12-23A-00
SERVICE DATA
(Serial number : 36000001 and after)
INTRODUCTION
We are constantly working on technical im-
provement of our products. For this reason,
technical data, equipment and design are
subject to change without notice. All speci-
fications and directions in this SERVICE
DATA are based on the latest products infor-
mation available at the time of publication.
HC-331ES, HC-341ES

HEDGE TRIMMER

HC-331ES
HC-341ES
CONTENTS
1 SERVICE INFORMATION .............................. 2
1-1 Specifi cation ............................................... 2
1-2 Technical data ............................................. 3
1-3 Torque limits................................................ 4
1-4 Special repairing materials ......................... 4
1-5 Service limits............................................... 5
1-6 Special tools ............................................... 6
2-1 General adjusting rules ............................... 7
2-3 Adjusting carburettor................................... 8
Reference No.
I S S U E D :
1
1
page
12-23A-00
2 0 0 8 0 4
