KEYBOARDPARTNER HX3 Drawbar Controller User Manual page 7

MIDI Implementation for Nord C2
HX3 Drawbar Controller sends MIDI CC data separately for MIDI channel 1 (or base
channel selected) for upper manual, channel 2 (or base channel + 1) for lower
manual and 3 (or base channel + 2) for bass pedals in Nord C2 mode.
Channel CC#
1 82
1 16..24
2 16..24
2 85
1 85
3 16
3 17
1 87
1 28
1 27
1 95
1 74
1 64
1 111
1 78
1 79
1 102
Type Function
Switch Rotary Slow/Fast
Slider Upper Drawbars
Slider Lower Drawbars
Switch Vibr Lower ON
Switch Vibr Upper ON
Slider Bass DB 16
Slider Bass DB 8
Switch Percussion ON
Switch Percussion SOFT
Switch Percussion FAST
Switch Percussion THIRD
Fixed Vibrato Knob
Slider Bass Pedal Sustain
Slider Amp 122 Volume
Slider Swell Trim Cap
Slider Tone
Fixed Reverb
Remarks
127 = FAST, 0 = SLOW, 64 = STOP
0 = SOFT, 127 = NORMAL
0 = SLOW, 127 = FAST
0 = 2nd, 127 = 3rd
0, 26, 51, 77, 102, 127 for V1..C3
"Overdrive" on Nord C2
"Equ Mid" on Nord C2
"Equ High" on Nord C2
0 = OFF, 40 = Rev 1, 80 = Rev 2, 120 = Rev 3
