40cm Petrol Scarifier &
Aerator
WELS40P
1938204001
en - Original Instructions
Sales & Support: 01793 333212
Before use please read & understand this manual; paying particular attention to the safety instructions.
The manufacturer reserves the right to change the product specifi cation and livery according to continues product improvements.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WELS40P and is the answer not in the manual?

Questions and answers

Related Manuals for Webb WELS40P

Summary of Contents for Webb WELS40P

  • Page 1 40cm Petrol Scarifier & Aerator WELS40P 1938204001 en - Original Instructions Sales & Support: 01793 333212 Before use please read & understand this manual; paying particular attention to the safety instructions. The manufacturer reserves the right to change the product specifi cation and livery according to continues product improvements.
  • Page 2 Instruction Manual 01 Mar 2019 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
  • Page 3 CONTENTS INTENDED USE SAFETY INSTRUCTIONS SPECIFICATIONS KNOW YOUR MACHINE ASSEMBLY OPERATION MAINTENANCE, CLEANING & STORAGE TROUBLE SHOOTING PARTS DIAGRAM & LIST DECLARATION OF CONFORMITY WARRANTY INTENDED USE The basic version of the equipment is a scarifier intended for private use, i.e. for use in home and gardening environments.
  • Page 4 Instruction Manual SAFETY INSTRUCTIONS Read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. Read &...
  • Page 5 Approved Webb Service Dealer. have been given supervision or instruction 15. Switch the engine off: concerning use of the machine by a person −...
  • Page 6 If damaged, have parts. the machine repaired by an Approved Webb 9. Prolonged use of the machine may lead to Service Dealer immediately. Many accidents disorders of blood circulation in hands caused are caused by poorly maintained machines.
  • Page 7 12. Use the machine, accessories and tool bits etc., in accordance with these instructions and in the manner intended for the particular type of petrol machine, taking into account the working conditions and the work to be performed. Use of the machine for operations different from intended could result in a hazardous situation.
  • Page 8 Instruction Manual SPECIFICATIONS Model WELS40P Product Number 1938204001 Engine Webb H210 Rated Engine Power 212cc / 4.0kW / 3400rpm Full Tank Volume 3.6L Oil Volume 0.6L Deck Material Steel Working Width 400mm Working Depth -15mm to 5mm Dethatcher Blades - Aerator Springs...
  • Page 9 KNOW YOUR MACHINE 1. Upper Handle 2. Transport Lever 3. Recoil Starter Handle 4. Collector 5. Wheel 6. Height Adjustment Knob 7. Handle Locking Knob 8. OPC/Brake Lever The lawn scarifier is pushed by hand over the area of grass to be cut. The cutters are driven by a petrol engine. The depth of cut is set by varying the central height-adjustment mechanism individually.
  • Page 10 Instruction Manual ASSEMBLY Remove the machine and contents from the carton. Be sure the carton is empty before discarding. If you require any assistance with regards to the contents of the machine, contact us: Tel: 01793 333212 - Mon – Fri 8.00am – 5.30pm (excl. Bank Holidays) Email: customerservice@webbgardenpower.co.uk HANDLE ASSEMBLY •...
  • Page 11 • Connect the lower and upper handle-bars with bolts, washers and locking knobs. (Fig.2D/Fig.2E/Fig.2F) Fig 2D Fig 2E Fig 2F...
  • Page 12 Instruction Manual • Attach the cable-clamps to the position shown and secure the cable. (Fig.2G) Fig 2G ADJUSTMENT FOR AN APPROPRIATE ANGLE • Screw out the locking knobs which fixed the lower handle. (Fig.3A) Fig 3A • Move the lower handle up or down, adjust it to the appropriate height. There are 2 adjusting heights to choose from.
  • Page 13 FITTING & REMOVING THE COLLECTOR WARNING Before you hook the grass catcher to the scarifier, you must ensure that the engine has stopped, and the cutting unit is not rotating. To fit: Raise the rear cover and hitch the collector on to the rear of mower, using the hooks of the collector and lugs on the machine.
  • Page 14 Instruction Manual RECOIL STARTER ROPE Move the starter handle from the engine to the rope guide. Sit the handle into the guide (Fig.5) Fig 5 DEPTH OF CUT Move height adjuster lever forward or back to adjust height. See “Height Adjuster” section of Operation section of this manual (Fig.
  • Page 15 OPERATION FUEL & OIL WARNING YOUR MACHINE IS SUPPLIED WITHOUT ENGINE OIL OR PETROL Operating the engine with insufficient oil within your fuel mixture, can have catastrophic consequences. Any failure caused by insufficient oil, will not be covered by the manufacturer’s warranty. See separate engine manual supplied with your scarifier.
  • Page 16 Instruction Manual ENGINE STARTING & STOPPING PROCEDURE STARTING A COLD ENGINE 1. Place the machine onto a flat, firm surface. 2. Turn the Engine Switch to the “ON” position. Engine Switch “ON” Fig 7A 3. To start a cold engine, move the Carburetor Lever to the “ON” position (Fig. 7B). Move the Choke Lever to the “OFF”...
  • Page 17 4. Standing behind the machine, pull the OPC/Brake Lever towards the upper handle with your left hand. (Fig 7C). Fig 7C 5. Keep hold of the OPC/Brake lever (Fig 7C) and grasp the starter handle (Fig 7D) and pull up rapidly. Return it slowly to the rope guide bolt after engine starts.
  • Page 18 Instruction Manual STARTING A WARM ENGINE 1. If the engine is still warm, leave the Choke Lever in the “ON” position (Fig 7E). 2. Keep hold of the OPC/Brake lever (Fig 7C) and grasp the starter handle (Fig 7D) and pull up rapidly. Return it slowly to the rope guide bolt after engine starts.
  • Page 19 GRASS COLLECTOR WORK WITHOUT THE COLLECTOR (OPTIONAL) You can work with or without the collector. Whenever you detach the collector, the rear deflector flap will drop down. When operating without the collector attached, the cuttings are ejected straight onto the ground. (Fig 9A) Fig 9A WORK WITH THE COLLECTOR...
  • Page 20 Instruction Manual HEIGHT ADJUSTMENTS CAUTION Do not at any time make any adjustment to scarifier without first stopping the engine. Your scarifier is equipped with a depth adjustment lever. The working positions are from 5mm to -15mm height. 1. Stop machine and disconnect spark plug cable before changing mower cutting height. 2.
  • Page 21 Use only original scarifier/aerator shafts approved by the manufacturer. The equipment can be assembled with the Dethatching (blades) or Scarifying (Spring Tines) cylinders. Only replace the cylinder with an original Webb product, to ensure top performance & safety. To change the cylinder, proceed as follows.
  • Page 22 Instruction Manual FIT CYLINDER Slide the new roller in the direction of the arrow, insert the shaft into the hexagonal socket and press the other side into the holder (Fig.11C/ Fig.11D/ Fig.11E). Fig 11C Fig 11D Fig 11E 1. Refasten the roller with the fixing plate and four screws (Fig 11B). 2.
  • Page 23 WARNING Do not cut where you cannot see what the cutting tool is cutting. DO NOT use the put the metal blade into contact with Utility Wires, Metal Stakes, Rubber, Masonry, Rocks, Fences, and Trees. DANGER DO NOT cut with a dull, cracked or damaged cylinder. Before using, inspect for obstructions. If an obstruction cannot be removed, mark its location clearly so you can avoid it during operation.
  • Page 24 Instruction Manual Air Filter Cover Fig 12A Fig 12B Air Filter NOTE Replace filter if frayed, torn, damaged or unable to be cleaned ENGINE Refer to the separate engine manual for engine maintenance instructions. Clean the engine regularly with a cloth or brush. Keep the cooling system (blower housing area) clean to permit proper air circulation which is essential to engine performance and life.
  • Page 25 NOTE: When storing any type of power equipment in an unventilated or material storage shed, − Care should be taken to rust-proof the equipment. Using a light oil or silicone, coat the equipment, especially cables and all moving parts. − Be careful not to bend or kink cables. −...
  • Page 26 PARTS DIAGRAM & LIST - WELS40P 1938204001...
  • Page 32 EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Petrol 40cm Lawn Scarifier & Aerator Model(s): WELS40P Product No.: 1938204001 Type/Serial No. As per rating label on machine Engine Displacement: 212cm Rated Engine Power: 4.0kW / 3400rpm...
  • Page 33 Notes...
  • Page 34 Instruction Manual This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you to take advantage of the conditional manufacturer domestic warranty*. Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
  • Page 35 Webb (excludes Electric Handheld) & Webb Pro, 2 year conditional warranty from the original date of sale to the fi rst domestic user. Webb Electric Handheld & Dynamic, Legacy & Heritage 1 year warranty from the original date of sale to the fi rst domestic user.
  • Page 36 It is the owner’s responsibility to ensure that their Webb machine is maintained at specifi c intervals. Any approved Webb service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time &...
  • Page 37 SERVICE BOOK Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have been completed. PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK. 1st Service This must be stamped by an approved service dealer to qualify for a free second year warranty.

  • Page 38: Service Record

    Service Record Instruction Manual 48 Months 60 Months Date Date 72 Months 84 Months Date Date 96 Months 108 Months Date Date 120 Months 132 Months Date Date...
  • Page 39 Email From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, off ers or just opinions, which may be used for marketing, research or analysis purposes.
  • Page 40 Webb Lawnmowers Murdock Road Dorcan Swindon Wiltshire SN3 5HY...
  • Page 41 EN - ORIGINAL INSTRUCTIONS 4-STROKE PETROL ENGINE MODEL: WEH210 OWNERS MANUAL SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 FOR YOUR SAFETY Please read & understand this manual, paying attention to the safety instructions, before use. Incorrect use of the product could put the operator or machine in danger. Whilst every effort has been made to ensure the accuracy of information contained in this manual, our policy of continuous improvement determines the right to make modifications without prior warning.
  • Page 42 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
  • Page 43 Indicates that equipment or property damage can NOTICE result if instructions are not followed. Gives helpful information. If a problem should arise, or if NOTE you have any questions about your engine, consult an Approved Webb Service Dealer. SPECIFICATIONS Model WEH210 Product Number 1938205201...

  • Page 44: Table Of Contents

    CONTENTS 1. ENGINE SAFETY 5. SERVICING YOUR ENGINE • • Important Safety Information The Importance of Maintenance • • Owner Responsibilities Maintenance Safety • • Refuel with Care Safety Precautions • • Hot Exhaust Maintenance Schedule • • Carbon Monoxide Refueling •...

  • Page 45: Engine Safety

    ENGINE SAFETY IMPORTANT SAFETY INFORMATION Most accidents with engines can be prevented if you follow all instructions in this manual and on the engine. Some of the most common hazards are discussed below, along with the best way to protect yourself and others.

  • Page 46: Engine Switch

    FUEL VALVE LEVER The fuel valve opens and closes the passage between fuel tank and carburetor. The fuel valve lever must on in the “ON” position for the engine to run. When the engine is not in use, leave the fuel valve lever in the “OFF” position to prevent carburetor flooding and to reduce the possibility of a fuel leak.

  • Page 47: Before Operation

    For your safety, and to maximize the service life of your equipment, it is important to take a few moments before you operate the engine to check its condition. Be sure to take care of any problem you find or have your local Approved Webb Service Dealer correct it, before you operate the engine. WARNING Incorrect maintenance of this engine, or failing to correct a problem before operation, could cause a malfunction in which you could be seriously injured.

  • Page 48: Operation

    OPERATION SAFE OPERATING PRECAUTIONS Before operating the engine for the first time, please review the IMPORTANT SAFETY INFORMATION and the section titled BEFORE OPERATION. WARNING Carbon monoxide gas is toxic. Breathing it can cause unconsciousness and even kill you. Avoid any areas or actions that expose you to carbon monoxide.
  • Page 49 3. Move the throttle lever away from the “SLOW” position, about 1/3 of the way toward the “FAST” position. (Some engine applications use a remotely mounted throttle control rather than the engine mounted throttle lever shown). SLOW HIGH THROTTLE LEVER 4.

  • Page 50: Stopping The Engine

    6. If the choke lever has been moved to the “CLOSED” position to start the engine, gradually move it to the “OPEN” position as the engine warms up. CHOKE LEVER OPEN STOPPING THE ENGINE To stop the engine in an emergency, simply turn the engine switch to the “OFF” position. Under normal conditions, use the following procedure.

  • Page 51: Setting Engine Speed

    The maintenance schedule applies to normal operating conditions. If you operate your engine under unusual conditions, such as sustained high load or high temperature operation, or use in unusually wet or dusty conditions, consult your local Approved Webb Service Dealer for recommendations applicable to your individual needs and use.

  • Page 52: Maintenance Safety

    Every 2 years (Replace if necessary) (2) 1. Service more frequently when used in dusty areas. 2. These items should be serviced by your Approved Webb Service Dealer 3. For commercial use, log hours of operation to determine proper maintenance intervals.

  • Page 53: Refueling

    This should not cause any concern for the operator. If this occurs at a steady engine speed, under normal load, change your brand of petrol. If it persists after taking this action, have the machine inspected by your Approved Webb Service Dealer. NOTE Running the engine with persistent spark knock or pinging can cause engine damage.

  • Page 54: Engine Oil Level Check

    ENGINE OIL LEVEL CHECK Check the engine oil level with the engine stopped and on a level surface. 1. Remove the filler cap/dipstick and wipe it clean. 2. Insert and remove the filler cap/dipstick without screwing it into the filler neck. Check the oil level shown on the filler cap/dipstick.

  • Page 55: Servicing Your Engine

    SERVICE YOUR ENGINE Oil is a major factor affecting performance and service life. Use 4-stroke SAE-30 or 10W-30 lawnmower engine oil. We recommend Handy Parts Oil (HP-140 or HP-195). We recommend that you use API Service Category SJ/SL oil. AIR FILTER INSPECTION Remove the air cleaner cover and inspect the filter.

  • Page 56: Idle Speed Adjustment

    7. Attach the spark plug cap/wire. IDLE SPEED ADJUSTMENT (Recommended action for Approved Webb Service Dealer) Standard Idle Speed: 1600+160rpm 1. Start the engine outdoors and allow it to warm up to operating temperature.

  • Page 57: Engine Oil

    FUEL STABILIZER To keep fuel fresh, we recommend you use SURE-START FUEL ADDITIVE (HP-199) from Handy Parts. A fuel additive added to your fuel at the time of mixture, will help make your machine easier to start, extend the shelf life of your fuel mixture for up to two years, keeps the carburettor & engine clean, plus reduces emissions and increases fuel economy.

  • Page 58: Transporting

    Fast position. Fuel filter clogged, carburetor Replace or repair faulty Take engine to an Approved malfunction, ignition components as necessary, with Webb Service Dealer malfunction. Valves stuck etc. approved genuine parts. ENGINE LACKS POWER POSSIBLE CAUSE CORRECTION Check air filter...

  • Page 59: Technical Information

    High altitude performance can be improved by specific modifications to the carburetor. If you always operate your engine at altitudes above 5,000 feet (1500 metres), have your Approved Webb Service Dealer perform a carburetor modification. This engine, when operated at high altitude with the carburetor modifications for high altitude use, will meet each emission standard throughout its useful life.
  • Page 60 All machines’ must be serviced within the first 12 months from the original date of purchase to comply with the warranty, failure to do so will invalidate the 2nd year of the warranty. WEBB ELECTRIC HANDHELD, WEBB DYNAMIC, HERITAGE & LEGACY, HANDY, MOWERLAND, Q-GARDEN 1 year from the original date of sale to the first domestic user.
  • Page 61 NOT COVERED BY THIS WARRANTY a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident. b) The warranty policy does not cover any costs necessary for the standard periodic maintenance services instructed by the operator’s manual, or service parts replacement which would include oil, filters, tyres, belts, brake linings, fuses, blades, seals and other service parts unless it can be proven that the item has evidence of faulty manufacture.

  • Page 62: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Petrol Engine Model(s): WEH210 Product No.: 1938205001 Type/Serial No. As per rating label on machine Engine Displacement: 212cm Rated Engine Power: 3.6kW / 3600rpm Complies with the following directives: Machinery Directive 2006/42/EC The conformity assessment procedure followed was in accordance with...

  • Page 64: Tel: 01793 333212

    For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: customerservice@webbgardenpower.co.uk (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) Power in your garden… www.webbgardenpower.co.uk Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...

Table of Contents
