KEYBOARDPARTNER HX3 Drawbar Controller User Manual page 6

MIDI Implementation for HX3 and NI B4
HX3 Drawbar Controller sends MIDI CC data always on MIDI channel 1 resp. base
channel for upper manual.
Channel CC#
1 1
1 7
1 11
1 12..20
1 21..29
1 30
1 31
1 33
1 34
1 66
1 68
1 70
1 71
1 72
1 73
1 74
1 75
1 76
1 78
1 79
1 84
2 12..20
2 30, 31
Type Function
Switch Rotary Slow/Fast
Slider Master Volume
Slider Swell Pedal
Slider Upper Drawbars
Slider Lower Drawbars
Switch Vibr Lower ON
Switch Vibr Upper ON
Slider Bass DB 16
Slider Bass DB 8
Switch Percussion ON
Switch Rotary RUN
Switch Percussion SOFT
Switch Percussion FAST
Switch Percussion THIRD
Fixed Vibr Mix
Fixed Vibr Amount
Slider Bass Pedal Sustain
Slider Amp 122 Volume
Slider Swell Trim Cap
Slider Tone
Fixed Reverb
Slider Lower Drawbars
Switch Vibr Lower ON
Remarks
Modulation Wheel
"Rotary On/Off" on B4
inverted!
inverted!
Chorus if < 96
0..55 = V1, 56..87 = V2, 88..127 = V3
"Key Click" on B4
"Tube Amp Drive" on B4, same as CC #7
"Tube Amp Body" on B4
"Tube Amp Brightness" on B4
0..23 = OFF, 24..47 = Rev 1, 48..63 = Rev 2,
64..127 = Rev 3
Same as 21..29 on Channel 1
Same as 30 on Channel 1
