- Page 1 LED strip manual liniLED® PCB Photon 20 mm ADAM V DC IP00 RoHS BEND RADIUS S D C M...
-
Page 3: Table Of Contents
LED strip PCB Photon General Handling Installation Operation and use Cleaning and maintenance Environment and waste Warning Area advice Product dimensions Product information Product specifications Cable selection Product care and handling Cutting instructions Soldering Connect IP00 Power supply Symbols... -
Page 4: General
- Products are transported in proper packaging. Products should remain packed until installation. - Take ESD (Electrostatic Discharge) protection measures when handling liniLED® products. - The products and their components may not be exposed to mechanical, static loads and other tension/compression other than from the product itself. -
Page 5: Warning
Area advice Depending on the area where the liniLED® LED strip is installed we offer a range of solutions to cope with external factors. The product portfolio for the liniLED® PCB LED strip only includes a range of IP00 connectors. -
Page 6: Product Information
Product information The liniLED® LED strip PCB Photon (IP00) is a high quality, flexible LED strip with an outstanding efficiency. Thanks to the small dimensions, the PCB LED strip is ideal to use in small spaces (indoor use only!). With 3M double sided tape on the back, the PCB LED strip is easy to mount. The liniLED®... -
Page 7: Cable Selection
The liniLED® LED strips need a minimum voltage at the beginning of the LED strip to function according to the specifi cations. The table below gives an indication of the maximum cable length based on the cable thickness and power supply voltage. The connection between the cable and LED strip is with a liniLED®... - Page 8 The liniLED® LED strips need a minimum voltage at the beginning of the LED strip to function according to the specifi cations. The table below gives an indication of the maximum cable length based on the cable thickness and power supply voltage. The connection between the cable and LED strip is with a liniLED®...
-
Page 9: Product Care And Handling
Do not bend the LED strip sidewards. The LED strip has to be unreeled on a horizontal surface at the time of installation. Do not unreel the spool of LED strip before installation. LED strip manual | liniLED® PCB Photon... -
Page 10: Cutting Instructions
Top view | Make sure the cut is vertical as illustraded in the image Top view | Only cut on the dotted lines to prevent damaging the LED above. strip. Dispose of the unnecessary material through waste recycling of electrical and electronic equipment. LED strip manual | liniLED® PCB Photon... -
Page 11: Soldering
Solder the wires to the PCB. We advise to use a cable with an area not 350o C bigger then 0.5 mm2. Pre-solder the wires. 350o C Solder the wires to the connector pads. 350o C LED strip manual | liniLED® PCB Photon... -
Page 12: Connect Ip00
In order to maintain adequate electrical contact, the connectors are designed for single use. Remove is possible but will result in the destruction of the connector. Use a flat screwdriver to open the connector. LED strip manual | liniLED® PCB Photon... -
Page 13: Power Supply
Cable X liniLED® Cable 1 m Control Connect the LED strip as indicated in the figure above. The wires should be connected as follows: Red (+) and Black (-). Insert the power plug. LED strip manual | liniLED® PCB Photon... -
Page 14: Symbols
(≤ 60.0 V DC or ≤ 42.4 V AC). The CRI value of this product is 80 or higher. The binning tolerance of this product is 2 MacAdam. ADAM S D C M LED strip manual | liniLED® PCB Photon... - Page 16 Triolight B.V. Subject to misprints, errors and modifications. No legal rights can be derived from this document. V0319...
