Trackunit DualID II User Manual

User guide
Trackunit DualID II

Using key pad:

1. Type pin code
2. Confirm with
3. Green light in LED3 indicates authorized ID
Begin operation.

Using RFID card:

1. Present card in front of reader
2. A beep signal indicates card is read ok
3. Green light in LED3 indicates authorized ID
Begin operation.
Info:

Yellow light in LED1 indicates the unit has power

Cancel key input with

Red flash in LED3 when input is cancelled

There is a 10 sec. time out for pin input

Don't use RFID card and pin simultaneously

LED2 is not in use
Installation check using "Verify my Trackunit"
Action
Go to : http://verify.trackunit.com/
Login with designated
username and password
Enter serial number of the unit being installed.
©Trackunit 2017
(start again)
LED 2
LED 1

LED indications

LED 1
Yellow Power
Green
-
Red -
Screen
LED 3
Keypad and
RFID card
reader
Accessories:
protective
bracket
LED 2 LED 3
- -
- ID ok
- ID cancel
7006.1201 v2.0 01.05.2017
