Telpo TP Series User Manual

Fxs+fxo voice gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Telpo FXS+FXO Voice Gateway
Revision Date
Version number
Address: Room 201,Building A5, Hantian technology park, Foshan City, Guangdong, China
User Manual
2017-09-07
V1.2
Telepower Communication Co.,Ltd
Tel: 0757-86299753
website: www.telpouc.com
Email:
telpouc@telpo.com
Fax: 0757-86337898-770
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telpo TP Series

Summary of Contents for Telpo TP Series

  • Page 1 Telpo FXS+FXO Voice Gateway User Manual Revision Date 2017-09-07 Version number V1.2 Telepower Communication Co.,Ltd Tel: 0757-86299753 website: www.telpouc.com Email: telpouc@telpo.com Fax: 0757-86337898-770 Address: Room 201,Building A5, Hantian technology park, Foshan City, Guangdong, China - 1 -...

  • Page 2: Welcome To Use

    Welcome to Use Introduction Thanks for purchasing our integrated access device (voice gateway). Make sure you have read this manual before use. Applicable device’s model: Telpo TP Series TP-8S8O/TP-16S16O Matters related to readers This manual is suitable for Project planner ...

  • Page 3: Operation Safety Rules

    Form 1 Prompts Reminding Icon Reminders Type  Reminding It means the important traits or operation guidance It means it may do harm to people, or cause damage Attention to the system, or the business data to be  disconnected or lost. ...
  • Page 4 Declaration Without our permission, it is prohibited to reproduce or reprint any part of this manual. We will not notify you of any alteration of this manual. Thanks for purchasing our product! Please feel free to give us any criticism and suggestion, we will deem them as the best encouragement and support for our work.

  • Page 5: Table Of Contents

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Contents WELCOME TO USE ..................2 INTRODUCTION .................... 2 OPERATION SAFETY RULES ................3 CHAPTER I PRODUCT INTRODUCTION ............8 1.1 Product Overview ..........................9 1.2 Product Features ........................... 9 1.2.1 Function characteristics ........................9 1.2.2 Voice characteristics ........................
  • Page 6 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 3.1 Preparation before Configuration ....................23 3.2 Cable Connecting ..........................24 3.3 PC’s IP Address Modification ...................... 24 3.4 Voice Gateway Login ......................... 26 3.5 Voice Gateway Setup Wizard ......................27 3.6 Voice Gateway Status Review ......................29 3.7 Voice gateway Restart ........................
  • Page 7 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.6 Global Parameter Settings ....................... 63 4.6.1 DSP Settings ............................64 4.6.2 SLIC Setting ............................65 4.6.3 Timer ..............................66 4.6.4 POS Settings ............................. 67 CHAPTER V ADVANCED SETTINGS ............67 5.1 Network Management Settings ....................68 5.2 Firewall Settings ..........................

  • Page 8: Chapter I Product Introduction

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Chapter I Product Introduction The chapter focuses on introducing the networking modes and technical specifications of voice gateway Following are the main contents: Product overview  Product features  Networking modes ...

  • Page 9: Product Overview

    Telpo TP-8S8O/TP-16S16O voice gateway is used widely. It can be installed in many places, such as corridor, house, phone bar and so forth. And it is helpful for a family, phone bar or small-sized company in network, telephone and fax, etc.

  • Page 10: Voice Characteristics

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Support rotation group, ring group, user group function  Multiple communication protocols: it supports session initiation protocol (SIP),  has advantages of strong expansibility, good compatibility and the like, and is capable of interacting with all sorts of IMS platforms.

  • Page 11: Network Characteristics

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Dialing rules: It supports E.164 coding rule, custom dialing rule and automatic  search agent server. DTMF standard: Inband audio, outband over RTP (RFC2833/SIP INFO)  Voice business: It supports hotline telephone, call transfer, call forward, call ...

  • Page 12: Management Maintenance

    1.3 Networking Mode The next generation network (NGN) is developing and perfecting based on the soft switch. Telpo TP-64S voice gateway in the access layer is used in extensive fields, including network access, telephone, fax and other demands of families, phone bars or small-sized companies.
  • Page 13 2、As a proxy server, it is responsible for dial-up access. Telpo TP-8S8O/TP-16S16O voice gateway’s WAN port is directly connected with  xDSL (Cable) Modem. As a proxy server, Telpo TP-64S voice gateway is responsible for proxy access. - 13 -...

  • Page 14: Technical Specifications

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Figure 1-2 Responsible for Dial-up Access as A Proxy Server 1.4 Technical Specifications model TP-8S8O TP-16S16O Size (mm) 441×290×44 441×290×44 W×H×D weight 3.2kg 3.3kg Max Power Consumption Power AC 85v～265V 47/63Hz AC 85v～265V 47/63Hz Upward interface 1 个...

  • Page 15: Appearance

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Network management One RS232（RJ45） interface Voice Port Eight Sixteen Interface Type 8FXS8FXO 16FXS16FXO Work Temperature -10℃~55℃ Storage Temperature -10℃~55℃ Humidity 0～95% (Non-condensed) 1.5 Appearance Figure 1-3 TP-8S8O front view Figure 1-4 TP-16S16O front view...

  • Page 16: Device View

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Figure 1-5 TP-8S8O /16S16O back view 1.6 Device View Figure 1-6 TP-8S8O view Figure 1-7 TP-16S16O view 1.7 Panel Diagram The panel diagram of TP-16S16O voice gateway is shown as follows. TP-8S8O is similar with TP-16S16O.
  • Page 17 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Figure 1-9 TP-16S16O panels The meaning of each kind of state of indicator light on the front panel of TP-16S16O voice gateway is shown as follows: Explanation on indicator light as follows. Indicator lights of FE port and CONSOLE interface are on RJ45 of the port.

  • Page 18: Chapter Ii Product Installation

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Chapter II Product Installation This chapter focuses on deliberately explaining the matters with respect to installation preparation, fixing and cable connection of voice gateway. It mainly includes: Installation preparation  Device fixing ...

  • Page 19: Device Fixing

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Where installation is executed should be well-ventilated, to help the device to  dissipate heat (the suitable environment is -10℃～55℃). Installation place should be free from water, moisture and thunder, etc. (the ...

  • Page 20: Plan Fixing

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 1: Subframe mounting hole; 2&4: Nut component; 3: Bearer Figure 2-1 Installation Completion Diagram 2.2.2 Plan Fixing Take out four rubber mats equipped with voice gateway and clip them into four small holes on the device’s base plate, and then put the device on a stable and flat desk,...
  • Page 21 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Figure 2-2 TP-8S8O/TP-16S16O Cable Connection Diagram  Warning: for operating safely, do not power on the device until all cables of it are connected and installation inspection is finished.  Reminding: It is suggested to utilize single-phase three cord power socket of neutral connector or multi-function microcomputer power socket.

  • Page 22: Chapter Iii Rapid Configuration

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 After turn on the cascade mode in primary device, do not  connect the LAN port of primary device with local area network. Take TP-16S16O cascading mode for example. TP-16S16O primary voice gateway WAN port connects with upward ethernet network (like ONU)/ASDL modem by cable.

  • Page 23: Preparation Before Configuration

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Cable connecting, PC address modification  Network access settings  SIP Rapid configuration  Voice gateway offers users an imaging and simple-operation WEB conversation interface, so users are able to configure all functions of voice gateway just on the...

  • Page 24: Cable Connecting

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 3.2 Cable Connecting 1. Connect the device power cord; 2. Link the upward network cable with voice gateway’s WAN port; 3. Connect voice gateway’s LAN port with PC, which is used to carry out management;...
  • Page 25 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Open network connection, right click “local connection”, click property; Open local connection property, choose “Internet protocol (TCP/IP)”, click property (R); Choose the option of “Use of the following IP address”, modify PC’s IP address according to the practical needs.

  • Page 26: Voice Gateway Login

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 3.4 Voice Gateway Login Open IE browser and input LAN port’s default IP address (IP 192.169.0.1:8008 or 192.168.0.235:8008) in address column. - 26 -...

  • Page 27: Voice Gateway Setup Wizard

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Enter username as admin and password as psw.voice gateway (note the capital and small letters), then import security code. It will immediately skip to gateway main interface once input right. User can configure the voice gate with the quick guide (the left button “Guide”).
  • Page 28 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 network; If choosing “PPPoE”, needs to fill in the username and password that  broadband supplier provides. If choosing “Static IP”, please fill in IP address, subnet mask, breakout gateway,  DNS address, SNTP address.

  • Page 29: Voice Gateway Status Review

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Note: Click “Port settings  basic settings” that is in the left column, complete username, and password and identified name in the basic settings, and then click to save. SIP parameters are conditional upon the soft switch. Usually, username is the identified name.

  • Page 30: Voice Gateway Restart

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Note: If the registration status of one port is “Failed”, please check settings of corresponding port’s parameters, and consult SIP soft switch platform. 3.7 Voice gateway Reboot Click “system Maitainece  Device Reboot” that is in the left column.

  • Page 31: Telnet Login

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 3.8 Telnet Login Through Telnet to log voice gateway in the configuration interface. (after the device is energized, LAN port’s default IP is 192.169.0.1 and subnet mask is 255.255.255.0). Carry out inband management to the device via command line configuration.

  • Page 32: Super Terminal Login

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 7. Input correct username and password, the default username is admin, and default password is psw.voice gateway. 3.9 Super Terminal Login Voice gateway can configure the device by CONSOLE port. Connect one end of serial port line to voice gateway’s CONSOLE control port, and another end to any serial...
  • Page 33 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 2. Import a link name, press enter key or use mouse to click “confirmation” to go to the next step. Then a “connection to” dialog box will appear. In “use at the time of connection”...
  • Page 34 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 3. Press enter key or click “confirmation” button to go to the next, and then set the port property. 。 - 34 -...
  • Page 35 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Perform settings as follows for port parameters: Bits for second: 9600  Data bits: 8  Odd-even check: No  Stop bit: 1  Data flow control: No  Press enter key or use mouse to click “confirmation”.
  • Page 36 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 5. Follow the system reminders and input correct username and password to log in. If it is your first time to log in, please use the default account. Default username is admin, and default password is psw.voice gateway. The detailed settings of the command are set forth in the later instructions.

  • Page 37: Chapter Iv Detailed Configuration

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Chapter IV Detailed Configuration This chapter has a detailed introduction to all configurations on voice gateway’s WEB web. It mainly includes: Device Status  Network Settings  SIP Settings  Port Settings ...

  • Page 38: Status Inquiry

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.1 Status Inquiry Here you are able to inquire voice gateway’s status, including device status, operation time, and software and hardware versions, WAN’s status information, LAN port information status, user port status and traffic statistic information, etc.

  • Page 39: Network State

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Explanations: It is essential to review the port’s corresponding number and registered status of SIP business. The current statuses include Idle, waiting for dialing, ringback, conversation, busy tone and ringing. 4.1.3 WAN Status...

  • Page 40: Network Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.2 Network Settings Network settings include: WAN setting: It refers to the upward access network port; LAN setting: It refers to the lower access network port including DHCP configuration and cascade configuration...
  • Page 41 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Explanations: 1. Use DHCP to acquire IP 2. PPPoE mode, input Username and password and then click to save. - 41 -...
  • Page 42 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 3. Static IP Enter IP address, subnet mask and default routing IP address, and then click to save. DNS settings DNS refreshing interval (usually it defaults 5 minutes), and prior and standby DNS address setting;...

  • Page 43: Lan Port Configuration

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 5. Cascade configuration, it has Single mode and Master mode, Slave mode.  if cascaded, need to differentiate the master device and slave device;  need to turn on the Master mode if used as Master device, need to turn on the slave mode if used as slave device, ...
  • Page 44 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 LAN port’s default IP is 192.169.0.1 / 255.255.255.0. It is suggested not : to make any modification except special case! Especially ensure not to repeat LAN port IP network segment with WAN port IP segment! Explanations: ...

  • Page 45: Qos Configuration

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.2.3 QOS Configuration Network service quality (QOS), Voice gateway supports prior marks of two-layer and three-layer data frames, to ensure conversation quality of IP voice. Explanations:  Two-layer Qos settings: VLAN ID is the tag based on 802.1Q.

  • Page 46: Sip Configuration

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.3 SIP Configuration SIP parameters are set pursuant to soft switch. The service provider usually has set the server’s parameters beforehand. In case you need to set them by yourself, please inquire the address, account number and password from the facilitator to register the server.

  • Page 47: Basic Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.3.1 Basic Settings  SRV mode: It needs to be enable when DNS server adopts SRV-type DNS analysis;  SRV domain name: When the SRV-type DNS analyzes, SRV domain name needs to be configured. Domain name starts with _sip._udp. For example, if the allocated domain name is sbc.telemobile.com, the configured one will be...

  • Page 48: Advanced Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Explanations:  Local domain: It is usually the same as the registered server;  Local SIP port: It is defaulted to be 5060, and voice gateway need to reboot if it is modified;...
  • Page 49 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Explanations: 1. NAT: Usually, voice gate in intranet is in need of turning on NAT penetration. It can normally communicate with voice gateway once used in SIP platform;  NAT STUN: It defaults to being enable;...
  • Page 50 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 register success or register fail.  Register flow limit, user can set the data packet sending number in every second.  Switch to backup SBC: allows to back to slave SBC  Switch back to primary SBC: allow to switch back to primary SBC ...

  • Page 51: Black/White List Configuration

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.3.3 Black/white List Configuration Explanations:  Choosing Disable, then turn off the black/white list function;  Choosing white list, then allows the number in white list to call in, and do not allow other numbers to call in.

  • Page 52: User Port Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.4 Port Settings Opening “Port settings” user can execute the basic settings like voice gateway’s SIP account, password and other parameters; Besides these, users also can set voice fax, advanced service, attendant, ringing group...

  • Page 53: Basic Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.4.1 Basic Settings Explanations:  Port: The sequence for telephone cable in accordance with the marks on phones’ external case;  Port type: FXS(Caller ID shows after ringing)  SIP username: SIP account;...

  • Page 54: Universal Registration Configuration

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.4.2 Register Group Setting - 54 -...

  • Page 55: Voice Fax Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.4.3 Voice/Fax Settings Explanations:  Select Port: It refers to choosing the port which needs configuration. Voice Settings:  Silence Compression: It is closed by default, means the period to recognize and eliminate the long-time silence from sound signal flow, so as to save network resources;...
  • Page 56 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 G711A/U, G723.1, G729;  Packet interval: It means the size of voice data packet on the conversation. The bigger the value is, the bigger the voice data package transmitted on the conversation will be, which suggests it makes full use of the network broadband.

  • Page 57: Advanced Business Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2  Max rate: it’s set to be 14400 by default;  High rate redundance : it’s set to be 2 by default;  Low rate redundance: it’s set to be 2 by default.

  • Page 58: Fxo Port Configuration

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 usage pattern as the hotline; 4.4.5 FXO Port Configuration FXO ports settings Set the FXO ports to conncet with multi FXS ports and attendant port. Bound Port, show FXO ports number Ring time, user can set the ring time when call in FXO.

  • Page 59: Pstn Outgoing Call Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.4.7 PSTN Callout settings To set outgoing call by FXO, and bind FXS with FXO. - 59 -...

  • Page 60: User Group Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.4.8 User Group Settings Set it as a gateway user to register to the platform 4.5 Call Routing The call routing settings include SIP Digit Map, PSTN Digit Map, and Priority Digit Map.

  • Page 61: Network Diagram

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.5.1 SIP Digit Map Explanations:  Voip Digit Map: It is defaulted to be enabled;  Quick Dial w/’#’: Call out when voicegateway get # number, and this attribute is set according to users’ requirements;...

  • Page 62: Pstn Diagram Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 configuration. If it is mutually called in a same device, it will be set as 127.0.0.1; if it is point-to-point callin, it should be configured as the IP address of counter party;...

  • Page 63: Global Parameter Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.5.3 Prior Digit Map  prior digit map is higher than SIP diagram, when it can not meet the demand of interal calls by SIP digit map, please use prior digit map.

  • Page 64: Dsp Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.6.1 DSP Settings Explanations:  RFC2833 Payload: The corresponding value is set as 97 ～ 101 based on demands, and the default is 97;  RTP port scope: It refers to the port that RTP protocol is using on conversations.

  • Page 65: Slic Setting

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.6.2 SLIC Setting  Ringing mode: can set different ringing mode, including Mode 1, Mode 2, and Mode 3. It is different ringing voltage in different mode. Mode 2 by default  Standby mode, it is enable by default.

  • Page 66: Timer

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 4.6.3 Timer Explanations:  Start time: No dial-up timeout (T timer),It is 16 seconds by default;  Short time: Dail-up timeout (S timer), It is 4 seconds by default;  Long time: Timeout of number matching failure (L timer). It is 16 seconds by default;...

  • Page 67: Pos Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2  The international call setting, limit the international outgoing calls 4.6.4 POS Settings When connecting with POS machine, it needs to set up the POS called number, can set up 20 called numbers at most.

  • Page 68: Network Management Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 5.1 NMS Settings Explanations:  To enable network management function, IP configuration of network management system and relevant parameter setting. Additionally, settings also include to set gateway’s device name and automatically register cycle of network management station;...
  • Page 69 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Explanations:  IVR config parameter: turn on/off the IVR function. Turn on voice gateway, and connect with a telephone, then enter function code (*33*) to enter the voice interaction mode. Follow the voice prompt to set the IP access, restore default configuration (include IP address), set the OMC Web management IP, turn on/off OMC Web management.

  • Page 70: Firewall Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Fill in client information Notify network management for parameter backup 5.2 Firewall Settings 5.2.1 White List Function Explanation: The white list function is closed by default.  Note: when turn on the white list function, if do not add white list address, then it will forbid all IP to login WEB GUI.

  • Page 71: Port Settings

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 5.2.2 Port Settings Only accept SIP server message, it is turn on by default. Reject to accept the non-SIP server message. If want to use FXO jumper, please turn off this function.

  • Page 72: User Management

     It is more likely to provoke irreparable damage in case of improper operation! Be cautious to use! Telpo voice gateway supports to update the software via http loaded file. During upgrade, be sure to supply power for device, and forbid to cut ...

  • Page 73: Data Backup Upgrading

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 5.3.3 Data Backup Upgrading DO NOT use the Non configuration file.It is more likely to provoke irreparable damage in case of improper operation! Be cautious to use! To back up and restore the gateway configured information.

  • Page 74: System Log

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Explanations: Reboot gateway causes the unsaved parameters to be lost. Restart takes around 2 minutes. 5.3.6 System Log 5.3.7 Voice File Upload Upgrade explanations Upgrade in WEB, choose the voice you want to upload, and click upload to upgrade...

  • Page 75: Chapter Vi Appendix

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 。 below, to pack the voice file to the final file Voice file create tool.rar Chapter VI Appendix Appendix I Basic Configuration Commands This section includes: Command line interface profile: It focuses on introducing how to log onto the command line interface, command line format and characteristics;...

  • Page 76: Profile Of Voice Command Line Interface

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Network parameters configuration: It focuses on introducing the configuration commands and methods related to network parameters; System parameters configuration: It focuses on introducing the configuration 。 commands and methods related to system.
  • Page 77 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 6.1.3 Command Classification and Command Format Two major commands are root command and sub-command: Root command It refers to the first-layer command set after entering CLI, including codec: compressed chip configuration command...

  • Page 78: Auxiliary Function

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 port_vis， pos_num，reg_reason_code，remote_dscr_resp，rereg， resend_time ， send_local_sdp ， sig_ab_mode ， trans_type ， wt_to_handle，show，exit，help debug， dmesg， download， ifshow， load， logoutep， logoutmg， System-layer mem，regmg，resourceinquiry，ping，protocol，ps，regep， sub-command reboot_type，route，save，test，timezone upload，version， exit，help Manage/snmp-laye agent, community, exit, group, help, show, switch, trap, user r sub-command Every command format is organized in the form of “command name, parameter 1,...

  • Page 79: Detailed Explanations For Voice Command Usage

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 After ending the command line entry (press enter key after nonempty character string), CLI will write the contents input last time into command history butter memory; After pressing upkey or downkey, users are able to search command history records and the searched records will be automatically written into command line.
  • Page 80 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 In consideration of many ONU ports, so the subport displays port’s parameters. The hosts of parameters are the global parameters, and the parameters showing in every port mode is the same as the set ones. Including...
  • Page 81 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Command to cancel Echo switch setting codec_ep1> ec {parameter} The parameter is only “enable” or “disable”, “enable” means to turn on the echo canceling function, and “disable” means to turn it off.
  • Page 82 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 set parameters include: Pulse Min Width Pulse Max Width Inter Digit Min Time Flash Min Time Flash Max Time Off Hook Time On Hook Time Such as: codec_ep1> line_hook Pulse Min Width [40]:...
  • Page 83 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Coding priority setting command Interaction setting mode: codec_ep1> priority Only “priority” command is entered, the command line will inquire the priority that user is going to set, as shown below: Algorithm priorities: [1] G.711A...
  • Page 84 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 codec_ep1> ring {parameter1} {parameter2} Parameter 1 is “on time”, namely the ring duration time; parameter 2 is “off time”, namely the ring interval time. The parameters for the both range from 0～65535, unit is ms.
  • Page 85 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Command for progress tone duration time setting codec_ep1> tone_duration The command is set by mode of interaction; it does not need any parameter. The set parameters include: Dial Tone Duration Busy Tone Duration...
  • Page 86 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Setting command of RTP flow keeping of H.248 codec_ep1> keepRTP The command is set by mode of interaction; it does not need any parameter. After performing the command, CLI will show RTP flow keeping on-off state, and then inquire the user whether to turn it on or turn it off.
  • Page 87 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 codec_ep1> exit If there is no any parameter set, please directly go back to the root command layer. If there is one or more parameter sets, after buttoning “exit”, the command line will...

  • Page 88: Network Parameter Setting Command Set

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 The parameter is the name of any command in this directory, it is optional. For instance, enter “help ring”：codec_ep1> help ring in codec layer. Function: Set ring on time and off time.
  • Page 89 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Setting of the physical port for connection # network/conn connection1> set phyport {parameter} Parameter is the physical port. There are two physical ports on the device, one is FEO, the other is FE1. So parameter’s value is fec0 or fec1.
  • Page 90 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 configuration of connection effect taking # network/conn connection1> exit effect The configuration of connection will take effect once this command is carried out. DNS setting command network> dns {parameter1} {parameter2} Parameter 1 is the IP of DNS1; and parameter 2 is the IP of DNS2.

  • Page 91: Protocol-Related Parameter Setting Command Set

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Buttoning “Ctrl ＋ C” during setting can give up setting. Exit command network> exit [parameter] Help command network> help [parameter] 6.2.3 Protocol-related Parameter Setting Command Set It will immediately go into the protocol-related parameter setting content once input “protocol”...
  • Page 92 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 protocol_ep1> mg {parameter1} [parameter2] Parameter 1 is the MG domain name, and parameter 2 is the MG port number (optional). The max domain name bit is 255, and port number ranges from 0～65535.
  • Page 93 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 buttoning of the enter key by users will keep the original set value, and buttoning “Ctrl ＋ C” can cancel the settings. For instance: protocol_ep1> ephterm Ephterm Prefixion [RTP/]: Start NO. [0]:...

  • Page 94: System Parameter Settings And System Tool Command Set

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Non-interaction setting mode protocol_ep1>mgcmode {parameter} Only numbers chosen from 0～3 can be input, which stands for the three MGC platforms under interaction mode. Command to set H.248 command delay protocol_ep1> cmddelay {parameter} The parameter is the time value of command delay, and unit is ms.
  • Page 95 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Command Set You are able to enter system parameter settings and system tool contents once input “system” command in the root command layer, see below: ＃system System user configuration command The user groups of the system cover Admin, DataUser, VoiceUser and Guest. Each group has the default users, they are Admin, DataUser, VoiceUser and Guest respectively.
  • Page 96 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 The parameter is the username that will be deleted. All system users displaying #system>user list This command has no need of any parameter. All information, including username and user group, will be displayed after the command is performed..
  • Page 97 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Parameter 3 is the name of server port document, for example: system> download config 192.168.1.3 cfg-pf2 system> download program 192.168.1.3 prog Upload command system> upload {parameter1} {parameter2} {parameter3} Usage is similar with download command.
  • Page 98 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Start endpoint (1~24): 1 Number of endpoints (1~24): 1 POTS1 Status Act: Port: Reg: Hook: HOOK_ON Conn: IDLE Sig: IDLE Among them, “Start endpoint” is the operating start endpoint number, beginning with 1; and “Number of endpoint” refers to the quantity of the operating endpoints, it is at least 1, but is not allowed to exceed the practical endpoint number.
  • Page 99 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 system> protocol h248 Progress information display command system> ps This parameter has no need of any parameter. It is transplanted into ps command of busybox and used to display related information of current each progress of the system.
  • Page 100 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 system> save or system> save as {parameter} The parameter only can be “pf0”, pf1”or “pf2”. “save as pf0” means there is no any parameter for this command. The command is used to save the configured values of the all current parameters into the different parts of Flash.

  • Page 101: Cli Cancellation Command

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 Command to display software and hardware version numbers system> version It has no need of any parameter. After the command is performed, CLI will display the following information: Hardware Version: … …...

  • Page 102: Parameter Display Command

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 6.2.7 Parameter Display Command ＃show {parameter} The parameter can only be “codec”, protocol”, net”, private” or “epstatus”. Of them, “codec” refers to the compressed chip; “protocol” refers to the protocol; “net” refers to network; and “private” means the private protocol. If the configured parameter value differs from the value being used, CLI will display all values which are being used together, and with “*”...

  • Page 103: Parameter Effect-Taking Command

    Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 6.2.8 Parameter Effect-taking Command ＃ take-effect The command does not need any parameter. It is adopted to force the current all configured values to take effect. 6.2.9 SNMP-related Parameter Setting Command Set Command to enable or disable snmp setting #manage/snmp>...
  • Page 104 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 deleted community. Command to display all community information #manage/snmp> community list This command displays all community information in the system, including name of community, right, and the IP designated to be visited.
  • Page 105 Telpo TP-8S8O/TP-16S16O Voice Gateway User Manual Version: V1.2 #manage/snmp> show all Once the command is carried out, all of snmp configured information will be shown. - 105 -...
