ELECTRIC HI-LO BATHTUB
"ONYX" REF: 7440
DIRECTIONS FOR USE AND MAINTENANCE
Picture: Electric Hi-Lo Bathtub "Onyx" ref: 7440.00
with "air whirlpool" option ref: 7121.99
Reval Continuing Care Ltd
Unit 15 Brynmenyn Business Centre
St. Theodore's Way
Brynmenyn Industrial Estate
Bridgend
S Wales CF32 9TZ
Tel: 01656 721 001
Fax : 01656 720 006
sales@revalcc.com
It is essential to read these directions for use before using your bathtub.
A4AN7440UK.doc
Advertisement
Table of Contents
Related Manuals for Reval Onyx
Summary of Contents for Reval Onyx
- Page 1 ELECTRIC HI-LO BATHTUB "ONYX" REF: 7440 DIRECTIONS FOR USE AND MAINTENANCE Picture: Electric Hi-Lo Bathtub "Onyx" ref: 7440.00 with "air whirlpool" option ref: 7121.99 Reval Continuing Care Ltd Unit 15 Brynmenyn Business Centre St. Theodore’s Way Brynmenyn Industrial Estate Bridgend...
-
Page 2: Table Of Contents
- SUMMARY - CONTENTS PAGES GENERAL DRAWINGS / MEASUREMENTS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - OPERATION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - TECHNICAL SPECIFICATIONS... -
Page 3: General Drawings / Measurements
GENERAL DRAWINGS: Sense mixer (bath & shower) hi/lo sensitive control cleaning shower aromatherapy control (option) shower flow valve chromatherapy control (option) whirlpool control (option) filling spout draining adjustable jack foot 12 nozzles for whirlpool (option) handgrip doot to access to the plumbig components door to access to the electric components... -
Page 4: Operation
OPERATION: Hi/Lo of the bathtub "Onyx" is obtained thanks an electric jack and a gas jack, the first one is driven by an electric control. To activate bath fill place hand over the bath fill sensor within 30mm. Bath will fill automatically to the fill level and stop automatically when water level indicator is reached. -
Page 5: Directions For Use
TECHNICAL SPECIFICATIONS: CONFORMITY: 73/23/CEE (low voltege directive) • 89/336/CEE (EMC directive) • NF EN 60335-1 (electric standard for bathtub..) • NF EN 60335-2-60 (electric standard for bathtub...) • NF EN 1717 (Anti-pollution) • WRAS (n°0712094) • TMV2 • TMV3 • DO8 DIRECTIONS FOR USE: ADJUSTMENT OF THE WATER TEMPERATURE To adjust the water temperature,, pass your finger in front of the cold water sensitive captor (blue triangle) or in front of the... -
Page 6: Shower Head
THERMIC DESINFECTION The « rada sense » control box is equipped with a system of thermic disinfection for its pipes, which is controlled by a PDA. Only a recognised technician can do this operation, so please call REVAL CC. HYDROTHERAPY Heated compressed fresh air is passed into the tub via 12 diffusers witch are aimed at the major muscle groups around the body. -
Page 7: Chromotherapy (In Option)
This can also be set to manual adjustment for fine tuning the mood of the bathroom to suit the mood and requirements of the user. There are several lighting sequences that will create the perfect atmospheric sensation. This coupled with Reval's Hydro-Aromatherapy system deliver the ultimate in bathing comfort, relaxation and rehabilitation. -
Page 8: Hydro-Aromatherapy (In Option)
The auto-clean function significantly reduces the risk and development of micro -biological organisms that can develop in humid and wet environments. Reval's unique air ducting system can be dismantled without the need for tools and can be termically cleaned during routine servicing in a matter of minutes. -
Page 9: Cleaning / Maintenance
CLEANING / MAINTENANCE: CLEANING OF THE TUB AND CONTROL PANEL : Only use liquid products (liquid soap). Don't use abrasive products like "scouring cream" to avoid scratches on the tub surface "Gelcoat". Furthermore, to eliminate calcareous marks settled by water moving, we recommend to use the scaler (Gel Servex ). -
Page 10: Maintenance Form (Logbook)
MAINTENANCE FORM (LOGBOOK): Page 10/10 A4AN7440UK.doc...
