Tyco R/C Mini Xtreme Cycle Manual

Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Keep these instructions for future reference: they contain important information.
GET STARTED!
Your vehicle has an amazing Gyro Stabilizer that makes it easy to
drive – and lets it perform amazing stunts! The stabilizer safely
spins at high speed inside the rear wheel, and it works like a
gyroscope to help keep your vehicle upright.
1. GET SET!
Energize the gyro stabilizer! Hold the vehicle off the ground and
push the left control stick all the way forward. Once the stabiliz-
er spins up to full speed, you'll be able to hear it – and if you
twist the vehicle from side to side you'll really feel it working!
Be sure to hold the vehicle by the driver figure, keeping
your fingers clear of the wheels.
2. LAUNCH IT!
Now gently hand-launch your vehicle. Set it on the ground and
give it a gentle push while pushing the left stick forward. Now
you're ready for the coolest stunt driving!
I. CONTENTS
VEHICLE
(1) Mini XTREME CYCLE™ Vehicle
may become hot and cause burns i f
el e ctroni c s get wet. Do not operate
vehi c l e through water or snow.
TRANSMITTER
NOTE: Your transmitter is
equipped with a special
automatic ON battery-sav-
ing feature. Just turn your
vehicle ON. Then push
either transmitter stick
and you will be able to run
and control your vehicle.
CAUTION:
Surfaces
92875-0920
Left Stick
Controls
Forward
Whip
& Braking
Antenna
(1) Transmitter
Right
Stick
Controls
Turning

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini Xtreme Cycle and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tyco R/C Mini Xtreme Cycle

Summary of Contents for Tyco R/C Mini Xtreme Cycle

  • Page 1 Antenna automatic ON battery-sav- ing feature. Just turn your vehicle ON. Then push Right either transmitter stick Stick and you will be able to run Controls and control your vehicle. Turning (1) Transmitter (1) Mini XTREME CYCLE™ Vehicle...

  • Page 2: Quick Start

    FEATURES Full function Available in 2 frequencies: 27 MHz and 49 MHz (refer to labels on transmitter & vehicle for frequency) Range up to 30'/9m TOP VIEW BOTTOM VIEW ON/OFF Switch Battery Latch Powerful Mabuchi Motor Gyro Stabilizer Battery (inside rear wheel) Compartment Refer to label on transmitter and vehicle for frequency.

  • Page 3: Operating Your Vehicle

    III. OPERATING YOUR VEHICLE FORWARD BRAKING LEFT TURN RIGHT TURN cles running on the same Don’t drive your vehicle in IV. QUICK TIPS frequency; electrical wires; sand or through water or When your vehicle starts to snow. If your vehicle does large buildings;...

  • Page 4: Driving Tips

    bilizer a little while to come up 3. When you want to stop, it’s V. DRIVING TIPS to full speed. And you’ll get best to turn into a skid while 1. You can also start with your different results on different braking, instead of hitting the vehicle resting on its side skid driving surfaces.
  • Page 5 3. JAMMIN’ JUMPS! Push the left stick all the way forward to accelerate. Drive your vehicle off a ramp or curb and watch it catch some “big air.” For the smoothest jumps, keep the stick pushed forward during the jump. Depending on speed and ramp angle, your vehicle may land on both wheels –...
  • Page 6 VII. BATTERY INSTALLATION: VEHICLE Turn your vehicle over. Rotate the battery latch to release the battery holder. Slide the battery holder toward the latch. Lift the battery holder out of the vehicle. Insert 4 AA alkaline batter- ies into the battery holder, with polarity (+/-) as shown on the battery holder.

  • Page 7: Safety Information

    BATTERY INSTALLATION: TRANSMITTER 1. Slide battery door open. 2. Install one 9-volt (6LR61) battery with polarity (+/-) as shown inside battery compartment. 3. Replace battery door. VIII. SAFETY INFORMATION • To avoid accidental opera- rechargeable (nickel-cad- Note to Adults mium) batteries. tion, remove all batteries •...
  • Page 8 © 2000 Mattel, Inc., Mt. Laurel, NJ 08054 U.S.A. PRINTED IN CHINA. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. Retain this address for future reference: Mattel U.K., Ltd., Vanwall Business Park, Maidenhead SL6 4UB. Mattel Australia Pty., Ltd., Richmond, Victoria 3121 - Consumer Advisory Service: 1800 800 812 (valid only in Australia).
