Telpo TP-8/16/24/32/64S Voice Gateway
Latest revision:
Revision No.:
Address: Room 201,Building A5, Hantian technology park, Foshan City, Guangdong, China

User Manual

Telepower Communication Co., Ltd.
Tel: +86 0757-86299753
website: www.telpouc.com
Email:
telpouc@telpo.com
Fax: +86 0757-86337898-770
2017-9-10
V1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP-8S and is the answer not in the manual?

Questions and answers

Related Manuals for Telpo TP-8S

Summary of Contents for Telpo TP-8S

  • Page 1: User Manual

    Telpo TP-8/16/24/32/64S Voice Gateway User Manual Latest revision: 2017-9-10 Revision No.: V1.2 Telepower Communication Co., Ltd. Tel: +86 0757-86299753 website: www.telpouc.com Email: telpouc@telpo.com Fax: +86 0757-86337898-770 Address: Room 201,Building A5, Hantian technology park, Foshan City, Guangdong, China...

  • Page 2: Welcome To Use

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Welcome to Use Introduction Thanks for purchasing our integrated access device (Voice gateway). Make sure you have read this manual before use. Applicable device’s model: TP-8/16/24/32/64S Matters related to readers This manual is suitable for ...

  • Page 3: Operation Safety Rules

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Operation Safety Rules  It is necessary to inspect the related power cables on a regular basis because overloaded power sockets or broken lines and connectors all are likely to trigger electric shock or fire. Please replace it immediately if there is any damage on surface. ...

  • Page 4: Table Of Contents

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Contents WELCOME TO USE ..................... 2 INTRODUCTION ....................2 OPERATION SAFETY RULES ................3 CHAPTER I PRODUCT INTRODUCTION ............6 1.1 Product Overview ..........................6 1.2 Product Features ............................7 1.2.1 Function characteristics ........................7 1.2.2 Voice characteristics ...........................7 1.2.3 Network characteristics ........................8 1.2.4 Protocol standards ..........................8 1.2.5 Management maintenance ........................8...
  • Page 5 TP-8/16/24/32/64S User Manual Version No.: V1.2 4.1.4 Telereport ............................32 4.2 Network Settings ..........................32 4.2.1 WAN Setting ............................. 32 4.2.2 LAN Setting ............................. 34 4.2.3 NAT Settings ............................ 36 4.2.4 QOS Settings ............................ 36 4.2.4 Vlan Settings ............................ 37 4.3 SIP Settings ............................

  • Page 6: Chapter I Product Introduction

    TP-8/16/24/32/64S User Manual Version No.: V1.2 6.2.7 Parameter Display Command ......................79 6.2.8 Parameter Effect-taking Command ....................79 6.2.9 SNMP-related Parameter Setting Command Set ................80 Chapter I Product Introduction The chapter focuses on introducing the networking modes and technical specifications of Voice gateway.

  • Page 7: Product Features

    TP-8/16/24/32/64S User Manual Version No.: V1.2 1.2 Product Features 1.2.1 Function characteristics  Multiple communication protocols: it supports session initiation protocol (SIP), has advantages of strong expansibility, good compatibility and the like, and is capable of interacting with all sorts of IMS platforms. ...

  • Page 8: Network Characteristics

    TP-8/16/24/32/64S User Manual Version No.: V1.2  Voice business: It supports hotline telephone, call transfer (forward transfer, backward transfer) and call waiting.  Three-party services  Safe communication: It supports signal encryption and media encryption.  Billing function: It supports internet access private billing and POTS-standard reversed polarity signal billing.

  • Page 9: Working Environment

    TP-8/16/24/32/64S User Manual Version No.: V1.2  Network management: It supports OMC (SNMP) network management.  Backup restoration: It supports to export and import the configured files.  Expansion function: Plate loading, device-level stack function 1.2.6 Working environment  Power input: 150～310V AC 47/63Hz ...

  • Page 10: Technical Specifications

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Figure 1-2 Responsible for Dial-up Access as A Proxy Server 1.4 Technical Specifications 8FXS 16FXS 24FXS 32FXS 64FXS Item 350×290×44 441×290×44 441×290×44 441×290×44 442×280×43 Size (mm) .6mm W×H×D 3.0kg 3.1kg 3.2kg 3.3kg 3.5kg Weight Max Power Consumption DC12V.Extern...

  • Page 11: Device View

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Netwo mana One RS232（RJ45） geme interf Voice Port The registered quantity of sip extension agent 8FXS 16FXS 24FXS 32FXS 64FXS Interface Type Work -10℃~55℃ Temperature Storage -10℃~55℃ Temperature Humidity 0～95% (Non-condensed) 1.5 Device View Figure 1-3 8FXS（Plastic shell）...

  • Page 12: Panel Diagram

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Figure 1-5 32FXS Figure 1-6 64FXS 1.6 Panel Diagram Here we take 32FXS for example to introduce the panel part of the product. The panel diagram of 32FXS is shown as follows. CONSOLE POTS 100-240V 1A 50/60Hz Figure 1-7 The Front Panel Diagram of 32FXS...
  • Page 13 TP-8/16/24/32/64S User Manual Version No.: V1.2 Color Status Explanation Often lighted The device has been charged Green Non-lighted The device runs out of power Flashed The device is in service Green Green Non-lighted The device runs out of power or operates abnormally Lighted Any POTS port has off-hook Green...

  • Page 14: Chapter Ii Product Installation

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Chapter II Product Installation This chapter focuses on deliberately explaining the matters with respect to installation preparation, fixing and cable connection of Voice gateway. It mainly includes: Installation preparation  Device fixing  Cable connection ...

  • Page 15: Cabinet-Type Fixing

    TP-8/16/24/32/64S User Manual Version No.: V1.2 2.2.1 Cabinet-type Fixing Users are able to install the Voice gateway with big port in the standard cabinet based on needs. If on-site installation is necessary, users are required to comply with: 1. First, clean up where the subframe will be put in the cabinet, tidy the former cables and place them in the cable area at two sides of rack, adjust the supporting plates of right and left subframes to be in place, and insert the combined nuts in the attachment into square holes at front two sides of the cabinet (4 for each side);...
  • Page 16 TP-8/16/24/32/64S User Manual Version No.: V1.2 Figure 2-2 TP-64S Cable Connection Diagram  Warning: for operating safely, do not energize the device until all cables of it are connected and installation inspection is finished.  Reminding: It is suggested to utilize single-phase three cord power socket of neutral connector or multi-function microcomputer power socket.

  • Page 17: Chapter Iii Rapid Configuration

    TP-8/16/24/32/64S User Manual Version No.: V1.2 ONU)/ASDL modem by cable. TP-64S primary voice gateway LAN port connects with slave voice gateway WAN port by cable. And so on, it can cascade three device including primary and slave devices FXS ports(1-192 telephone ports) connect with user telephones by 6*32 pair single-core copper connectors.

  • Page 18: Preparation Before Configuration

    TP-8/16/24/32/64S User Manual Version No.: V1.2 3.1 Preparation before Configuration Before configuring Voice gateway, you are required to first confirm: 1. Network access method: 2. Voice gateway’s WAN port supports PPPoE dialing, dynamic IP address and static IP address. 3. SIP server address, port, account and password. For example: Voice gateway data configuration information (enter the italic information pursuant to the practical requirements).

  • Page 19: Pc's Ip Address Modification

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Connect route 32 RJ-11 business port with user’s telephone. 3.3 PC’s IP Address Modification Connect computer with Voice gateway’s LAN port, and set its IP address as 192.169.0.2~192.169.0.254, subnet mask as 255.255.255.0, and gateway as 192.169.0.1. It is fine not to fill in DNS or keep the initial value.

  • Page 20: Voice Gateway Gateway Login

    TP-8/16/24/32/64S User Manual Version No.: V1.2 3.4 Voice gateway Gateway Login Open IE browser and input LAN port’s default IP address (IP 192.169.0.1 or 192.169.0.235) in address column. Enter username as admin and password as psw.iad (note the capital and small letters), then import security code.
  • Page 21 TP-8/16/24/32/64S User Manual Version No.: V1.2 right. - 21 -...

  • Page 22: Voice Gateway Network Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 3.5 Voice gateway Network Settings Choose “Network Settings  WAN Setting” and choose “Static IP”, fill in the relevant parameters such as gateway IP address, subnet mask, exit gateway, and then click to save. Explanations: ...

  • Page 23: Sip Server Parameters Setting

    TP-8/16/24/32/64S User Manual Version No.: V1.2 3.6 SIP Server Parameters Setting Click “SIP Settings  Basic settings” that is in the left column, complete the main server’s information and port in the basic settings, complete the local domain name in the local SIP parameter settings, and then click to save.

  • Page 24: Ports Status

    TP-8/16/24/32/64S User Manual Version No.: V1.2  Basic settings” that is in the left column, complete Click “Port settings username, password and identified name in the basic settings, and than click to save. Explanations: SIP parameters are conditional upon the soft switch. Usually, username is the identified name.

  • Page 25: Device Reboot

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Note: If one port shows “unregistered”, please check settings of corresponding port’s parameters, and consult SIP soft switch platform. 3.9 Device Reboot Click “System Maintenance  Device Reboot” that is in the left column. After Voice gateway restart, use IE browser to log in Voice gateway once more via LAN IP, check Voice gateway status, and confirm the operating WAN port information in the status inquiry and confirm registration status in the user port status.

  • Page 26: Hyperterminal Login

    TP-8/16/24/32/64S User Manual Version No.: V1.2 determine.] 5. Execute the following command in command line’s window, refer to telnet 192.169.0.1 1250 in the following image: 6. Click enter key to go to the device’s telnet login interface, see beow: 7. Input correct username and password, the default username is admin, and default password is psw.iad.
  • Page 27 TP-8/16/24/32/64S User Manual Version No.: V1.2 2. Import a link name, button enter key or use mouse to click “OK” to go to the next. Then, a “connection to” dialog box will appear. In “use at the time of connection” drop-down menu, make sure the chosen port must be consistent with serial port of PC machine linked with Voice gateway, as shown in the following image.
  • Page 28 TP-8/16/24/32/64S User Manual Version No.: V1.2 3. Press enter key or click “OK” button to go to the next, and then set the port property. Perform settings as follows for port parameters:  baudRate: 9600  DataBits: 8  Parity: Non ...

  • Page 29: Chapter Iv Detailed Configuration

    TP-8/16/24/32/64S User Manual Version No.: V1.2 5. Fellow the system reminders and import correct username and password to log in. If it is your first time to log in, please use the default account. Default username is admin, and default password is psw.iad. The detailed settings of the command are set forth in the later instructions.

  • Page 30: Device Status

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Global parameter settings  4.1 Device Status Here you are able to inquire Voice gateway’s every status, including device model, operation time, software and hardware versions, WAN’s status information, LAN port information status, user port status and traffic statistic information, etc.

  • Page 31: Wan Status

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Explanations: It is essential to review the port’s corresponding number and registered status of SIP business. The current statuses include idleness, waiting for dialing, ringback tone, conversation, busy tone and ringing. 4.1.3 WAN Status Click “Device Status”, and then click “WAN state”, the following information will appear in the system.

  • Page 32: Telereport

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.1.4 Telereport Click “Device Status”, and then click “telereport”, the following information will appear in the system. Explanations: Traffic statistics cover the real-time state of current activated port, conversation time and other information. 4.2 Network Settings Network settings include: WAN Setting: It refers to the upward access network port;...
  • Page 33 TP-8/16/24/32/64S User Manual Version No.: V1.2 Explanations: 1. Choose IP type  Use DHCP to acquire IP  By “online pattern” to open “DHCP”, then click to save.  PPPoE dialing, input account and password and then click to save. 2.

  • Page 34: Lan Setting

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.SNTP settings coincide with network time protocol, and automatically synchronize with the device time. Cascade configuration, it has standalone mode and primary device mode, slave device mode  if cascaded, need to differentiate the primary device and slave device; ...
  • Page 35 TP-8/16/24/32/64S User Manual Version No.: V1.2 ：LAN port’s default IP is 192.169.0.1 / 255.255.255.0. It is suggested not to make any modification but a special case! Especially ensure not to repeat LAN port IP network segment and WAN port IP segment! Explanations: ...

  • Page 36: Nat Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.2.3 NAT Settings Explanations:  NAT function is not started using by default. If it is started, the computer connected with LAN port can share network.  Open the host, and offer DMZ function. In special cases, a computer in local area network needs to be exposed to wide area network completely, to realize double-way communication.

  • Page 37: Vlan Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2  VLAN prior level is 802.1P. It ranges from 0~7. Note: Before start, please firstly determine whether the entire transit network backs up VLAN or not. Otherwise, it will contribute to some faults, such as IP disconnection, DNS analysis failure, registration failure and so on.

  • Page 38: Basic Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 please inquire the address, account and password from the facilitator to register the server. 4.3.1 Basic Settings  SRV mode: It needs opening when DNS server adopts SRV-type DNS analysis;  SRV domain: When it is the SRV-type DNS analysis, SRV domain name needs to be configured.

  • Page 39: Advanced Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Explanations:  Local domain: It is usually the same as the registered server;  Local sip port: It is defaulted to be 5060, and Voice gateway need restarting if it has any modification;  Registered Interval: It refers to the interval that Voice gateway sends online information to SIP server, 60 to 3600 seconds are available, and factory default one is 600 seconds.
  • Page 40 TP-8/16/24/32/64S User Manual Version No.: V1.2 It can normally communicate with Voice gateway once used in SIP platform;  NAT STUN: It defaults to being open;  NAT keepalive interval: It is 5 seconds by default; 2.Heartbeat  Heartbeat switch: It is set to send heartbeat parameters to platform, not turned on by default;...

  • Page 41: Black And White List

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.3.3 Black And White List Explanations: It is used to filter incoming calls with specified numbers  Select disable, and it does not enable incoming black and white lists;  Select white list, it only allows the specified number of calls, prohibit other calls, the maximum 128 numbers.

  • Page 42: Basic Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.4.1 Basic Settings Explanations:  Port: The sequence for telephone cable is in accordance with the marks on machine’s external case;  Port type: FXS and FXO;  SIP Username: SIP account;  Password: IIP account’s password; ...

  • Page 43: Register Group Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.4.2 Register Group Settings - 43 -...

  • Page 44: Voice Fax Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.4.3 Voice Fax Settings Explanations:  Port configuration choice: It refers to choosing the port needs configuring. Voi ce Setting:  Silence Compression: It is closed by default, means the period to recognize and eliminate the long-time silence from sound signal flow, so as to save network resources;...

  • Page 45: Advanced Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Accordingly, set the value small depending on the network rate. The default value is 1, equal to 15ms;  DTMF Mode: It supports inband, SIPINFO and RFC2833;  DTMF gain: It is defaulted to be -4dB; ...

  • Page 46: Ringing Polling Setting

    TP-8/16/24/32/64S User Manual Version No.: V1.2  The Caller Display Restrict:It is not enabled by default.  Call Wait: It deems to be stated using;  No disturb: The port will not be called in in enabled mode, so it needs to be started;...

  • Page 47: Ringing Group Setting

    Make the function of multiple extensions ring in the same ring group when call in, the max ring group number is 16; Telpo suggestion: it is better to least than 16 users in a ring group when only one device. 4.4.7 User Group Settings...

  • Page 48: Dialing Routing Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.5 Dialing Routing Settings The dialing routing settings include Sip Digit Map and Prior Digit Map. 4.5.1 SIP Digit Map Explanations:  Diagram: It is defaulted to be enabled;  #speed dialing: Call out when getting # number, and set up according to requirements;...

  • Page 49: Prior Digit Map

    TP-8/16/24/32/64S User Manual Version No.: V1.2  Underweight length: It refers to the replacement rule of the number set as called number;  Overweight: It refers to the replacement rule of the number set as called number;  Additional overweight: It refers to the replacement rule of the number set as called number;...

  • Page 50: Global Parameter Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.6 Global Parameter Settings 4.6.1 DSP Settings Explanations:  RFC2833 Payload: The corresponding value is set as 97～101 based on demands, and the default is 97;  RTP port scope: It refers to the port that RTP protocol is using at the time of setting conversation.

  • Page 51: Slic Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.6.2 SLIC settings  Ring mode: different ringing modes can be set, including mode 1, mode 2 and mode 3; different modes of ringing voltage are different; defaults to mode 2.  Standby mode: enabled by default. - 51 -...

  • Page 52: Timers

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.6.3 Timers Explanations:  No dial-up timeout (T timer): It is 16 seconds by default;  Dail-up timeout (S timer): It is 4 seconds by default;  Timeout of number matching failure (L timer): It is 16 seconds by default; ...

  • Page 53: Pos Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 4.6.4 POS settings When it connects to the POS, you need to set the called number of the POS call, and you can set 20 called numbers. Chapter V Advanced Settings This chapter introduces how to make use of Voice gateway to perform some advanced settings by WEB web to let users utilize expanded functions.

  • Page 54: Nms Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 5.1 NMS Settings Explanations:  Settings like whether to enable network management function, IP configuration of network management system and relevant parameter setting. Additionally, settings also include to set gateway’s device name and automatically register cycle of network management station;...
  • Page 55 TP-8/16/24/32/64S User Manual Version No.: V1.2 Explanations:  Trun on/off TR069 function, support TR069(CM) and TR069(CTC) Explanations:  IVR configuration parameters: It sets whether to turn on the IVR phone configuration function. After Voice gateway is started, you can access the phone at any port and enter the function code (*33*) into the voice interaction mode.

  • Page 56: Firewall Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Fill in customer information Notify network management for parameter backup. Explanations:  Turn on S10 AG mode, it is not star up by default; Use to manage voice gateway device by S10 softswitch, the management includes account management, parameter management, software upgrade.

  • Page 57: Port Settings

    TP-8/16/24/32/64S User Manual Version No.: V1.2 5.2.2 Port Settings Only accept SIP server message, it is turn on by default. Reject to accept the non-SIP server message. If want to use FXO jumper, please turn off this function. 5.3 System Maintenance System functions cover authority management, software upgrading, data backup upgrading, factory setting restoration, etc.

  • Page 58: User Management

    TP-8/16/24/32/64S User Manual Version No.: V1.2 5.3.1 User Management  Pay attention to capital and small letters when entering password. Account number: admin Password: psw.iad Account number: ac_iad password: psw.access  User account will be locked after 5 password error, and can not login.

  • Page 59: Config Backup

    TP-8/16/24/32/64S User Manual Version No.: V1.2 5.3.3 Config Backup  A: Prohibit the use of non configuration file, if you do not operate properly, it may cause irreversible damage! Please be careful with!! To back up and restore the gateway configured information. 5.3.4 Default Settings Explanation: It needs to reserve gateway’s IP address and routing settings except for factory...

  • Page 60: Device Reboot

    TP-8/16/24/32/64S User Manual Version No.: V1.2 5.3.5 Device Reboot Explanations: Restarting gateway causes the unsaved parameters to be lost. Restart takes around 2 minutes. 5.3.6 System log You can see the detailed system logs here. - 60 -...

  • Page 61: Device Information

    TP-8/16/24/32/64S User Manual Version No.: V1.2 5.3.6 Device information You can name the device here. - 61 -...

  • Page 62: Chapter Vi Appendix

    TP-8/16/24/32/64S User Manual Version No.: V1.2 Chapter VI Appendix Appendix I Basic Configuration Commands This section includes: Command line interface profile: It focuses on introducing how to log onto the command line interface, command line format and characteristics; Compressed chip configuration: It focuses on introducing the configuration commands and methods related to compressed chip;...
  • Page 63 TP-8/16/24/32/64S User Manual Version No.: V1.2 Root command level: Cursor display with “＃” after, it means the current command is in the root command layer; Sub-command level: current setting directory name with “>” and cursor display after , it means the current command is in the sub-command layer;...

  • Page 64: Auxiliary Function

    TP-8/16/24/32/64S User Manual Version No.: V1.2 reboot_type，route，save，test，timezone upload，version， exit，help Manage/snmp-layer agent, community, exit, group, help, show, switch, trap, user sub-command Every command format is organized in the form of “command name, parameter 1, parameter 2..”. For instance, network> ip-mask 192.168.1.2/24 Therein, “network>”...

  • Page 65: Detailed Explanations For Voice Command Usage

    TP-8/16/24/32/64S User Manual Version No.: V1.2 6.2 Detailed Explanations for Voice Command Usage 6.2.1 Compressed Chip Setting Command Set You could go to compressed chip setting contents once entering “codec” command, see below: ＃ codec Please input endpoint index (1 ~ 24): 1 In consideration of many ONU ports, so the subport displays port’s parameters.
  • Page 66 TP-8/16/24/32/64S User Manual Version No.: V1.2 codec_ep1> fax {parameter} The parameter is only “t38” or “transparent”, “t38” means the fax protocol is T.38, and “transparent” means the fax protocol is EAP over radius. G.723.1 code rate setting command codec_ep1> g.723.1 {parameter} The parameter is only “high”...
  • Page 67 TP-8/16/24/32/64S User Manual Version No.: V1.2 The parameter is only “－3.5”, “－7” or “0”, unit is dB. Command to set compressed chip package cycle codec_ep1> pktintvl {parameter} The parameter is the package cycle, unit is ms. For example: codec_ep1> pktintvl 20 Coding priority setting command Interaction setting mode: codec_ep1>...
  • Page 68 TP-8/16/24/32/64S User Manual Version No.: V1.2 function; and “disable” means to close it. T38 control mode setting command codec_ep1> t38_mode {parameter} The parameter is only “mgc” or “mg”. Therein, “mgc” means T38 mode is controlled by mgc; and “mg” means T38 mode is controlled by mg. T38 port setting command codec_ep1>...
  • Page 69 TP-8/16/24/32/64S User Manual Version No.: V1.2 H.248 timer setting command codec_ep1> dm_timer {parameter1} {parameter2} {parameter3} Therein, parameter1 is the short timer, parameter 2 is the long timer, parameter 3 is the start timer, and unit is second. Setting command of RTP flow keeping of H.248 codec_ep1>...

  • Page 70: Network Parameter Setting Command Set

    TP-8/16/24/32/64S User Manual Version No.: V1.2 of taking effect immediately, and “[3]” refers to saving the changed parameters and take effect immediately. After making a choice, CLI will go back to the root command layer. Users can button “Ctrl-C” or enter key to cancel the operation. Non-interaction mode codec_ep1>...
  • Page 71 TP-8/16/24/32/64S User Manual Version No.: V1.2 Example: #network> connection connection1 Setting of the physical port for connection # network/conn connection1> set phyport {parameter} Parameter is the physical port. There are two physical ports on the device, one is FEO, the other is FE1.

  • Page 72: Protocol-Related Parameter Setting Command Set

    TP-8/16/24/32/64S User Manual Version No.: V1.2 network> ntp The command is set by mode of interaction, it does not need any parameter. After performing the command, CLI will show the on-off state of current NTP client service, and then inquire users whether to open or close it.
  • Page 73 TP-8/16/24/32/64S User Manual Version No.: V1.2 Parameter 1 is the MG domain name, and parameter 2 is the MG port number (optional). The max domain name bit is 255, and port number ranges from 0～65535. Command to set MGC domain name and port protocol_ep1> mgc {parameter1} [parameter2] Its usage is the same as the “mg”...

  • Page 74: System Parameter Settings And System Tool Command Set

    TP-8/16/24/32/64S User Manual Version No.: V1.2 that will be set. See below: MGC Mode: [0] DEFAULT [1] HW [2] ZTE [3] BELL Input your choice[0~3]: At this time only numbers chosen from 0～3 can be input. If the users want to give up the settings, they are able to button “Ctrl＋C”...
  • Page 75 TP-8/16/24/32/64S User Manual Version No.: V1.2 The user groups of the system cover Admin, DataUser, VoiceUser and Guest. Each group has the default users, they are Admin, DataUser, VoiceUser and Guest respectively. Password and username are not different. Users from different group have different rights. User from guest group only has right to read, but has no right to configure;...
  • Page 76 TP-8/16/24/32/64S User Manual Version No.: V1.2 Download command system> download {parameter1} {parameter2} {parameter3} Parameter 1 only can be “config”, pf0”, pf1”, pf2” or “program”. Of them, “program” refers to procedure mapping files, others refer to parameter configuration files, they are required to be relative to the different parts of Flash respectively.
  • Page 77 TP-8/16/24/32/64S User Manual Version No.: V1.2 Memory status display command system> mem This command does not need any parameter. It is used to display the current memory status of the system. Network connectivity test command system> ping {parameter} The parameter is the IP address planned to be tested, for instance: system>...
  • Page 78 TP-8/16/24/32/64S User Manual Version No.: V1.2 The parameter only can be “pf0”, pf1”or “pf2”. “save as pf0” means there is no any parameter for this command. The command is used to save the configured values of the all current parameters into the different parts of Flash.

  • Page 79: Cli Cancellation Command

    TP-8/16/24/32/64S User Manual Version No.: V1.2 6.2.5 CLI Cancellation Command #logout The command has no need of any parameter, and it is used to cancel CLI. 6.2.6 System Restart Command # reboot The command has no need of any parameter, and it is used to restart the target board. 6.2.7 Parameter Display Command ＃show {parameter} The parameter can only be “codec”, protocol”, net”, private”...
  • Page 80 TP-8/16/24/32/64S User Manual Version No.: V1.2 take effect. 6.2.9 SNMP-related Parameter Setting Command Set Command to enable or disable snmp setting #manage/snmp> switch { parameter } This command is to turn on or off the snmp module. The parameter only can be “on” or “off“. “on” means to turn on snmp function;...
  • Page 81 TP-8/16/24/32/64S User Manual Version No.: V1.2 #manage/snmp> trap set { parameter1 } { parameter2 } The command is used to set trap’s port number and host IP. Parameter 1 is host IP, namely the address that trap information is sent to; parameter 2 is trap’s port number, the default is 162. (All communities here use the same trap configuration).
