ER200T Router Users Guide
Rev: V10.0
October 30, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ER200T and is the answer not in the manual?

Questions and answers

Related Manuals for ConnectedIO ER200T

Summary of Contents for ConnectedIO ER200T

  • Page 1 ER200T Router Users Guide Rev: V10.0 October 30, 2018...

  • Page 2: Table Of Contents

    Table of Contents HARDWARE CONFIGURATION ........................4 1.1............................4 RODUCT NTERFACES RS-232 CONFIGURATION ..........................6 2.1..........................6 INDOWS LATFORM XAMPLE 2.2. : ..........................8 INUX LATFORM XAMPLE RADIO CONFIGURATION ..........................11 SYSTEM CONFIGURATION ..........................12 4.1. IP S ...............................
  • Page 3 Introduction Connected IO Inc’s., ER2000T is a 4G - CAT1 router for M2M applications. The Router includes a 4G modem with an embedded host processor based on the Mediatek MT7620A SoC and supports 802.11 b/g/n WiFi functionality. The 4G connectivity is made by an operator certified LTE module. This document provides instructions, and basic operational guidelines, to aid a Systems Administrator with the deployment of this product.

  • Page 4: Hardware Configuration

    1. Hardware Configuration 1.1. Product Interfaces Number Item Description DC Power Input 12VDC @ 2.0A Input. Center conductor is Positive Push & Release to reset the device Reset Button Push & Hold for 5-seconds then release installs factory preset 2FF Mini-SIM format SIM Access Slide the door open to access the SIM holder.
  • Page 5 Number Item Description WiFi Antenna SMA connector for WiFi Antennas (NOT Reverse Polarized) Cellular Antennas SMA connector for both Primary and Diversity Antenna Ports WiFi LED, Orange: Wifi is connected/Off: No WiFi Power LED, Yellow: Power is connected/Off: unit is off Cellcular Connection Strenght Indicators, Green: Cellcular Connection The following table lists the signal strength range corresponding to...

  • Page 6: Rs-232 Configuration

    2. RS-232 Configuration The serial port communication on ER2000T series is a bidirectional asynchronous mode transfer mechanism with the following default settings: Data Rate: 9600bps Date bits, Parity, Stop bit: 8N1 Flow Control: No 2.1. Windows Platform Example TeraTerm software was used to demonstrate this tutorial in Windows mode. 1.
  • Page 7 Output (Windows Tera Term): © 2018 – Connected IO, Inc. P a g e...

  • Page 8: Linux Platform Example

    From tera term, type a few keys and they will appear on the router side when "cat /dev/ttyS0" command is run. Input (Windows Tera Term): Output (ER2000T-X-CAT1): 2.2. Linux Platform Example: Minicom software was used to demonstrate this tutorial in Linux. 1.
  • Page 9 Output (Linux Minicom or Putty): From minicom, type a few keys and they will appear on the router side when "cat /dev/ttyS0" command is run. © 2018 – Connected IO, Inc. P a g e...
  • Page 10 Input (Linux Minicom): Output (ER2000T-X-CAT1): 10 | P a g e © 2018 – Connected IO, Inc.

  • Page 11: Radio Configuration

    3. Radio Configuration Model Name LTE Band (MHz) 3G (MHz) WiFi  B2: 1900 PCS  B4: 1700/2100 AWS 1  B2: 1900  Yes, 802.11 b/g/n ER2000T-NA-CAT1  B5: 850  B5: 850 compliant  B12: 700 ac  B13: 700 c ...

  • Page 12: System Configuration

    4. System Configuration 4.1. Initial IP Setup The Router Management GUI can be accessed through the Ethernet ports with the default IP address of 192.168.71.1. To configure the Router, follow the following sequence: • Connect the Ethernet cable between the computer and the Router LAN port •...
  • Page 13 You should now see the LOGIN PAGE as shown in Figure 1. The default password is “password”. Please create a new password under Web GUI System->Administration page to secure your router. Figure 1: Login Page Now you should see the Router OVERVIEW PAGE which includes important messages such as system status and memory information as shown in Figure 2.

  • Page 14: Setup New Ip

    4.2. Setup New IP Select Network->Interfaces as shown in Figure 3. 14 | P a g e © 2018 – Connected IO, Inc.
  • Page 15 Figure 3: Network List Select LAN and click “Edit” from Figure © 2018 – Connected IO, Inc. 15 | P a g e...
  • Page 16 Figure 4: Interface Overview Enter the new IP address in the “IPv4 address” filed, and then click the “Change” icon in the bottom-right corner in Figure 16 | P a g e © 2018 – Connected IO, Inc.
  • Page 17 Figure 5: New IP Address for LAN After the new IP setup, scroll down to the bottom of the page and press “Save & Apply” as shown in Figure Figure 6: Save the New Setting © 2018 – Connected IO, Inc. 17 | P a g e...

  • Page 18: Connecting To Wifi

    5. Connecting to WiFi For computers using the Windows operating system (For instance: Windows 10), Click the network internet access icon and if there are wireless networks in range, try to connect to a WiFi “ConnectedIO_M2M” network without security key as shown in Figure Figure 8 : Network Internet Access Open a browser and typing...

  • Page 19: System Maintenance

    6. System Maintenance This chapter describes how to back-up the current Router configuration to your computer, and how to restore that same configuration at a later date if needed. This can be done by selecting System > Backup/Flash Firmware: Figure 10: System List ©...

  • Page 20: Backup The Configuration

    6.1. Backup the Configuration Select Firmware in the GUI page then click the icon “Generate archive” to save this configuration to a file in the folder you’ve specified. Figure 11: Backup the Configuration The file is in tar.gz format, CIO suggests that you rename it to a meaningful filename for easy recovery. 20 | P a g e ©...

  • Page 21: Restore The Configuration

    6.2. Restore the Configuration Click the icon “Choose File”, select the backup file, and then click “Upload archive” in flash operations page as shown Figure 7. Device will write the stored configuration back to flash then reboot the system. Figure 7: Restore the Configuration 6.3.

  • Page 22: Firmware Upgrade

    7. Firmware Upgrade Select System from web GUI and find “Backup/Flash Firmware”. Click the icon “Choose File” and select the new upgrade image. Then click “Flash image”. Figure 9: Firmware Upgrade After system uploads the file, click “Proceed” on the confirmation page as shown in Figure 15. The upgrade process may take longer than 10 minutes for flashing and rebooting.
  • Page 23 Figure 10: Firmware Upgrade Verify © 2018 – Connected IO, Inc. 23 | P a g e...

  • Page 24: Modem

    8. Modem Select Network -> Modem as shown Figure Figure 11: Modem Page 8.1. AT Command You can use AT commands to check the LTE status. The AT command format is “AT+ Command” for example: AT+CSQ. Enter the AT command and click “Send”. AT command responses will be displayed in the message bar right below the command see Figure Figure 12: AT Command Example...

  • Page 25: Apn Change

    8.2. APN Change Typically, the APN is auto-configured or auto-detected. The APN Change command allows you to change the local telecommunication company. Enter the APN name and click “Change” button as shown in Figure Figure 13: APN Change If you would like to check whether the APN setting is successful, pleases enter AT command “AT+CGDCONT?”...

  • Page 26: Logs

    9. Logs 9.1. System Log Select Status -> System Log Figure 21: System Log 9.2. Kernel LOG Select Status -> Kernel Log Figure 14: Kernel Log 26 | P a g e © 2018 – Connected IO, Inc.

  • Page 27: Antenna

    Antenna 10.1. Detachable Antenna Guidelines This M2M Router device, ER2000T-NA-CAT1 and ER2000T-VZ-CAT1, integrates an LTE (4G) and WiFi radio function. Is uses an external antenna (dipole antenna) and a standard antenna connector (SMA type) which is not covered under FCC 15.203 requirements. Therefore, this equipment needs to be installed by a professional technician since the M2M application usually resides inside other equipment where the end- user cannot change the external antennas easily.

  • Page 28: Recommended Antennas

    • At least 20cm of separation distance between the antennas, the collocated router transmitters, and the human body must be maintained always. 10.4. Recommended Antennas To aid in selecting an antenna for this router device the following antennas are recommended as functional and meeting the requirements for most M2M applications.

  • Page 29: Environmental

    Environmental 11.1. Operating Environment • Operating Temperature: -20°C to +55°C • Storage Temperature: -40°C to +85°C 11.2. Physical Parameters • Size: 114.6mm x 99.6mm x 24.7mm • Weight: 157gr. © 2018 – Connected IO, Inc. 29 | P a g e...

  • Page 30: Approvals And Certifications

    Approvals and Certifications 12.1. Manufacturing • RoHS Compliance • This device has been tested and found to be RoHS compliant with the council RoHS directive – 2011/65/EU. 12.2. North American Certifications 12.3. ER2000T-NA-CAT1 & ER2000T-VZ-CAT1 • FCC Compliance: This device Complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions.

  • Page 31: Fcc General Warning

    FCC General Warning This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 32: Industry Canada (Ic) Notices

    antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Antenna Manufacturer Part No. Peak Gain Type LTE: 698-960MHz/1710-2170MHz/2500-2960MHz 0.7 dBi Max / 3.8 dBi Max / 3.2 dBi Max GTT Europe LTD OA-LTE-01-01-GT Omni-Dipole...
  • Page 33 Ce périphérique a également été évalué et démontré conforme aux limites d'exposition aux RF d'IC dans des conditions d'exposition à des appareils mobiles (antennes sont supérieures à 20 cm à partir du corps d'une personne). Detachable Antenna: This M2M Router device, ER2000T-NA-CAT1, integrates an LTE (4G) and WiFi radio function. Is uses an external antenna (dipole antenna) and a standard antenna connector (SMA type) which is not covered under FCC 15.203 requirements.
  • Page 34 Revision History: Date Rev No. Description 07-10-2017 V0.1 Initial draft 07-27-2017 V0.2 Numerous Updates 07-28-2017 V0.3 Nomenclature clean-up 07-28-2017 V0.4 Certification section clean-up 08-01-2017 V0.5 Certification section clean-up 08-02-2017 V0.6 Removed -VZ-CAT1 from the Manual 08-09-2017 V0.7 Added WiFi Antenna Gain 11-15-2017 V0.8 Added VZ-CAT1 back into Manual...
