- Page 1 Document Revision 1.03 Part Number: 930-0052-00 Kontron M2M Smart Services Developer Kit Wind River Linux LiveUSB Getting Started Guide with Eurotech ESF™...
-
Page 2: Table Of Contents
LiveUSB Technology ..........................2 Connecting the Hardware ..............4 Connecting the Kontron M2M System M2M and Your Host Computer ..............4 Ports and Antennas ........................... 6 Powering the Kontron M2M System ......................7 ... - Page 3 Troubleshooting Your Evaluation Setup ..........20 Network Topology Overview ........................20 For retrieving the evaluation license: ....................20 For running the evaluation: ........................ 20 Troubleshooting Graphics Problems on Your LiveUSB Host Computer ..23 www.kontron.com www.kontron.com...
-
Page 4: Introduction
Kontron does not accept any liability for any printing errors or other inaccuracies in the manual unless it can be proven that Kontron is aware of such errors or inaccuracies or that Kontron is unaware of these as a result of gross negligence and Kontron has failed to eliminate these errors or inaccuracies for this reason. -
Page 5: Required Hardware
Intel® Atom™ based Reference Platform for M2M Specification The Kontron M2M System is built on a COM Express module, which integrates with a carrier board to provide a System controller. The Kontron M2M System is a high-performance, low-power module based on the Intel® Atom™ processor. It uses ®... - Page 6 5. Wind River documentation for Wind River Workbench and Wind River Linux. 6. Eurotech’s ESF Hello World Tutorial and Denali User Guide. The pre-configured LiveUSB environment lets you use Wind River development tools without the need to install, configure, or build anything prior to the evaluation.
-
Page 7: Connecting The Hardware
Connect an Ethernet cable between the Ethernet port on the Kontron M2M system and a network switch or hub. Also connect your host computer to the same switch or hub. Optionally connect the Kontron M2M System to a USB keyboard, a USB mouse, and a display if the GUI Demo is to be exercised. - Page 8 Workbench and demo setup for using LiveUSB Drive Needed for GUI Demo/Tutorials WAN/Internet DVI/HDMI Monitor DVI/HDMI Monitor Router Kontron System LiveUSB USB Hub Flash Drive Keyboard and mouse Keyboard and mouse Included in the box...
-
Page 9: Ports And Antennas
BIOS settings (and the configuration of the S3 switch inside the Kontron/Intel® Atom™ based Reference Platform). These ports have static configurations and can provide 5Vdc power. DO NOT PLUG USB OTG (On-The-Go) DEVICES INTO THESE MICROUSB PORTS. -
Page 10: Powering The Kontron M2M System
You should ensure that your Kontron M2M System is correctly connected and is capable of booting. To do this plug the power adapter into the AC wall socket – there is no on/off switch. The board should begin booting within a few seconds. The Kontron M2M System is preprogrammed with Wind River Linux, which is specifically configured for development purposes. -
Page 11: Starting The Evaluation Software
Starting the Evaluation Software Booting the Host Computer Before booting your host computer, ensure that the LiveUSB flash drive is correctly plugged into a USB port on the host computer. Switch on your host computer. You may have to interrupt the boot process in order to instruct the BIOS to boot from the LiveUSB flash drive instead of the internal hard drive. - Page 12 License Acti ivation on an In nternet connecte ed host If the host o on which you wi ll be running yo our evaluation is s connected to th he Internet then n this method p rovides the easi iest and quickes st way of obtaini ing an evaluatio...
- Page 13 Once completed press the Save Changes button and then press the Next button (from the previous screen shot). Fill in your registration details (including a valid email address) and click the Submit button at the bottom of the form. You will be notified when host successfully obtains an Evaluation license. You can then begin using the Wind River host tools.
-
Page 14: Starting Your Software Evaluation
Starting Your Software Evaluation After the host computer boots into the Fedora LiveUSB environment, you will see a desktop that includes a number of icons, including a link to this document and quick launches to the tools. Check online for the latest versions of documentation. For your convenience, there are several pull down menus under Applications->Wind River. -
Page 15: Getting Started With Esf
This approach permits simpler and faster programming, with shorter, easier to read code and transparent portability across different hardware platforms. ESF can be installed into Wind River Workbench and the Kontron M2M Smart Service Developer Kit filesystem by following the instructions at http://esf.eurotech.com/doc/FRI/ESF_Install.html. -
Page 16: Everyware™ Device Cloud (Edc)
Everyware™ Device Cloud (EDC) The Everyware™ Device Cloud is a complete, scalable infrastructure that, working together with ESF, enables the Kontron M2M System to send and receive data to the EDC cloud where end applications or pre-made user designed components consume it. -
Page 17: Recovering Your Linux Image On The Kontron M2M System
Recovering Your Linux Image on the Kontron M2M System Your Kontron M2M System comes factory-installed with Wind River Linux and a Tilcon Graphics Suite demonstration. When you reset the target system, you should see the demonstration screen if the optional display is connected. -
Page 18: Making The Evaluation Image Recovery Tool Usb Drive
Making the Evaluation Image Recovery Tool USB Drive Before you make a bootable recovery USB image, you must have booted the host computer from the evaluation LiveUSB drive (or from a development workstation that has had the LiveUSB contents installed on its hard drive). Then: Insert a second USB flash drive that is 2 GB or larger into your host computer (Note: This is not supplied as part of the kit). -
Page 19: Recovering Your Kontron M2M System Software Evaluation System
Disconnect the power adapter from AC power again to turn off your system. Disconnect the evaluation image recovery tool USB drive. Reconnect the power adapter to AC power to turn on your system. The Kontron M2M System target now boots into the Tilcon Graphics Suite demonstration. -
Page 20: Manual License Activation
Manual L License A Activatio Manual Lice ense Activ vation on a a non-Inter rnet conne ected host If the host o on which you wi ll be running yo our evaluation is s not connected to the Internet (for example, it t is in a secure network env vironment) then... - Page 21 Fill in your registration details in the form (including a valid email address). Click the URL to read the Wind River Privacy Statement. Once you have read and understood the Wind River Privacy Statement, select the tick box to acknowledge your agreement. Click the Submit button at the bottom of the form.
-
Page 22: Automatic License Activation On A Windows Host
license@ @windriver.com he user_registra ation.txt file sho ould be emailed d, as an attachm ment, to ind River servi ice representativ ve from the Wi ind River licen nsing departmen nt will then help p you ith further instru uctions. Automatic License Ac ctivation o... -
Page 23: Troubleshooting Your Evaluation Setup
Troubleshooting Your Evaluation Setup Network Topology Overview For retrieving the evaluation license: To retrieve the evaluation license automatically, the LiveUSB host computer must have access to the Internet. The host computer will attempt to retrieve an IP address on its first wired interface dynamically via DHCP. Although wireless connections may be available on the LiveUSB host computer, they are disabled in the default configuration. - Page 24 Troubleshooting Your License Activation Configure your system as shown in section 2.1. From the main Fedora menu, select Applications > Wind River > IP Address > Switch to DHCP. From the main Fedora menu start the EDK agent, select Applications > Wind River > Embedded Development Kit Agent.
- Page 25 Perform the steps in section 3.3 to complete your license activation. If this procedure does not work, contact Wind River licensing at the appropriate location. North America, South America, Asia/Pacific: Phone: 800-872-4977 (800-USA-4WRS) Email: license@windriver.com Japan: Phone: 81-3-5778-6001 Email: license-jp@windriver.com Europe, Middle East, Africa: Phone: +(00)(800) 4977-4977 Email:...
-
Page 26: Troubleshooting Graphics Problems On Your Liveusb Host Computer
Troubleshooting Graphics Problems on Your LiveUSB Host Computer The LiveUSB was validated with many different host computers, but some computers may have a graphics controller that is incompatible with the default boot settings of the LiveUSB. If you see distorted graphics (or no graphics at all), your host computer has an incompatible graphics controller. - Page 27 85386 Eching/Munich Road Germany Tel.: +1 888 294 4558 Beijing 100070, P.R.China Tel.: +49 (0)8165/ 77 777 Fax: +1 858 677 0898 Tel.: + 86 10 63751188 Fax: +49 (0)8165/ 77 219 info@us.kontron.com Fax: + 86 10 83682438 info@kontron.com info@kontron.cn...
