Automatic Barrier Gate
Instructions
Version: 1.0
Date: August, 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB1000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZKTeco PB1000 Series

Summary of Contents for ZKTeco PB1000 Series

  • Page 1 Automatic Barrier Gate Instructions Version: 1.0 Date: August, 2016...

  • Page 2: Table Of Contents

    Automatic Barrier Gate Instructions contents Chapter 1 Overview ..............................2 1.1 Appearance and Dimensions of the Chassis ..................2 1.2 Appearance and Dimensions of the Boom of the Barrier Gate ............2 1.3 Chassis Components ............................ 4 1.4 Working Principles ............................ 4 1.5 Specification Parameters of Product Series ....................

  • Page 3: Chapter 1 Overview

    PB1000 and PB2000 series barrier gates are available currently. The chassis appearance of the two series differs greatly, where PB1000 series use the gray painted housing while PB2000 series use the stainless steel housing. Figure 1-1A shows the appearance and dimensions of the PB1030 chassis and Figure 1-1B shows the appearance and dimensions of the PB2030 chassis.
  • Page 4 Automatic Barrier Gate Instructions 5m Straight Boom: 5 m (boom length, which can be extended to 5.8 m) Figure 1-2C...

  • Page 5: Chassis Components

    Automatic Barrier Gate Instructions Loop Detector (optional) Speed reducer Motor Controller ZKTeco 12 V power Motor crank supply (optional) Air switch Bottom amplification Four expansion bolts Motor Air switch Figure 1-3 Components inside the Chassis 1.4 Working Principles The core of the barrier gate adopts the modular design and consists of five modules: bearing and precision platform, power subsystem (motor), sine speed reduction subsystem, compression spring-type moment balance subsystem, and electric control subsystem.
  • Page 6 Automatic Barrier Gate Instructions ③ Sine speed reduction subsystem: The sine speed reduction subsystem is composed of constant-speed wheels and variable-speed wheels. It controls the falling speed of the boom. The speed is the lowest at the lifting start point and falling start point, and highest at the angle of 45 degrees.

  • Page 7: Specification Parameters Of Product Series

    Automatic Barrier Gate Instructions Lifting/ Fastening Appearance Model Boom Type Standard Boom Length Falling Note Mode Speed 3 m（the expansion boom Straight Chassis on PB1012L boom the left can be extended to 3.8 m） The 3M standard 3 m（the expansion boom Straight Chassis on configuration is...

  • Page 8: Chapter 2 Product Installation

    Automatic Barrier Gate Instructions Chapter 2 Product Installation 2.1 Installation Precautions 1) Install the parking lot barrier gate on a level road. If the road level is a slope, a horizontal base should be built. In addition, the parking lot barrier gate system needs to be correctly wired and operated in accordance with the wiring diagram.

  • Page 9: Civil Installation Of The Chassis

    Automatic Barrier Gate Instructions Chassis Expansion bolt Control 4-MQ2 Screw pad room Ground Ground Base concrete The power wire is Standard power wire wrapped and protected RVV3*1.0 using the wire sleeve when laid out under the ground (the strong current should be separated from the weak current) 2.3 Civil Installation of the Chassis...

  • Page 10: Boom Installation

    Automatic Barrier Gate Instructions Chassis Expansion bolt Screw pad Ground Ground Base concrete Figure 2-3C Figure 2-3D Figure 2-3E 2.4 Boom Installation Boom Installation Procedure 1) Take out booms. 2) Apply glue to the protrusion side of the convex boom and insert the protrusion side into the concave boom to bond the two booms to become one boom, as shown in Figure 2-4A.
  • Page 11 Automatic Barrier Gate Instructions 调整距离 Adjust the distance Figure 2-4C Installing the Decorative Cap Fasten screws after Decorative cap A adjusting the expansion boom Screw Decorative cap B Figure 2-4C Figure 2-4D Decorative cap B Decorative cap A Expansion boom Main boom Main boom Anti-crash strip...

  • Page 12: System Diagram

    Automatic Barrier Gate Instructions Figure 2-4F Installing the Boom to the Chassis 2.5 System Diagram Installation Diagram for the Barrier Gate and Wall: The distance between the chassis and the wall should be greater than or equal to 100 mm. The distance between the boom and the wall should be greater than or equal to 100 mm.
  • Page 13 Automatic Barrier Gate Instructions System Diagram Control room Standard power wire RVV3*1.0...

  • Page 14: Chapter 3 Device Wiring And Commissioning

    Automatic Barrier Gate Instructions Chapter 3 Device Wiring and Commissioning 3.1 Commissioning Preparations 1) Internal cables have been laid out completely prior to device delivery. Users are not allowed to change the cable layout but connect the device to a 220V/110 power supply. 2) The chassis housing must be grounded and a leakage circuit breaker must be installed on the power side.

  • Page 15: Additional Functions (Optional)

    Automatic Barrier Gate Instructions 4) Use the motor crank to lift the boom in the case of a power failure. Crank system: Add the following accessories: fan, temperature control board, power module 1）Cooling Temperature control board (placed inside the box) 12 V power system, Add the following accessories: Heating device,Temperature control board,Power 2）Heater...

  • Page 16: Chapter 4 Common Faqs

    Automatic Barrier Gate Instructions Chapter 4 Common FAQs Q: After the boom is installed, the boom does not give any response when a remote controller or external controller is used to control the boom lifting and falling. A: The signal problem occurring on the grating makes the mechanism get jammed. Check whether the grating plug malfunctions, use a controller to control the lifting and falling of the boom.

  • Page 17: Chapter 5 Device Maintenance

    Automatic Barrier Gate Instructions Chapter 5 Device Maintenance 5.1 Maintenance Items 1) Maintain the boom. Fix the degumming or falling part of the reflection film. 2) Tighten the cable joints and fix the contact points of the device. 3) Clear away dust from components inside the chassis. 5.2 Maintenance Period Maintenance technicians need to maintain the barrier gate system at the following frequency: 1) Maintain the boom once every month.

  • Page 18: Appendix 1 Packaging List

    Automatic Barrier Gate Instructions Appendix 1 Packaging List Barrier gate 1 pc Boom 1 set Transmittor 2 pc 2 pcs Instruction book 1 pc White stick band for installation positioning 1 pc Decorative cap for the boom 1 set Hardware pack 1 set M12 expansion bolt 4 pcs...

  • Page 19: Appendix 2 Wiring Diagram Of The Control Board

    Automatic Barrier Gate Instructions Appendix 2 Wiring Diagram of the Control Board Attached Figure – A Control Board Diagram The controller Match code Description: Press the K4 button on the controller, motherboard flashing yellow light, mean in the matching state, then press and hold the remote K1/K2 switch button pairing, when the flash a red light on the motherboard, the pairing is successful.
  • Page 20 Automatic Barrier Gate Instructions 220V/110V input Air switch Bumping bounce back system Loop Detector (optional) Grating1 Grating2 Motor Top illuminator of the pb2000 Expansion Board Boom illuminator (Optional (Optional) Relay 12V Power (Optional) Fan(Optional) Heater(Optional) Attached Figure – B1 Mains Supply and Motor Wiring Diagram...
  • Page 21 Automatic Barrier Gate Instructions 220V/110V input Air switch Motor Attached Figure – B2 Mains Supply and Motor Wiring Diagram Grating1 Grating2 Top illuminator of the pb2000 Attached Figure – C Grating and PB2000 illuminator Wiring Diagram...
  • Page 22 Automatic Barrier Gate Instructions Air switch Loop Detector (optional) Loop Detector coil (optional) Attached Figure – D Loop Detector Wiring Diagram Bumping bounce back system (optional) Attached Figure – E Bumping bounce back system Wiring Diagram...
  • Page 23 Automatic Barrier Gate Instructions 220V/110V input Air switch Expansion Board Boom illuminator (Optional) (Optional) Relay 12V Power (Optional) Fan(Optional) Heater(Optional) Attached Figure – F Expansion Board Wiring Diagram...
  • Page 24 Automatic Barrier Gate Instructions Expansion Board (Optional) Relay Attached Figure – G Wiring Diagram of the Combined Expansion Board and Controller...
