Microsoft Surface Hub 2S Integration Manual page 5

Key Component
AC power
②
DC power
③
Ethernet
④
USB-A
⑤
USB-C
⑥
HDMI in
⑦
Mini
⑧
DisplayPort out
Surface Hub 2S A/V Integration Guide
Description
incorporated into the design to help support retention of
attached cameras.
NOTE: TouchBack and video ingest are not supported on
•
these ports.
100-240V input
Connect to standard AC power and Surface Hub 2S will
auto switch to the local power standard such as110 volts
in the US and Canada or 220 volts in the UK or other
countries.
NOTE: When the AC cord is plugged in, the system
remains in an off state in which only the system
management controller (SMC), real time clock (RTC), and
keypad are running.
24V DC input port
Use for connecting to mobile battery.
1000/100/10 BaseT
Use for providing a continuous connection in a corporate
environment and related scenarios requiring maximum
stability or capacity.
USB 3.0 Port
Use as a walk-up port for plugging in peripherals such as
thumb-drives.
USB 3.0 Port
Use as a walk-up port for connecting external PCs and
related devices or plugging in peripherals such as thumb-
drives.
NOTE: This is the recommended video input port,
supporting both TouchBack and InkBack.
HDMI 2.0, HDCP 2.2 /1.4
Use for multiple scenarios including HDMI-to-HDMI
guest input.
DisplayPort 1.2 output
Use for video-out scenarios such as mirroring the Surface
Hub 2S display to a larger projector.
Key
parameters
IEC 60320 C14
Xbox1 Dual
barrel to
Anderson
connector
RJ45
Type A
7.5 W Port
(5V/1.5A)
Type C
18 W Port
(5V/3A, 9V/2A)
Standard HDMI
Mini
DisplayPort
2
