Summary of Contents for BK Precision 1823A
- Page 1 Instruction Manual Model 1823A 2.4 GHz Universal Frequency Counter...
- Page 2 Introduction Thank you for purchasing our product. Electronic measuring instruments produced by us are high technology products made under strict quality control. We guarantee their exceptional precision and utmost reliability. For proper use of the product, please read this operation manual carefully. Note 1.
-
Page 3: Table Of Contents
CONTENTS 1. PRODUCT DESCRIPTION 1-1. Introduction ------------------------------------------------------ ( 4 ) 1-2. Technical Specifications -------------------------------------- ( 5 ) 1-3. Equipment Ratings --------------------------------------------- ( 8 ) 1-4. Supplied Accessories ------------------------------------------ ( 8 ) 2. INSTALLATION 2-1. Initial Inspection ------------------------------------------------- ( 9 ) 2-2. -
Page 4: Product Description
1. PRODUCT DESCRIPTION 1-1. Introduction This reciprocal UNIVERSAL COUNTER series are microprocessor controlled instruments for frequency measurements at high resolutions within a short period of time. The high resolution is due to uniquely developed LSI as well as the expanding/reciprocal systems. It covers a frequency range from 0.1 Hz to 2.4 GHz based on 10 MHz time base T.C.O (temperature controlled oscillator) and also featuring, ... -
Page 5: Technical Specifications
1-2. Technical Specifications INPUT A CHARACTERISTICS • FREQUENCY RANGE : 0.1 Hz to 100 MHz (DC Coupled) 30 Hz to 100 MHz (AC Coupled) • SENSITIVITY : 0.1 Hz to 1 Hz: 250 mV 1 Hz to 100 MHz: 30 mV •... - Page 6 • MAX. INPUT VOLTAGE LEVEL 100M FREQUENCY (Hz) FIG 1. MAX. Input Level. (Input A,B) INPUT B. CHARACTERISTICS = Same as Input A TIME INTERVAL(A→B) • RANGE : 0.1 uSec-10 Sec(0.1 Hz-10 MHz) • LSD : 100 nSec •...
- Page 7 INPUT C. CHARACTERISTICS FREQUENCY RANGE: 80 MHz to 2.4 GHz SENSITIVITY: 25 mV from 80 MHz to 150 MHz 20 mV from 150 MHz to 2.0 GHz 60 mV from 2.0 GHz to 2.4 GHz • COUPLING : AC only •...
-
Page 8: Equipment Ratings
displayed. When Hold is released, a new measurement begins. • GATE TIME : Depending on input frequency < 10 mS------------Somewhere between 0.9 and 9 mS < 0.1 S--------------Somewhere between 9 and 90 mS < 1 S---------------- Somewhere between 90 and 900 mS <... -
Page 9: Installation
Power cord-----------------------------------------------------------------1 Spare Fuse-----------------------------------------------------------------1 2. INSTALLATION 2-1. Initial Inspection This instrument was carefully inspected both mechanically and electrically before shipment. It should be physically free of damage. To confirm this, the instrument should be inspected for physical damage in transit. Also, check for supplied accessories. -
Page 10: Operation
Allow more than 30 minutes for the unit to warm up so that it is stabilized and ready for use. 3. OPERATION 3-1. Controls, indicators and connectors FIG(2) FRONT PANEL GATE INDICATOR : The gate light, when lit, indicates the main gate is open and measurement in progress. - Page 11 the knob out and rotating it varies the level from negative to positive around the mid point. INPUT C, BNC : Input for frequency measurements above 80 MHz Female BNC connector terminated in 50 Ω. LOW PASS FILTER : With this switch pushed in, the input B is routed through a SWITCH(LPF) low-pass filter with -3 dB point of approximately 100 kHz.
- Page 12 e. TOTAL A. When this mode is selected, the unit counts cycles of the input A signal and continuously displays that count. f. T.l (A→B). When this mode is selected, the unit measures the time interval from an edge of the input A signal to an edge of the input B signal.
- Page 13 VOLTAGE FUSE POWER MAX 115V ~ 0.5A F 230V ~ 0.2A F S/N : Made in Korea FIG (3) REAR PANEL AC INLET: AC power input connector VOLTAGE SELECTOR: Selects the AC Power (115 V or 230 V) FUSE HOLDER: Replace fuse by unscrewing.
-
Page 14: Operating Instruction
RS-232C CONNECTOR : Connector for serial interfacing with a computer. 3-2. Operating Instruction Below is the basic operating information needed for frequency counter. a. Connect the unit to AC power cord into receptacle on rear panel and plug into AC inlet. b. -
Page 15: Period Measurements
DC coupling position. 3-3-2 INPUT C (80 MHz to 2.4 GHz) CAUTION THE MAXIMUM INPUT LIMIT TO THIS INPUT IS 3 Vrms MAXIMUM OVER THE INPUT FREQUENCY RANGE. THE X 10 ATTENUATOR DOES NOT APPLY. a. Apply the signal to be measured to the input C. BNC. b. -
Page 16: Time Interval Measurement(A-B)
3-6. Time Interval Measurements(A→B) In time interval mode, unit measures the elapsed time from a selected edge of the input A waveform to a selected edge of the input B waveform. For a stable reading, the two input signals should be related to each other such that this time interval remains reasonably constant from one measurement to the next. -
Page 17: Ratio Measurement (A/B)
Frequency Ratio Measurements (A/B) 3-7. In this mode of operation, the counter displays the ratio of the frequency applied to input A to the frequency applied to input B. The input A frequency should preferably be equal to or greater than that of input B. And both frequencies must be within the limits given in the "SPECIFICATIONS"... -
Page 18: Use Of Rs-232C Serial Interfacing
3-8. Use of RS-232C Serial Interfacing 1) Hardware/Software Requirements . IBM PC/XT/AT or compatible computer . Microsoft Windows . Serial port for connection with counter 2) Output Data Formats (1) Baud rate : 9600BPS 1 start bit (0) 8 data bit 1 stop bit (1) NONE PARITY (2) To Frequency counter... -
Page 19: Maintenance
4. MAINTENANCE CAUTION IT IS ESSENTIAL FOR SAFETY TO PROPERLY MAINTAIN AND SERVICE THIS INSTRUMENT WARNING VOLTAGES WITHIN THIS INSTRUMENT ARE SUFFICIENTLY HIGH TO ENDANGER LIFE. COVERS MUST NOT BE REMOVED EXCEPT BY PERSONS QUALIFIED AND AUTHORIZED TO DO SO AND THESE PERSONS SHOULD ALWAYS TAKE EXTREME CARE ONCE THE COVERS HAVE BEEN REMOVED. -
Page 20: Others
5. OTHERS 5-1. BNC Cable Considerations Accuracy of radio frequency measurements can be affected by connections between signal source and counter. Main considerations are standing waves and shunt cable capacitance. Standing wave is usually present due to reflections when a transmission line is not terminated in its characteristic impedance. -
Page 21: Line Frequency Measurements
5-3. Line Frequency Measurements Use of the attenuator, low pass filter, and/or x10 probe is advisable when measuring line frequency because the high amplitude signal and noise can cause wrong counting. WARNING USE CAUTION IN MEASURING THE LINE FREQUENCY OF AN AC OUTLET. USING THE PROBE TIP ONLY, MEASURE BOTH SIDES OF THE LINE. - Page 22 Limited One-Year Warranty B&K Precision Corp. warrants to the original purchaser that its product and the component parts thereof, will be free from defects in workmanship and materials for a period of one year from the data of purchase. B&K Precision Corp. will, without charge, repair or replace, at its’ option, defective product or component parts.
- Page 23 Model Number: ______________ Date Purchased:__________ Service Information Warranty Service: Please return the product in the original packaging with proof of purchase to the below address. Clearly state in writing the performance problem and return any leads, connectors and accessories that you are using with the device.
- Page 24 22820 Savi Ranch Parkway Yorba Linda, CA 92887 PN: 481-542-9-001 TEL: 714-921-9095 Printed in Korea 2004 B&K Precision Corp. FAX: 714-921-6422 V042111 www.bkprecision.com...
