Page 1: User Manual
EMU Router User Manual Revision: V.07 Emu Router User Manual Rev: V0.7 June 2016 ConnectedIO CONFIDENTIAL... - Page 2 V0.2 ConnectedIO Modem page 19-4-2016 V0.3 Modify Language Setting ConnectedIO 07-06-2016 V0.4 Change Company Logo ConnectedIO Change IP address to default 30-06-2016 V0.5 ConnectedIO 192.168.45.1 16-07-2016 V0.6 Add Approvals and Certifications ConnectedIO 10-08-2016 V0.7 Add Antenna Section ConnectedIO ConnectedIO CONFIDENTIAL...
-
Page 3: Table Of Contents
4.4. Firmware Upgrade 5. Modem 5.1. AT Command 5.2. APN Change 5.3. Mode Setting 6. LOG 6.1. System LOG 6.2. Kernel LOG 7. Antenna 7.1. Antenna – Installation Guidelines 7.2. Maximum Antenna Gain 7.3. Recommended Antennas 8. Environmental ConnectedIO CONFIDENTIAL... - Page 4 EMU Router User Manual 8.1. Operating Environment 8.2. Physical Parameters 9. Approvals and Certifications 9.1. Manufacturing 9.2. North American Certifications 9.2.1. ER1000-VZ & ER1000T-NA 9.2.2. ER1000T-NA 9.3. European Certifications 9.3.1. ER1000T-EU ConnectedIO CONFIDENTIAL...
-
Page 6: Introduction
1. Introduction ConnectedIO Emu Router is a 4G router with full band offering LTE connectivity for M2M applications. The Emu router includes a 4G modem and an embedded host processor based on Mediatek MT7620A SoC. The 4G connectivity is made by an operator certified LTE module. The host platform provides Linux based embedded operating system and openwrt code base. - Page 7 Connect the Ethernet cable between the computer and the Emu Router LAN port Setup the desktop as a static IP in 192.168.45.x domain or DHCP client to get IP from EMU Router Open a browser and type http://192.168.45.1 to start the settings On login page, you can just click the Login icon to enter the GUI as shown in Figure 1.
-
Page 8: Setup New Ip
Figure 2: Overview Page 3.2. Setup New IP Select Network->Interfaces as shown in Figure 3. - Page 9 Figure 3: Network List Select LAN and click “Edit” from Figure 4. Figure 4: Interface Overview Enter the new IP address in the “IPv4 address” filed, and then click the “Change” icon in the bottom-right corner in Figure 5.
- Page 10 Figure 5: New IP Address for LAN After setup new IP, the GUI will return to “Interface Overview”, you have to press “Apply” in the upper right corner as shown in Figure 6. Figure 6: Save the New Setting After pressing “Apply”, the system will show a confirmation window. Please see Figure 7.
-
Page 11: Enable/Disable The Dhcp Server On Lan Interface
Figure 7: Configuration Change 3.3. Enable/Disable the DHCP Server on LAN Interface [N.A] 4. System Maintenance This chapter describes how to back-up the current EMU Router configuration to your computer, and how to restore that same configuration at a later date if needed. -
Page 12: Backup The Configuration
4.1. Backup the Configuration Select Firmware in the GUI page then click the icon “Generate archive” to save this configuration file in the folder you specified. Figure 9: Backup the Configuration The file is in tar.gz format, we suggest that you can rename it to a meaningful file name. -
Page 13: Reset To Factory Default Under Web Gui
Figure 10: Restore the Configuration 4.3. Reset to Factory Default under Web GUI Click the icon “Perform reset”, a warning window will pop-up saying “Really reset all changes?” The device will reset to factory default and reboot if “Yes” is chosen. NOTE: It is important NOT to power off the device before the entire process is completed. -
Page 14: Modem
“browse” and select the new image that you want upgraded to the device. The upgrade process may take longer than 10 minutes for flashing and rebooting. It is important NOT to power off the device during the process. Administrators can PING the device after the upgrade process is completed to ensure that the device is programmed and rebooted successfully. -
Page 15: At Command
Select Network -> Modem as shown Figure 14. Figure 14: Modem Page 5.1. AT Command You can use the AT command to check the LTE status. The AT command format is “AT+ Command” for example: AT+CSQ. Enter the AT command and click “Send”. -
Page 16: Apn Change
5.2. APN Change Typically, your APN is auto-configured or auto-detected. The APN Change command allows you to change the local telecommunication company. Enter the APN name and click “Change” button as shown in Figure 16. Figure 16: APN Change If you would like to check whether the APN setting is successful, pleases enter AT command “AT+CGDCONT?”... -
Page 17: Log
Figure 18: Mode Change 6. LOG 6.1. System LOG Select Status -> System Log Figure 19: System Log 6.2. Kernel LOG Select Status -> Kernel Log... -
Page 18: Antenna
Figure 20: Kernel Log 7. Antenna 7.1. Antenna – Installation Guidelines When installing the antenna to the ER1000 product line there are a number of items to consider so good antenna performance can be maintained. Install the antenna in a place covered by the LTE signal. ... -
Page 19: Maximum Antenna Gain
The antenna should be install and operated with a minimum distance of 20cm between the radiator and the human body. Antenna gain must not exceed the limits in the following table: Frequency Band ER1000-VZ ER1000T-NA 700 MHz 6.0 dBi 8.0 dBi 850 MHz 6.0 dBi... -
Page 20: Environmental
RoHS Compliant 9.2. North American Certifications 9.2.1. ER1000-VZ & ER1000T-NA FCC Compliance o This device Complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 21 TBD ========== End of Document ==========...
