DualID II User Guide

Using key pad

1. Type pin code
2. Confirm with
3. Green light in LED3 indicates authorized ID
4. Begin operation.

Using RFID card

1. Present card in front of reader
2. A beep signal indicates correct reading of the
card
3. Green light in LED3 indicates authorized ID
4. Begin operation.
Info
• LED1 indicates that the unit is powered
• Cancel key input with
• Red LED3 indicates that the input is canceled
• Wait 10 seconds before commencing new pin input
• Don't use RFID card and pin code simultaneously
• LED2 is not in use
LED
Color
Yellow
1
Green
3
3
Red
and start again
Meaning
Power on
Approved ID
Canceled ID
trackunit.com/support
1
2
3
LED
Keypad and RFID card
reader
support@trackunit.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DualID II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Trackunit DualID II

  • Page 1 DualID II User Guide Using key pad 1. Type pin code 2. Confirm with 3. Green light in LED3 indicates authorized ID 4. Begin operation. Using RFID card 1. Present card in front of reader 2. A beep signal indicates correct reading of the card 3.
  • Page 2 DualID II Installation Guide 11mm When mounting DualID II, The cable can be installed Drill a hole in the back use screws compatible with in two different ways. It can panel and pull the cable the surface on which it will either go downwards or out through it.
