Summary of Contents for Jet JSS-16A
- Page 1 JSS-16A SCROLL SAW Original: Operating Instructions Translations: Gebrauchsanleitung Mode d´emploi JPW (Tool) AG Tämperlistrasse 5 CH-8117 Fällanden Switzerland Phone +41 44 806 47 48 +41 44 806 47 58 www.jettools.com M-10000808MA 2015-11...
- Page 2 CE-Conformity Declaration Product: Scroll Saw JSS-16A Stock Number: 10000808MA Brand: JET Manufacturer: JPW (Tool) AG, Tämperlistrasse 5, CH-8117 Fällanden, Switzerland On our own responsibility we hereby declare that this product complies with the regulations * 2006/42/EC Machinery Directive * 2014/30/EU...
-
Page 3: Table Of Contents
Dear Customer, Many thanks for the confidence you have shown in us with the purchase of your new JET-machine. This manual has been prepared for the owner and operators of a JET JSS-16A scroll saw to promote safety during installation, operation and maintenance procedures. -
Page 4: Remaining Hazards
Never cut pieces that are too small. represent a risk to health. Blade stroke 15mm Dust form some tropical woods in Blade speed 550~1600 SPM During cutting operation the particular, and from hardwoods like Max cutting height at 90° 50mm workpiece must firmly be pressed beach and oak, is classified as a Table size... -
Page 5: Transport And Start Up
B….Bearing covers With the variable speed control knob C….Table (P) the cutting speed can be chosen. D….Sawdust blower E…..Blade and key storage area F….Mounting holes 6. Machine operation G….Bevel scale Correct working position: H….Bevel lock knob I…..Lower blade holder In front of the machine standing in J….Transparent sawguard the direction of cutting. -
Page 6: Setup And Adjustments
8. Maintenance and inspection Release blade tension. power source, pull mains plug. -remove the brush covers. General notes: -Replace the collector brushes (Jet Maintenance, cleaning and repair Article Number: JSS16-083 ….2 work may only be carried out after pieces needed). -
Page 7: Jss16A
Machine vibrates excessively *Stand on uneven surface- adjust base for even support. Cut is not square *Bevel stop setting is bad. Cutting surfaces is bad *Wrong sawblade used *resin collection on sawblade *sawblade is dull *sawblade damaged- replace sawblade immediately *workpiece inhomogeneous *Feed pressure too high- Do not force the workpiece. -
Page 8: Jss16A
JSS-16A Scroll Saw 10000808MA ~230V 50Hz PARTS LIST JPW (TOOL) AG Tämperlistrasse 5 CH-8117 Fällanden Switzerland Phone +41 44 806 47 48 +41 44 806 47 58 www.jettools.com P-10000808MA 2015-11... -
Page 9: Jss16A
Parts Breakdown for JSS-16A Scroll Saw... - Page 10 Parts List for JSS-16A Scroll Saw Index No. Part No. Description Size Qty. JSS16A-001 Philips Screw M5x8 JSS16A-002 Foam Ring JSS16A-003 Plate Cover JSS16A-004 Hex Nut JSS16A-005 Spring Washer JSS16A-006 Base JSS16A-007 Bearing Flange Oil Cap JSS16A-008 Housing Set JSS16A-009...
- Page 11 Parts List for JSS-16A Scroll Saw Index No. Part No. Description Size Qty. JSS16A-059 Hex Socket Screw M6x25 JSS16A-060 Work table bracket JSS16A-061 Pointer JSS16A-062 Bevel Scale JSS16A-063 Work Table JSS16A-064 Work table insert JSS16A-065 Speed adjusting knob JSS16A-066 Soket head cap screw...
-
Page 12: Jss16A
JSS16A-114 PCBA & Switch Assembly Wiring Diagram for JSS-16A Scroll Saw 10000808MA…………………..….. ~ 230V, 50Hz...
