3. Assembly of the base unit.
The RP3 rowing simulator comes pre-assembled into 7 separate parts:
- Mainframe assembly
- Main bar
- Seat
- Front Leg
- Rear leg
- Foot stretcher
- Box with tools and other parts
Tools needed: inbus key 6 mm and spanner size 13 for M8 nuts
Assembly procedure.
The main bar has one straight and one upward curved end, this upward curved end
is the back end.
1-
Lay the main bar on the transport box with the curved back end of the main
bar pointing downwards and make sure it's clean. Picture 1.
2-
Push the main bar into the rear leg, make sure the serial number is on the side
where the black knob is. Picture 2. Before inserting the 8 mm bolts make sure
the holes of the leg are in line with the holes of the main bar, tighten them
firm. Picture 3
3-
Slide the seat onto the main bar with the double curved side of the seat
pointing towards the hind leg, see picture 4.
4-
Make sure that before subsequently slide the main frame assembly onto the
main bar with the shaft side pointing away from the seat, that the parking
lock system is set on green! Picture 5. Put the mainframe on the transport box.
Picture 6. Push the main bar through the mainframe, don't use extreme force
it should glide through!
5-
Place the front leg, make sure again that the holes are in line before inserting
the 8 mm bolts and tighten them firm. Picture 7. Place the buffer on the front
leg. Picture 8.
6-
The stretcher boards have a strap, both of them provided with a buckle. The
stretcher boards should be attached to the stretcher bars in such a way that
the buckles point away from the main frame. Picture 9
Put the two stretcher bars through the corresponding holes in the main frame
and put the stretcher grip bolts in the stretcher bars. Picture 10.
7-
Screw on the knob for the disc, first take out M6 screw. Then screw on the
sliding vane. Picture 11 and 12
4 / 19
