- Page 1 Quick Start Bulletin 1609 UPS Ethernet Network Card 1609-ENET...
-
Page 2: Important User Information
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. -
Page 3: Overview /Additional Resources
• Support syslog for keeping the event log remotely • Support IPv4 and IPv6 • Support EtherNet/IP protocol Additional Resources These documents contain additional information concerning related products from Rockwell Automation. Resource Description Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1... - Page 4 Preface Notes: Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
-
Page 5: Table Of Contents
EtherNet/IP IO Data Mapping ........29 Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... - Page 6 Table of Contents Notes: Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
-
Page 7: Web Mode Setup
Review the 1609 Network Management Card installation instruction and user manuals. (1609-IN015A-EN-P and 1609- UM008A-EN-P) What You Need • Computer connected in the system • UPS Unit: 1609-D • UPS Ethernet card: 1609-ENET Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... -
Page 8: Chapter 1 Web Mode Setup
3. Insert the card in the UPS ENET card slot. Note: This 1609-ENET card is hot swappable 4. Connect the Ethernet cable to the bottom Ethernet port. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... - Page 9 UPS with a static IP address. 6. Launch your web browser. 7. Type the 1609-ENET IP address “192.168.1.100” in the address bar and press enter. 8. Type the username and password. “Username: admin / Password: password” Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
- Page 10 This section allows you to monitor information such as UPS Input, Output and Battery statuses. Note: The 1609 Network Management Card will logout the user automatically if there is not any data transmission through HTTP/HTTPS for more than 30 minutes. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
-
Page 11: Ethernet Mode Setup
Review the 1609 Network Management Card installation instruction and user manuals. (1609-IN015A-EN-P and 1609- UM008A-EN-P) What You Need • Computer connected in the system • UPS Unit: 1609 - D • UPS Ethernet card: 1609 - ENET • RSLinx Classic • RSLogix 5000 Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... -
Page 12: Chapter 2 Ethernet Mode Setup
3. Insert the card in the UPS ENET card slot. Note: This 1609-ENET card is hot swappable 4. Ensure you connect the Ethernet cable to the bottom Ethernet port. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... - Page 13 Command Prompt and enter ping 192.168.1.100. You should receive replies. Note: Make sure your computer is on the same network as the UPS with a static IP address. 6. Open RSLinx Classic and create an Ethernet driver. Go to the Communications toolbox and select Configure Drivers. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
- Page 14 Chapter 2 Ethernet Mode Setup 7. Select Ethernet devices from the drop down menu and select Add New. 8. Enter the respective IP addresses of your devices and select OK. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
-
Page 15: Program Setup
9. Ensure that you can see the 1609-ENET card. The device should appear as follows: Program Setup 1. In your RSLogix5000 program, add an "ETHERNET-MODULE" under the Ethernet Network Bridge in the IO Configuration tree. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... - Page 16 2. Make sure you have the correct parameters including the Comm Format and IP address (192.168.1.100). Select OK. Note: If you are online you'll be prompted with an "Online Module Creation" warning message; check the "Inhibit Module Connection" and select YES. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
- Page 17 Ethernet Mode Setup Chapter 2 3. Go to the Generic Ethernet module properties. 4. Go the Connection tab. Change the RPI to 1000ms, uncheck the "Inhibit Module" and select OK. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
- Page 18 Note: If you are online you'll be prompted with an "Uninhibiting Module Online" warning, select Yes. 5. After adding your module with the correct parameter, you should have an "IO Not Responding" and a yellow triangle in your module. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
- Page 19 7. Reset the card by pressing the black circle button on the card. Wait approximately 45 seconds until communications are established. You should have an "IO OK" and the yellow triangle in the module should be gone. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
- Page 20 Service Type Get Get Attribute Single CIP Service Class UPS Object Instance Instance 1 Attribute Attribute id 1 = 1 (hex) (Appendix B) Destination Name given to destination tag Path ENET_Card Name given to Device Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
- Page 21 Ethernet Mode Setup Chapter 2 Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
- Page 22 Chapter 2 Ethernet Mode Setup 4. Finalize all edits in the program. Go to the "Controller Tags", you should be able to see your results. Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
-
Page 23: Ethernet/Ip Object Service
One instance supported (0x01) Get_Attribute_All Attribute List: Get_Attribute_Single Details such as Parameters Table Physical Address UPS Object 0x377 Attributes Supported: Services Supported: One instance supported (0x01) Get_Attribute_Single Attribute List: Set_Attribute_Single Details such as Appendix B Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... -
Page 24: Appendix A Ethernet/Ip Object Service
Path processing shall stop when a path destination unknown Remove error is encountered. Instance 0x03 Invalid parameter See Status Code 0x20, which is the pred value to use for this value condition. Create/Delete Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... -
Page 25: Ethernet/Ip Parameters
Ethernet Link Object (0xF6) Attribute ID Rule Name Data Type Description of Attribute Interface Speed UDINT Interface speed currently in use Interface Flags DWORD Interface status flags Physical Address ARRAY of 6 USINTs MAC layer address Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... -
Page 26: Appendix B Ethernet/Ip Parameters
UPS wait a period of time to startup the system Required Get/Set ExternalBatteryPack Indicate the number of external battery pack Required InputNumLines The number of input lines utilized in this device Limited 1 Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... - Page 27 The ambient temperature at or near the UPS Required Battery Temperature °C Battery casing abort(0), generalTest(1), Required Get/Set TestType Perform the UPS Test procedure batteryTest(2), testFor10sec(3), testUntilBattlow(4) Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
- Page 28 Indicates whether the UPS output is turned off or OutputOff bit 14 Indicates whether the Smart Shutdown is in SmartShutdown bit 15 progress UPSShutdown bit 16 UPS shutdown Reserved bit 17-31 Reserved for future use and shall be set to zero Rockwell Automation Publication 1609-QS002A-EN-P - May 2014...
-
Page 29: Ethernet/Ip Io Data Mapping
Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Restart Bit ShutDown Bit SilenceAlarm Perform Test Procedure Shutdown Seconds (low byte) Shutdown Seconds (high Byte) Restart Seconds (low byte) Restart Seconds (high byte) Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... -
Page 30: Appendix C Ethernet/Ip Io Data Mapping
OutputLoad (high byte) OutputFrequency (low byte) OutputFrequency (high byte) BatteryVoltage (low byte) BatteryVoltage (high byte) BatteryCapacity (low byte) BatteryCapacity (high byte) BatteryEstimatedTime (low byte) BatteryEstimatedTime (high byte) BatteryTemperature (low byte) BatteryTemperature (high byte) Rockwell Automation Publication 1609-QS002A-EN-P - May 2014... -
Page 31: Rockwell Automation Support
New Product Satisfaction Return Rockwell Automation tests all of its products to help ensure that they are fully operational when shipped from the manufacturing facility. However, if your product is not functioning and needs to be returned, follow these procedures.
