ConnectedIO™ LTE Router
Quick Installation Guide
© 2018 Connected IO – All Rights Reserved Worldwide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ER2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for ConnectedIO ER2000

  • Page 1 ConnectedIO™ LTE Router Quick Installation Guide © 2018 Connected IO – All Rights Reserved Worldwide...
  • Page 2 FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 3: Table Of Contents

    If you discover an error in this document, please e-mail your comments or suggested corrections to docs@connectedio.com. Manual Revision 1 – P/N xxx-xxx...
  • Page 4: Overview

    2. Select a mounting location. 3. Attach the antenna. 4. Install the Power Adapter. 5. Attach any Ethernet cables to the ER2000 RUs and draw the slack cable to the associated Ethernet Equipment. 6. Install and activate the SIM card. 7. Test the link.
  • Page 5: Unpacking The Er2000 Units

    Unpacking the ER2000 units The ER2000 units come ready to use. To complete the installation, you will need a CAT-5 jumper cable to connect your network equipment and an activated SIM card from your Carrier. The following components are included in the ER2000 system: ER2000™...
  • Page 6: Ac Power Adapter

    The adapter plugs into the RU barrel-jack and provides 12 VDC @ 2A of power. We recommend that you use only the AC Power transformer supplied with the ER2000 unit, or contact Connected IO for a suitable replacement power adapter.
  • Page 7: Leds

    LEDs On the top panel of the RU are a set of 7 LEDs. • The first shows Amber if there is a WiFi connection. • The second shows yellow if the RU is powered on. • The next 5 LEDs are green and show the LTE Signal Strength. Ports The RU has the following port configuration: •...
  • Page 8: Planning The Installation

    It is important to verify that you do not exceed the distance capabilities of the ER2000. If you are unsure of the distance between the two points, you can use a measuring device such as range finders. You can also look at the architect’s site plan or contact a local surveying service for assistance.
  • Page 9: Power And Poe Adapters

    Power and PoE Adapters If the location of the BPU is not close to a Power Outlet, you can use an extension cord or a PoE adapter kit to extend your connection. Before selecting an electrical outlet for use in powering the PoE Adapter, verify that the electrical outlet is non-switched (not attached to a wall switch).
  • Page 10: Installing The Er2000

    Every Connected IO device needs a SIM card to operate in the LTE domain. It is possible to operate an ER2000 without a SIM card only when using it as an Ethernet-connected router. The ER2000 uses a Mini (2FF) size SIM card which is installed in a slot un the underside of the RU.
  • Page 11: Initial Ip Address Setup

    The final step is to ping a known address on one side of the bridge from a station on the other side using the Windows “Ping” utility. If the ping is done successfully, you have properly installed the ER2000. It should provide you with years of trouble-free service.
  • Page 12 Connected IO 8304 Esters Boulevard Suite 850 Irving, TX 75063 Main: +1 (972) 366-0070 Toll Free: (888) 366-1657 www.Connected IO.com ER-2000 Quick Installation Guide Page 9 © 2018 – Connected IO, Inc.
