- Page 1 Marvel BMS communications Installation, Operation and Maintenance Manual Effective April 2019 ***Interactive PDF***...
-
Page 2: Table Of Contents
Installation, Operation and Maintenance Manual Marvel BMS Contents General Purpose �����������������������������������������������������������������������������������������������������������3 Components ������������������������������������������������������������������������������������������������������������������4 Architectural Layout �������������������������������������������������������������������������������������������������������5 General Serial Card Installation�������������������������������������������������������������������������������������6 Initial installation� �����������������������������������������������������������������������������������������������������6 Connection Setup from Marvel to Serial Card ���������������������������������������������������������6 Network Connection Settings and Access ���������������������������������������������������������������6 Accessing Bacnet network settings� ������������������������������������������������������������������������6 PCONET adjustable parameters for Bacnet protocol�... -
Page 3: General Purpose
Installation, Operation and Maintenance Manual Marvel BMS General Purpose The Marvel BMS communications availability is designed to on off, Alarm monitoring, status monitoring, conditions give a general control and monitoring ability to any of the monitoring, and set points access�... -
Page 4: Components
Installation, Operation and Maintenance Manual Marvel BMS Components There are several different types of communication cards available to communicate via BMS� LonWorks (FIG1) Bacnet mstp (FIG2) Bacnet/Modbus IP (FIG3) Modbus mstp (FIG4) Fig 1 Fig 2 Fig 3 Fig 4 Subject to change without notice. -
Page 5: Architectural Layout
Installation, Operation and Maintenance Manual Marvel BMS Architectural Layout Subject to change without notice. 120.5-IM (0419) -
Page 6: General Serial Card Installation
Installation, Operation and Maintenance Manual Marvel BMS General Serial Card Installation Initial installation. It’s important to know what type of communications will be required at the building and or what the Marvel will be required to connect to� It’s important to understand the architecture first before installing a serial card or attempting to connect via your BMS communications�... -
Page 7: Pconet Adjustable Parameters For Bacnet Protocol. Bacnet Ms/Tp Setup
Installation, Operation and Maintenance Manual Marvel BMS the information in the rare case of saving trouble repeat the steps above it will eventually save your settings� PCONET adjustable parameters for Bacnet protocol. Bacnet MS/TP setup. You can setup various aspects of the Bacnet protocol for your network in this page�... -
Page 8: Points List's Referencing
Installation, Operation and Maintenance Manual Marvel BMS Points list’s referencing UCA will provide points list’s for the different programs on values� If there is only an R you can only read the values� the website� www�unitedcoolair�com/ the points lists are laid The description lists a description of what the variable is out in a table�... -
Page 9: Troubleshooting
Installation, Operation and Maintenance Manual Marvel BMS Troubleshooting It is very important to eliminate possibility of field errors before adjusting the controller. No field wiring, network, or BMS server programming are addressed here. Issue Possible cause Remedy Failure to communicate to the board... -
Page 10: Limited Warranty
Engineered to Order LIMITED WARRANTY Authorized Distributor: United CoolAir Units are backed by a 1 year limited warranty on parts and a 5 year limited warranty on the compressor (labor not included). Maintenance items such as filters and belts are excluded under this limited warranty�...
