WizCom Technologies Quicktionary-Multi Operation Manual page 15

3. Activate the right cursor by
pressing
4. Move the right cursor to right of
end of the expression, using
.
28
5. Press ; the translation appears.
TIPS
Protect Quicktionary from direct
sunlight, heat, dampness and dust.
Do not drop or knock the device and
always keep it in its plastic case to
avoid scratches.
Clean Quicktionary with a soft, dry
cloth. Never use a wet cloth or
solvents such as benzene or diluting
agents.
If you are in direct sunlight and the
"Ready to Scan" message does not
appear, or "Excessive Lighting"
appears, restart Quicktionary in a
shaded place.
If the text on the display appears
upside down, adjust Quicktionary to
right-handed or left-handed use.
If the words you want to scan are in
a format too large to scan, or the text
is printed unclearly, use the Opticard.
or .
or
TECHNICAL DATA
Methods of input
Scanning printed matter
Using Opticard keys
Using Quicktionary keys
Display Characteristics
Graphic screen 122 x 32 pixels
20 characters per line
3 lines
Scanner resolution
300 DPI
Size and type of letters capable of
scanning
8-14 points
Omnifonts
Bold, italics, underline
Black, blue or gray characters on white,
yellow or red background
White, yellow or red characters on black,
blue or gray background
Maximum length of scan
2" / 5cm
32 characters
Maximum scanning speed
1.6" / 40mm per second
Translation speed
2-5 seconds
Auto shut-off options
Adjustable from 15 - 240 seconds
Power supply
3 AAA alkaline batteries
Battery lifetime
Approx. 3,000 scans
