- Page 1 MX250 Enterprise Media Exchange Hardware Manual Manual Part Number 90-18300 Zultys Technologies 771 Vaqueros Avenue Sunnyvale, CA 94085 tel: +1-408-328-0450 fax: +1-408-328-0451 http://www.zultys.com...
-
Page 2: Revision History
This document contains proprietary information which is protected by copyright. The contents of this manual and the associated software are the property of Zultys Technologies, and all rights are reserved. No part of this document may be photocopied, reproduced, stored in any computer format, translated to another language, or publicly displayed without the prior written consent of Zultys Technologies. -
Page 3: Table Of Contents
Mounting the MX250 ........ - Page 4 Configuring the MX250 ........
-
Page 5: Introduction
Scope 1.1.1 Audience This manual is intended for properly trained service personnel and technicians who need to install an MX250 system. The manual assumes you are familiar with electronic circuitry and wiring practices. 1.1.2 Installation and Use Unpack the product and verify the items as described in chapter 2, starting on page 7. -
Page 6: Product Function
1.1.4 What this Manual Does Not Include This manual does not describe the features and functionality of the MX250, nor does it describe how you should provision or use these products. The manual does not discuss technology details, pricing, names of sales representatives, or names of distribution channels. -
Page 7: Documentation Overview
1. Introduction 1.2.2 Protocols Figure 1-2 shows the supported protocols on the MX250. Interface Supported Protocols T1 (1.544 Mb/s) voice loop start, ground start, E&M wink start, E&M immediate start, ISDN PRA (Nortel, Lucent, National, Japanese ISDN) E1 (2.048 Mb/s) voice ETSI ISDN PRA, ETSI ISDN with overlap receiving T1 (1.544 Mb/s) data... -
Page 8: Forms Of Documentation
The printed version of this manual is updated as required. 1.4.2 This manual is available in PDF format. You can download the PDF file from the MX250 web site http://www.zultys.com You can obtain old versions of the manual that may describe the hardware that you have, the manual that was used to produce the most recently printed manual, or the latest manual that describes all the latest features of the product. -
Page 9: Related Documents
Using the administration software for configuration and maintenance of the MX250 MXIE User’s Manual Complete manual on the configuration and use of the client software for the MX250 MXIE User’s Guide Quick reference on the use of the client software for the MX250 Voice Mail User’s Manual... - Page 10 MX250 Hardware Manual...
-
Page 11: Receiving The Equipment
MX250. Caution Do not drop or jolt the MX250. The hard disc inside the MX250 is designed for continuous operation, but is fragile until installed. If you allow the MX250 to receive a hard knock, you can cause irreversible damage to the hard disc. -
Page 12: In Case Of Damage Or Malfunction
• there is a discrepancy between the packing slip and the equipment received • the equipment does not function correctly Your supplier will arrange for repair or replacement, at Zultys’ discretion. In certain cases, Zultys may require a claim settlement. -
Page 13: Returning Items For Repair Or Replacement
If it is inconvenient to obtain supplies from Zultys, use a strong, double-walled shipping carton. Place about 70 mm (3 in) of cushioning material around all sides of the equipment. Zultys is not responsible for any damage that occurs during shipment back to your supplier or to the factory. - Page 14 The method of shipment which Zultys will return repaired merchandise back to your facility will be the same method by which you shipped the merchandise to Zultys. For example, if you shipped merchandise to Zultys by ground shipment, Zultys will return the merchandise to you by ground shipment.
-
Page 15: Hardware
This chapter describes the MX250 hardware along with the telecommunications and data communications interfaces. Front Side of MX250 The front panel side of the MX250, as is shown in figure 3-1, has no wiring connectors. Chapter 7, starting on page 37, describes the LED indicators. Figure 3-1... -
Page 16: Rear Side Of Mx250
Reset button – When power to the MX250 is off, pressing this button will turn on the unit. When power is on, pressing this button for one second initiates a system shut down. IP address – An area to enter the configured IP address assigned to the MX250 with a label or permanent marker. -
Page 17: Mx250 Circuits
See section 4.3 on page 23. 14. Hard Discs – Two slots which hold the SCSI hard disc drives. The MX250 requires one to operate. The other serves as a redundant hard disk drive that is mirrored with the first one in a RAID1 configuration. - Page 18 3.4.2.1 Usage The MX250 supports up to three analog FXO or FXS cards through the interface slots. Each analog card provides eight analog circuits. FXO circuits support Loop Start and Ground Start protocols; FXS circuits support Loop Start. Analog circuit protocols are configured through the MX Administrator software.
- Page 19 The FXO and FXS interface boards have a 50-pin telco receptacle (female) for connecting analog circuits to the MX250. Figure 3-6 shows the pin placement on the telco connector of the FXS and FXO cards. Figure 3-7 shows the function assignment of each pin.
- Page 20 Figure 3-10 displays the connection of PCM circuits to the network or other equipment. Use a straight cable to connect the MX250 to the network jack. Use a crossover cable to connect the MX250 to an existing terminal system (such as an existing PBX). Figure 3-10 also displays MX250 pinouts and pinouts typically used for terminal and network equipment.
- Page 21 ISDN BRA (S/T Interface) 3.4.4.1 Usage The MX250 supports up to three BRA cards through the interface slots. Each card has four S/T circuits. The protocol for each circuit is configured through the MX Administrator software. 3.4.4.2 BRA RJ45 Pin Assignments Each ISDN BRA circuit terminates on an RJ45 connector.
-
Page 22: Console Mode
When the MX250 is in console mode, you can connect a computer to the Second Ethernet Port (item 8 in figure 3-2 on page 12). The IP address used to access the MX250 depends whether the MX250 was placed in console mode during normal operation or during power up. - Page 23 Once the MX250 is in console mode, you can access it at the assigned IP address. To exit the console mode press and hold the console button for two seconds. The MX250 exits the console mode and restores the status of the LEDs.
- Page 24 MX250 Hardware Manual...
-
Page 25: Preparation
• types of cables for the voice and data circuits The MX250 is designed to be permanently installed within a network room in a 19" equipment rack. You must carefully install the MX250 system to ensure its proper operation. Warning The MX250 is designed to be installed by qualified personnel only. - Page 26 You will also void your warranty. 4.2.3 Ventilation The MX250 requires space on both sides for ample air flow. The internal fans move the air from left to right as you look at the front of the equipment. Important Do not cover the slots and openings on the equipment.
-
Page 27: Power Requirements
The total ac power input on the MX250 is 100 W, which includes power for ringing and battery feed to analog telephones and fax machines. The MX250 has a universal ac input that you can connect to a standard electric outlet (100 Vac to 240 Vac, 47 Hz to 63 Hz). -
Page 28: Electrostatic Discharge (Esd) Precautions
MX250 Hardware Manual The MX250 monitors the battery voltage, which allows the system to provide an alert or shut down the system when battery voltage declines below a specified value. The MX250 has no provision for monitoring the voltage of the component batteries of an external UPS. -
Page 29: Mounting The Mx250
Devices typically connected to the MX250 include the firewall, the LAN switch, the battery power system, and the provisioning computer. All connections to the MX250 system are made at the rear panel. Leave space next to the rear panel for cables and for personnel installing the system. -
Page 30: Installing Brackets For Cable Management
Cable management on the MX250, requires the installation of the plastic brackets on the rear side of the chassis. The plastic brackets cannot be installed on the front side of the MX250 chassis. Follow these instructions for proper installation of the plastic brackets for cable management: From the right side of the rear face, remove the M4 screw from position A in figure 5-2. -
Page 31: Installing Mounting Brackets On Chassis
Installing Mounting Brackets on Chassis The MX250 main chassis is supplied with two mounting brackets that you must fasten onto the chassis prior to installing it into a 19" equipment rack. The system can be mounted into one of the four following positions: •... - Page 32 MX250 Hardware Manual Figure 5-5 Mounting Brackets in the Middle of Front Side of Chassis Figure 5-6 Mounting Brackets in Middle of Rear Side of Chassis Remove the M4 screw from position A (front side installation) or position C (middle of the front side or middle of the rear side installation).
-
Page 33: Installing The Chassis Into The Equipment Rack
Once mounted in position with the screws in place, use a power screwdriver to tighten all four screws. 1. The MX250 is supplied with four 12-24 mounting (imperial) screws and M6x10 mounting (metric) screws for conven- tional 19” equipment racks. Use either the 12-24 mounting screws or the M6x10 mounting screws, depending on the... - Page 34 MX250 Hardware Manual...
-
Page 35: Connecting, Wiring, And Configuring
Before installing the MX250 chassis into the network rack, you must install two AAA batteries into the fan tray to power the real time clock on the MX250. The position for these batteries is on the fan tray shown in figure 6-1. To install the batteries:... -
Page 36: Setting The Ip Addresses
Ensure power to the MX250 is turned off. Press and hold the Console button. Turn power on the MX250 by using the ac cord to connect the ac input port to the wall outlet. Keep the Console button held for about 60 seconds. -
Page 37: Connecting The Mx250 To The Networks
UI will display panel stating that a reboot is required to save IP address changes. Press Reboot button to apply changes and restart system. User Interface will lose connection with the MX250 as it shuts down and then restarts. When system restarts, it will not be in console mode. - Page 38 Wiring options for FXO on MX250 Connect data lines to the IP WAN. • Connect the MX250 to T1 or E1 circuits through the RJ45 ports on the PCM card. Configure circuit type and protocol for each circuit using the MX Administrator software.
-
Page 39: Configuring The Mx250
être située ou installée à proximité du matériel et être facile d’accés. Danger The power cord provides the safety ground for the MX250. Keep this cord properly connected at all times, even if the equipment is not powered by the ac mains. - Page 40 MX250 Hardware Manual Enter the following values in the Login panel: • Login: Administrator • Password: zultys • URL: Enter the configured IP address For details on configuring the MX250, see the MX Administration User’s Manual.
-
Page 41: Leds
This chapter describes how the various indications for each LED on the MX250. The three LEDs on the front have the same indication as the three LEDs on the rear of the MX250. All LEDs are controlled by the same PCB. -
Page 42: Operational System
MX Clusters is a software option that allows you to connect multiple MX250 systems to operate as a single MX unit. Each MX250 system that is a member of an MX cluster is referred to as a node. An MX system that is a component of a cluster is configured as one of three types of cluster nodes: master, member, or standby. - Page 43 Standby System LEDs In normal mode: • The Load LED of the standby MX250 system flashes green (250 ms) and off (250 ms) when the standby is fully operational. • The Load LED is off when the MX system is initializing. During this time, the hard drive of the standby node is copying the contents of the master node.
-
Page 44: System Shut Down
MX250 Hardware Manual System Shut Down You can initiate a shutdown of the MX250 from the Administrative UI as described in the MX Administrators Manual. On the MX250 you can also shut down the system with the power button. When you shut down the MX250, all applications are gracefully shutdown and Linux is terminated properly. -
Page 45: Maintenance And Use
Usage Warning Do not use the MX250 to report a gas leak when in the vicinity of the gas leak. Servicing To ensure the operation of the real time clock when the system is off, you should replace the AAA batteries in the fan tray at least once per year. - Page 46 MX250 Hardware Manual...
-
Page 47: Appendix A Acronyms
A p p e n d i x A Acronyms Ampere alternating current ANSI American National Standards Institute B8ZS bipolar with 8 zeroes substitution bits per second Basic Rate Access to ISDN channel associated signaling CCITT International Telegraph and Telephone Consultative Committee common channel signalling central office customer premises equipment... - Page 48 MX250 Hardware Manual fractional E1 fractional T1 foreign exchange office (analog subscriber side interface) foreign exchange subscriber (analog exchange side interface) ground hour(s) HDLC high level datalink control HDB3 high density bipolar 3 zero substitution Hertz International electrotechnical commission IEEE...
- Page 49 Mb/s million bits per second multi frequency MFR1 multi frequency R1 mega-Hertz millimeter milli-second most significant bit milli-Watt media exchange (MX250) not applicable NCTE network circuit-terminating equipment NEBS network equipment building system nanosecond network termination network terminal equipment NVRAM non-volatile random access memory...
- Page 50 MX250 Hardware Manual real time clock rack unit (1.75 in, 44.45 mm) receive receive data (or received data) second system controller superframe format for T1, comprising 12 frames in a superframe (D4) spanning tree protocol SRAM static random access memory T-carrier for digital signal level 1 (1.544 Mb/s)
-
Page 51: Appendix B Glossary
A p p e n d i x B Glossary 10/100Base-T. A physical media that can operate as 10Base-T or 100Base-T. 10Base-T. A physical media specified by the IEEE 802.3 standard for supporting Ethernet with a maximum transmission rate of 10 Mb/s. 10BaseT consists of copper twisted-pair cable normally used for wiring ordinary telephones. - Page 52 Jitter. Jitter is the deviation in some aspect of the pulses in a high-frequency digital signal or the period frequency displacement of the signal from its ideal location. The MX250 utilizes Jitter Buffers to compensate for jitter.
- Page 53 Local Area Network (LAN). A group of computers and associated devices that share a common communications line and the resources of a single processor or server within a limited geographic area, such as an office building. 10BaseT Ethernet is the most commonly used form of LAN. A hardware device called a hub serves as the common wiring point, enabling data to be sent from one machine to another over the network.
- Page 54 MX250 Hardware Manual Repeater. A device that receives a digital signal on a transmission medium and regenerates the signal for the next leg of the medium. Repeaters overcome attenuation losses caused by free-space electromagnetic-field divergence or cable loss over electromagnetic media. A series of repeaters facilitates the extension of a signal over long distances.
- Page 55 System Controller (SC). One of the boards inside the MX20. It is connected to a hard disc that stores all of the application software for the MX250 and upon power on, forwards the software to the other boards in the system. This board also has the console port directly connected to it so that you can always communicate with the system.
- Page 56 Also referred to as a location or address, URLs specify the location of files on servers. A general URL has the syntax protocol://address. For example, http://www.zultys.org/index.html specifies that the protocol is http and the address is www.zultys.org/ index.html. Unshielded Twisted Pair (UTP). Also known as 10BaseT. This is the standard cabling used for telephone lines.
-
Page 57: Appendix C Regulatory And Safety Compliance
A p p e n d i x C Regulatory and Safety Compliance Usage The MX250 complies with the following agency approvals and standards. The MX250 is therefore approved for business use and connection to the PSTN in the following countries: •... -
Page 58: Electromagnetic Compatibility (Emc) Immunity
MX250 Hardware Manual • AS/NZS 3548/CISPR 22/EN 55022 Emission Class A • EN61000-3-2 Harmonics current to public supply system • EN61000-3-3 Voltage fluctuations to public low-voltage system • EN55022 Class A Electromagnetic Compatibility (EMC) Immunity • IEC61000-4-2 ESD • IEC61000-4-3 Radiated RF electromagnetic field immunity •... - Page 59 If trouble is experienced with this equipment, please contact Zultys for repair and warranty information. If the trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the problem is resolved.
- Page 60 MX250 Hardware Manual...
-
Page 61: Index
..... 5 returning to Zultys ... . 9 special paragraph styles ..4 subscribers . - Page 62 ..... . . 22 WAN connection ....34 warning, definition in manual ..4 58 MX250 Hardware Manual...
