes natural juice ※Malfunction of vacuum sensor can be caused over 500 Meters of altitude above sea level. ※The product should not be used in countries using different voltage. *HOUSEHOLD USE ONLY...
-
Page 2: Special Features
Special Features Vacuum Blending Triple 3D Moving Blades [Deep Blending Function] In optimal vacuum conditions with pressure of -80kPa, 3D-Moving System with specially-heat treated 6 Blades it preserves color and nutrients by preventing ingredients from rotating tridimensionally enables deep blending. contacting air and enriches the natural taste of fresh ingredients. -
Page 3: Important Safeguards
CONTENTS Special Features Do not use the product outside its intended purposes How to Use Each Function Before requesting service Important Safeguards How to Operate Specification (Vacuum, Auto, Auto-blending). Safety Warning Cleaning and Care / Do not dismantle, assemble or change the product or parts, How to use (Optional) Blade wrench Tips on Operating and be sure to repair any failure at service centers. -
Page 4: Safety Warning
Do not use or store near heat or open flame. Safety Warning ㆍ It might cause deformation or discoloration of the product. Do not touch the power plug with wet hands. Never dismantle, repair or remodel Body. ㆍ Otherwise, it might cause electric shock. ㆍ... -
Page 5: Before Use
Tips on Operating Parts Vacuum Display It changes to blue during vacuum and returns to white after completion of vacuum. Before use Noise Reduction Cover It minimizes noise when blending, with a vacuum function equipped in. 1. Check if the Container and Container lid are perfectly combined into the Body. Vacuum Valve It is used for keeping/clearing the vacuum (If the Container is not perfectly combined to the Body, the product will not work). -
Page 6: How To Use Each Function
Maximum Capacity of Container by ingredients How to Use Each Function Control part Function How to use - Add liquids (Water, Milk, Juice, etc) because the blades may be going around or the blending particles may become rough when the ingredients are thick. Dial button Power standby * When the power is turned on and the Container is perfectly combined. -
Page 7: How To Operate
How to operate - After purchasing the product, clean the Container and Blade Assembly with dish detergent before using. - At the initial use, Body may generate a little amount of smoke and smell. Bee~ Turn the Power on. (This is caused during the motor drying process and will disappear after a few times of use). - Each function has a Smart Auto-Control function, which automatically stops operation when ingredients become the optimal condition. -
Page 8: Before Requesting Service
Cleaning and Care / How to use (Optional) Blade wrench Before requesting service When abnormality occurs during operation - When cleaning the Container, - Putting the Noise Reduction Cover in water may do not put the Blade Assembly in water. cause failure;... -
Page 9: Specification
Specification Product name Vacuum blender Model name SV-500E, SV-510E, SV-520E, SV-530E, SV-500B, SV-510B, SV-520B, SV-530B, SV-500 Rating voltage AC220~240V / 50~60Hz Power consumption 1500W Product size 216mm x 240mm x 443mm Rating time Auto control. Weight 6.2kg Container capacity Maximum capacity of blend: 1300ml / maximum capacity of grinding: 500ml Manufacturer NUC Electronics Co., Ltd.
Need help?
Do you have a question about the SV-500E and is the answer not in the manual?
Questions and answers
No, Your vaccum blender is a total crap. this is the third time is stops working in 3 years. The vaccum pump turns on, but no vaccum. Now, the front light is red and nothing works. Kuvings is nothing but problems. What to do? Get is to service center again and pay another 6000 baht to get it fix? Or junking it and buy another brand.
If the Kuvings SV-500E vacuum blender stops working and the vacuum pump turns on but does not create a vacuum, you should:
1. Assemble the Vacuum Valve and Container Lid properly.
2. Put the Noise Reduction Cover in place properly.
This answer is automatically generated
