SoClean 2 User Manual

SoClean 2 User Manual

Automated pap disinfecting system
Hide thumbs Also See for 2:

Advertisement

User Manual

SoClean 2 Automated PAP Disinfecting System
SoClean.com
SC1701_V7-Manual_USA_0220.indd 1
2/22/19 12:45 PM

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2 and is the answer not in the manual?

Questions and answers

Neil Harvey
March 10, 2025

How do I change out the pick-up hose from my SoClean 2 adaptor to the tank in My Respironics Dreamstation C-Pap machine

1 comments:
Mr. Anderson
March 10, 2025

To change the pick-up hose from the SoClean 2 adapter to the tank of the Respironics DreamStation CPAP machine, follow these steps:

1. Detach the Injection Fitting and Short Hose – Remove these parts from the main SoClean hose. They will no longer be used, but keep them for future use if needed.

2. Open the Reservoir Lid – Access the water chamber of your DreamStation CPAP machine.

3. Insert the Injection Hose – Feed the injection hose from the SoClean 2 adapter down into the reservoir through the designated port.

4. Close the Reservoir Lid – Ensure that the injection hose remains inside and the lid is securely closed.

5. Attach the Adapter – Secure the SoClean 2 adapter to the reservoir. Do not detach the injection hose from the adapter.

6. Connect the Main Hose – Attach the main SoClean hose to the stem on the side of the adapter.

This setup ensures proper integration between the SoClean 2 and the DreamStation CPAP machine for sanitization.

This answer is automatically generated

Summary of Contents for SoClean 2

  • Page 1: User Manual

    User Manual SoClean 2 Automated PAP Disinfecting System SoClean.com SC1701_V7-Manual_USA_0220.indd 1 2/22/19 12:45 PM...
  • Page 2 Thank You! Thank you for purchasing the SoClean 2 While the SoClean is designed to fit many PAP models, some models require additional parts or set-up steps. PAP disinfecting system. If you do not currently have these parts, they can be purchased from SoClean or an authorized reseller.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INDICATIONS FOR USE, CONTRAINDICATIONS, SPECIFICATIONS, WARNINGS & CAUTIONS YOUR HEALTH & OZONE SAFETY CLASSIFICATION, MANUFACTURER SYMBOLS & FCC NOTICE INCLUDED WITH YOUR SOCLEAN 2 SOCLEAN CONTROL PANEL KEY PAP PARTS CONNECTION STEPS SUPPORTED PAP MACHINES & ADAPTERS SET LANGUAGE, CLOCK &...
  • Page 4: Indications For Use, Contraindications, Specifications, Warnings & Cautions

    Data on file. † * DISCLAIMER: SoClean does not represent through the use of the term disinfect, disinfectant or disinfection herein, or in other documentation, a kill rate of more than 99.9% of germs and bacteria in PAP equipment. 2 | INDICATIONS FOR USE, CONTRAINDICATIONS, SPECIFICATIONS, WARNINGS & CAUTIONS SC1701_V7-Manual_USA_0220.indd 2...
  • Page 5 Clock time and Cycle Start time are set on your Switch slot. SoClean 2 before using your PAP machine. Failure to do so may result in the SoClean 2 device operating at CAUTION: The Lid Gasket is removable. Ensure that an unexpected time.
  • Page 6: Your Health & Ozone Safety

    WARNING: If a strong ozone odor is detected when the SoClean is operating turn the SoClean 2 off by disconnecting the AC power adapter and inspect the SoClean 2 for visible damage, such as cracks in the enclosure or tubing along with tubing connections.
  • Page 7: Classification, Manufacturer Symbols & Fcc Notice

    EC/EU MDD Class IIa per 93/42/EEC Annex IX Rule 15 - Device is intended to disinfect medical devices. Designed by and Manufactured for: SoClean, Inc., 12 Vose Farm Road, Peterborough, New Hampshire 03458 USA Produced by: JDI Electronics Factory, China Symbols Waste Electrical &...
  • Page 8: Included With Your Soclean 2

    INCLUDED WITH YOUR SOCLEAN Number Part Name Description This allows you to set up the SoClean 2 device on either the right or Removable PN1214 left side of your PAP machine. Place this plug in the hose slot that Hose Slot Plug you don’t use.
  • Page 9 ENG | 7 SC1701_V7-Manual_USA_0220.indd 7 2/22/19 12:46 PM...
  • Page 10: Replacement Parts

    Cartridge Filter Kit. SoClean has discovered counterfeit Cartridge Filter Kits being sold, particularly on Amazon and eBay , with check valves and filters, that leak and can cause damage to your SoClean machine or to your property due to water leakage from the ® ®...
  • Page 11 ENG | 9 SC1701_V7-Manual_USA_0220.indd 9 2/22/19 12:46 PM...
  • Page 12: Soclean Control Panel

    SOCLEAN CONTROL PANEL WARNING: In the event of loss of power to your home or the SoClean 2, ensure the correct Clock time and Cycle Start time are set on your SoClean 2 before using your PAP machine. Failure to do so may result in the SoClean 2 operating at an unexpected time.
  • Page 13 Sets daily disinfecting start time. See page 20. Changes clock to 24-hour or 12-hour format. See page 19. Messages The SoClean display panel shows messages that can require action. This list shows the messages and how to correct them: Message What to Do Ensure that the PAP hose is seated securely in the hose slot.
  • Page 14: Key Pap Parts

    KEY PAP PARTS The SoClean device is designed to connect permanently to SoClean.com for additional instructions for specific your PAP machine and allow operation of either product. PAP machines. The SoClean device connects to most PAP machines These are typical parts of a PAP machine that are referenced using the standard included parts.
  • Page 15 PAP Machine Reservoir* Open Humidifier Humidifier Heat Plate * Reservoir contains water and typically can be removed. Mask Hose PAP Hose Mask (Full, small, nasal pillows) ENG | 13 SC1701_V7-Manual_USA_0220.indd 13 2/22/19 12:46 PM...
  • Page 16: Connection Steps

    CONNECTION STEPS After following these steps, your SoClean 2 will disinfect your PAP machine daily without disconnecting. Before you disconnect your PAP machine to wash the parts, look at where the PAP hose is connected. You will reconnect the SoClean Injection Fitting to the same location.
  • Page 17 (where your PAP hose was connected), allowing the smaller Injection Hose B to enter into the reservoir (figure 2). The end of the tubing should be positioned over the heat plate. If necessary, carefully trim the Injection Hose B in increments until it is the correct length, and over the heat plate.
  • Page 18 3. Reconnect your PAP hose to the end of the Injection Fitting. CAUTION: Please be sure the black Injection Hose from the back of the SoClean 2 is connected to your PAP before PAP Hose operating your SoClean 2. (goes to mask) Note: If you are having difficulty connecting to your PAP, an additional part may be necessary.
  • Page 19: Supported Pap Machines & Adapters

    SoClean.com or contact your authorized reseller. SoClean, is an independent company not affiliated with Aeiomed, Apex Medical, Carefusion, Fisher & Paykel, Philips Respironics, PMI Probasic, Puritan Bennett, RESmart, ResMed, or Transcend. Names and associated trademarks are solely owned by the respective companies and manufacturers. Depictions of brand logos on our website are for informational and educational purposes only and are used for customer equipment recognition.
  • Page 20: 18 | Set Language, Clock & Disinfecting Schedule

    SET LANGUAGE Language Time Format To choose correct language: Language 1. Press the buttons simultaneously. 2. Choose ‘Language’ by using the button. 3. With ‘Language’ selected, press the button Time Format 4. Scroll through language options by using the button.
  • Page 21 If you unplug the SoClean 2 or experience a power loss, you will need to reset the current time only. The disinfecting settings will remain saved. For safe use, operate your SoClean 2 only as instructed in this guide.
  • Page 22 Daily Disinfecting (in minutes) These two processes follow each other in this setup. 1. Press the button. 2. Press the button to decrease or increase the number of minutes of your cycle time. Set Run Time (in minutes) Note: The default run time of 7 minutes should be sufficient to disinfect your PAP equipment.
  • Page 23 PAP equipment is stored in the Disinfecting Chamber. Ensure that your PAP equipment is in place and the SoClean lid is closed. 1. Press the button to begin the disinfecting cycle. The disinfecting cycle starts immediately and runs for the set cycle time.
  • Page 24: Using Your Soclean 2

    Switches regularly for damage or inability to move up/down. that the ozone performs its disinfection function and Failure of the Hose Detect Switch on your SoClean 2 may dissipates appropriately. After that period, the status light result in the SoClean operating at an unexpected time.
  • Page 25 Chamber helps prevent accidental loss of the Removable Slot Plug. Ozone is a gaseous disinfectant that naturally breaks down after it is generated. The SoClean is designed to safely contain ozone within the system and has a catalyst Cartridge Filter inside the Disinfecting Chamber to convert ozone back to oxygen.
  • Page 26: Care & Maintenance Of Your Soclean

    Your PAP equipment will have a light, clean scent. damaged or if cracks in the tubing or enclosure 4. What if the scent the SoClean 2 leaves is too strong are noticed, stop using the SoClean and contact for me? Wash your equipment with the Neutralizing Customer Service.
  • Page 27 13. If I lose power, do I need to reset my SoClean? but still wish to disinfect my equipment? You can In the event of loss of power to your home or the SoClean use the Manual function to run a cycle. (See page 21).
  • Page 28 For more information about SoClean 2 or our other innovative products, please visit: SoClean.com Copyright © 2011-2019 SoClean is a registered trademark of SoClean, Inc. ® 12 Vose Farm Road, Peterborough, NH U.S.A. 03458 Patent: SoClean.com/patents Revision V07 866-501-3705 SC1701_V7-USA 0219 SC1701_V7-Manual_USA_0220.indd 26...
