Page 2: Table Of Contents
Contents Compliance Information EMC ................4 IEC Measurement Category &... - Page 3 Noise ................Signal Level .
-
Page 4: Compliance Information
Compliance Information 1.1 EMC EC Declaration of Conformity - EMC Complies with EN61010-1, EN60950-1 (Adapter/charger) & EN61326-1. For details, request the EU Declaration of Conformity for this instrument via bkprecision.com. EN 61010-1:2010 Safety requirements for electrical equipment for measurement, control, and laboratory use Part 1: General requirements EN 60950-1:2010 Information technology equipment - Safety Part 1: General requirements EN 61326-1:2010 Electrical equipment for measurement, control and laboratory use -... -
Page 5: Iec Measurement Category & Pollution Degree Definitions
Compliance Information 1.2 IEC Measurement Category & Pollution Degree Definitions Measurement Category (CAT) - classification of testing and measuring circuits according to the types of mains circuits to which they are intended to be connected. Measurement Category other than II, III, or IV : circuits that are not directly connected to the mains supply. -
Page 6: Product End-Of-Life Handling
Compliance Information 1.3 Product End-of-Life Handling The equipment may contain substances that could be harmful to the environment or human health if improperly handled at the product’s end of life. To avoid release of such substances into the environment and to reduce the use of natural resources, we encourage you to recycle this product to an appropriate system that will ensure that most of the materials are reused or recycled appropriately. - Page 7 Compliance Information Symbols - HIGH VOLTAGE - possibility of electric shock. WARNING – Statements or instructions that must be consulted in CAUTION order to find out the nature of the potential hazard and any actions which must be taken. On (Supply). This is the AC mains connect/disconnect switch on the front of the instrument.
-
Page 8: Electrical Power
Safety Notices The following safety precautions apply to both operating and maintenance personnel and must be followed during all phases of operation, service, and repair of this instrument. Before applying power to this instrument: • Read and understand the safety and operational information in this manual. •... - Page 9 Safety Notices Ground the Instrument To minimize shock hazard, the instrument chassis and cabinet must be connected to an electrical safety ground. This instrument is grounded through the ground conductor of the supplied, three- conductor AC line power cable. The power cable must be plugged into an approved three-conductor electrical outlet.
-
Page 10: Environmental Conditions
Safety Notices Environmental Conditions This instrument is intended to be used in an indoor pollution degree 2 environment. The operating temperature range is 0 C to 40 C and 20% to 80% relative humidity, with no condensation allowed. ∘ ∘ Measurements made by this instrument may be outside specifications if the instrument is used in non- office-type environments. - Page 11 Safety Notices Do not operate instrument if damaged If the instrument is damaged, appears to be damaged, or if any liquid, chemical, or other material gets on or inside the instrument, remove the instrument’s power cord, remove the instrument from service, label it as not to be operated, and return the instrument to B&K Precision for repair.
- Page 12 Safety Notices Do not touch live circuits Instrument covers must not be removed by operating personnel. Component replacement and internal adjustments must be made by qualified service-trained maintenance personnel who are aware of the hazards involved when the instrument’s covers and shields are removed.
- Page 13 Safety Notices Servicing Do not substitute parts that are not approved by B&K Precision or modify this instrument. Return the instrument to B&K Precision for service and repair to ensure that safety and performance features are maintained. Fuse replacement must be done by qualified service-trained maintenance personnel who are aware of the instrument’s fuse requirements and safe replacement procedures.
-
Page 14: Introduction
Introduction 3.1 Overview The 1820B series includes the 1823B and 1826B models, which are portable, battery-powered universal counters with a 10-digit, 0.5" LCD display. They cover frequencies from below 0.001 Hz to over 6 GHz (up to 3 GHz for the 1823B) and support measurements such as frequency, period, ratio, pulse width, and count. -
Page 15: Features
Introduction 3.2 Features • 3 GHz (1823B) and 6 GHz (1826B) models • Dedicated microwave channel with N-type connector (1826B only) • 10-digit display resolution with 0.5” LCD • ±1 ppm time base stability • Internal rechargeable batteries allow for up 24 hours of wireless operation •... -
Page 16: Package Contents
Introduction 3.3 Package Contents Please inspect the instrument mechanically and electrically upon receiving it. Unpack all items from the shipping carton, and check for any obvious signs of physical damage that may have occurred during transportation. Report any damage to the shipping agent immediately. Save the original packing carton for possible future reshipment. -
Page 17: Dimensions
Introduction 3.4 Dimensions The 8620B series dimensions are approximately. Model 1823B 1826B Dimensions 10.3 x 8.5 x 3.5 inches (260 x 215 x 89.6 mm) (W x H x D) Weight 2.1 lbs (950 g) plus 0.4 lbs (170 g) AC adapter Table 3.2 Dimensions and Weight Figure 3.2 1820B Dimensions... -
Page 18: Getting Started
Before connecting and powering up the instrument, please review the instructions in this chapter. 4.1 Input Power The 1820B series instruments can be powered by three sources: an internal rechargeable battery, DC input from the supplied AC adaptor, or USB power from a desktop or portable PC. The AC adaptor takes priority over USB or battery power;... -
Page 19: Ac Adaptor Operation
Getting Started removed. The Power key can be used to turn the instrument on or off while USB power is connected. USB power is available even without using the connection for remote control. 4.1.3 AC Adaptor Operation The AC adaptor connects to the rear panel socket labeled DC IN. When connected, the red EXT POWER LED lights up, indicating power, and the yellow CHARGING LED shows if the battery is charging. -
Page 20: Front Panel Operation
Front Panel Operation At power-on, the power supply will automatically enter the front-panel operation mode and the instrument can be controlled via the front panel keys and knob. Input ................5.1.1 Input A Configuration . -
Page 21: Input
Front Panel Operation 5.1 Input Inputs A, B, or C (1826B only) are selected by pressing the Select Input key, with an indicator showing the active input. 5.1.1 Input A Configuration Input A handles frequencies from 0.001Hz to over 125MHz and offers various configuration options for different waveforms and amplitudes. -
Page 22: Input B
Front Panel Operation 5.1.2 Input B Input B is for frequency measurements from 80MHz to over 3GHz with a nominal 50 impedance. The Ω maximum input voltage is 1Vrms, and the input is diode-clipped for signals over 250mVrms. It is protected against accidental connection to mains voltages up to 250Vrms at 50/60Hz. -
Page 23: Functions
Front Panel Operation 5.2 Functions Functions are selected using the keys located below the display, with annunciators indicating the current settings. Figure 5.1 Function Selection and Annunciator 5.2.1 Input A Function Selection Pressing the Frequency, Period, or Width key sets the instrument to the corresponding function. Holding the key for more than 1 second switches to the secondary function: Count, Ratio, or Duty, with the selected function indicated on the display. -
Page 24: Input B Function Selection
Front Panel Operation 5.2.2 Input B Function Selection With Input B (80MHz–3GHz) selected, only Frequency and Period functions are available. Attempts to select Width Count, or Duty will be ignored, indicated by a brief flash of the B annunciator. Selecting Ratio (by holding the Period key) activates Ratio B:A mode, which compares the frequency of Input B to Input A. -
Page 25: Measurement Fundamentals
Measurement Fundamentals 6.1 Frequency and Period Measurements The instrument uses **reciprocal counting** for measurements. After each gate time, it waits for the current input cycle to finish before capturing the count data. By measuring the total time for a whole number of cycles and dividing it by the number of cycles, it calculates the signal’s average period and derives the frequency. -
Page 26: Accuracy Considerations
Accuracy Considerations 7.1 Internal Oscillator The instrument features an internal temperature-compensated crystal oscillator (TCXO), calibrated to within ±0.2ppm at 21ºC using a Rubidium reference. At temperatures between 5ºC and 40ºC, the additional error is less than ±1ppm. The oscillator’s aging rate is under ±1ppm in the first year and decreases over time. -
Page 27: Specifications
Portable Bench Universal Frequency Counters 1820B Series Specifications Specifications Model 1823B 1826B Input specifications Input coupling AC or DC Input impedance 1 MΩ or 50 Ω Attenuation 1x or 5x Active edge Rising or falling, or width high or low... - Page 28 1820B Series Specifications (cont.) Specifications Model 1823B 1826B Measurement functions Measurement accuracy Measurement accuracy is timebase accuracy + measurement resolution + 2 counts. Input A range Frequency: 0.001 Hz (DC coupled) to 125 MHz; Period: 8 ns to 100 s (DC coupled)
-
Page 29: Service Information
Service Information Warranty Service: Please go to the support and service section on our website at bkprecision.com to obtain an RMA #. Return the product in the original packaging with proof of purchase to the address below. Clearly state on the RMA the performance problem and return any leads, probes, connectors and accessories that you are using with the device. -
Page 30: Limited Three-Year Warranty
LIMITED THREE-YEAR WARRANTY B&K Precision Corp. warrants to the original purchaser that its products and the component parts thereof, will be free from defects in workmanship and materials for a period of three years from date of purchase. B&K Precision Corp. will, without charge, repair or replace, at its option, defective product or component parts.
