Technical information

Housing:
Dimensions:
Weight:
Power supply:
Battery:
Power consumption:
ON:
+RFID
+RFID + Bluetooth
RFID output power:
LF / 125 / 134 kHz
HF 13,56 MHz
UHF 868 MHz
UHF 916 MHz
Interfaces
Operation modes:
Bluetooth
USB
Display:
Number of Keys:
Operating
temperature:
Certifications:
Memory:
Supported
Transponder:
LF
HF ISO 15693
HF ISO 14443/NFC
UHF
Supported operating
systems:
MultiPen User Manual V.1.2
Plastic IP 64
190 x 35 x 30 mm
125 g
USB 5 V DC
NIHM 2200 mAh
1 mA (Automatic Power OFF)
Max. 300 mA (400 msec)
Max. 380 mA (400 msec)
200 mW
220 mW
20 dBm
20 dBm
BLUETOOTH™ 2.1
USB CDC (Communication device class)
USB HID (Human interface device)
SPP or HID
CDC or HID
OLED 4 Rows
3 (ON/OFF, BLUETOOTH™ ON, READ TAG)
-20°C...+65°C
CE
1000 UID's with time stamp
ISO 11784/785, UNIQUE, HITAG 1/S, FDX-B,
HDX
ISO 15693
ISO 14443/NFC
ISO 18000-6 EPC Class I Gen 2
WINDOWS™ 7/8/10, WINDOWS™ Mobile,
ANDROID ™, IOS (HID BT)
©TECTUS
Push Read Button (1x)
Push Read Button (1x)
*Read distance :
Up to 20 mm
Up to 25 mm
Up to 80 mm
Up to 80 mm
*Depending on Tag type, Tag
size
and mounting situation
ATEX, IECEx
HITAG S read and write
Read and write
Read and write
Read EPC
