RL Line/Load Reactors
TECHNICAL REFERENCE MANUAL
High Voltage! Only a qualified electrician can carry out the electrical installation
of this filter.
WARNING
❶
Performance Data
❷
Selection Guide
❸
Installation Guide
❹
Start-up/Troubleshooting
208V – 690V
Quick Reference
Pages 5 - 7
Pages 8 - 35
Pages 36 - 42
Pages 43 - 45
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MTE RL Series
Summary of Contents for MTE RL Series
- Page 1 RL Line/Load Reactors 208V – 690V TECHNICAL REFERENCE MANUAL High Voltage! Only a qualified electrician can carry out the electrical installation of this filter. WARNING Quick Reference ❶ Performance Data Pages 5 - 7 ❷ Selection Guide Pages 8 - 35 ❸...
- Page 2 This page intentionally left blank...
-
Page 3: Table Of Contents
RL Reactors Technical Reference Manual 208V – 690V TABLE OF CONTENTS RL LINE/LOAD REACTORS ........................III 1. SAFETY ..............................1 ......................1 ARNINGS AND AUTIONS ....................2 ENERAL AFETY NSTRUCTIONS 2. GENERAL INFORMATION ........................3 & R ....................3 ECEIPT EPAIR TATEMENT ........................... - Page 4 RL Reactors Technical Reference Manual 208V – 690V Open Dimension Reference ....................... 24 RL L ....................... 25 EACTORS Technical and Mechanical Specifications ................... 25 RL L ....................... 26 EACTORS Technical and Mechanical Specifications ................... 26 RL L ....................... 27 EACTORS Technical and Mechanical Specifications ...................
- Page 5 RL Reactors Technical Reference Manual 208V – 690V List of Figures Figure 3-1: Altitude Derating Curve .................... 7 Figure 3-2: Temperature Derating ....................7 Figure 5-1: Line Reactor ......................39 Figure 5-2: Load Reactor ......................39 Figure 5-3: Multiple Line Reactors.....................39 Figure 5-4: Single Phase Line Reactors ..................39 List of Tables Table 3-1: Performance Specifications ..................
-
Page 6: Safety
RL Reactors Technical Reference Manual 208V – 690V 1. SAFETY Warnings and Cautions The following symbols are used in this manual: High Voltage Warning: warns of situations that dangerously high voltage is involved. Failure to use proper precautions may lead to serious injury or death. -
Page 7: General Safety Instructions
Open panel reactors must have a 2”x2” area cleaned of paint and varnish on the lower mounting bracket. Only spare parts obtained from MTE Corporation or an authorized MTE distributor can be used. Loose or improperly secured connections may damage or degrade reactor performance. -
Page 8: General Information
RL Reactors Technical Reference Manual 208V – 690V 2. GENERAL INFORMATION The purpose of this manual is to properly specify, size, and install the RL Series Line/Load Reactors. For most current information, please refer to website https://www.mtecorp.com/products/reactors/rl-reactors/ Receipt & Repair Statement Upon Receipt of this Filter: RL Line/Load Reactors have been subjected to demanding factory tests before shipment. -
Page 9: Enclosures
RL Reactors Technical Reference Manual 208V – 690V Enclosures MTE enclosures are designed to provide a degree of protection for electrical components and prevent incidental personnel contact with the enclosed equipment. Depending on the enclosure selected, these enclosures meet the requirements of NEMA 1/2 or 3R. -
Page 10: Rl Line/Load Reactors Performance Data
RL Reactors Technical Reference Manual 208V – 690V 3. RL LINE/LOAD REACTORS PERFORMANCE DATA Performance Specifications Table 3-1: Performance Specifications Impedance Levels 1.5%, 2%, 3%, 4%, 5% available Reactors rated 1 to 750 Amps – 150% of rating Continuous Service Factor* Reactors rated above 750 Amps –... -
Page 11: Audible Noise
RL Reactors Technical Reference Manual 208V – 690V Audible Noise RL Line/Load Reactors offer low noise operation. Core and coil construction, flux density control, harmonic compensation as well as our epoxy impregnation process assure minimal audible noise radiation. Although our reactors are typically “quiet”, waveforms vary by drive type and application and therefore reactor audible noise may vary by application. -
Page 12: Altitude Derating
RL Reactors Technical Reference Manual 208V – 690V Altitude Derating Altitude Derating Curve 1.05 1.00 0.95 0.90 0.85 0.80 0.75 0.70 3300 6600 9900 13200 16500 Altitude (Feet) Figure 3-1: Altitude Derating Curve Temperature Derating Reactor Temperature De-Rating 1.05 1.00 0.95 0.90 0.85... -
Page 13: How To Select
VFD drive generated harmonics, and to reduce motor operating temperature. Single Phase Applications: RL reactors may also be sized to protect single phase drives. Please see MTE Application Note: How to Use a 3-Phase Line Reactor for a Single-Phase Application for details. -
Page 14: Understanding The Rl Line/Load Reactor Part Number
RL Reactors Technical Reference Manual 208V – 690V Understanding the RL Line/Load Reactor Part Number: RL _ - _ _ _ _ X MOV Options* A = 208 Volts C = 240 Volts E = 400 Volts G = 480 Volts J = 600 Volts Current Rating (i.e. -
Page 15: Rl Line/Load Reactor Options
Top Mounted. To signify the change, add B8 to the end of the RL part number. (Note: Terminal blocks are only available on reactors 45 Amps and below. Contact MTE for additional information.) Lug Option Details: “B1”... -
Page 16: Rl Line/Load Reactors 120V - 600V Single Phase
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 120V – 600V Single Phase Part Number Selection Tables Table 4-1: RL Reactors 120V – 600V – Single Phase Motor Input Voltage & Hz Impedance 120V 60Hz 208V 60Hz 240V 60Hz 240V 50Hz 400V 50Hz... -
Page 17: Rl Line/Load Reactors 208 Volts, 60Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 208 Volts, 60Hz Part Number Selection Tables Table 4-2: RL Reactors 208V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-00204 RL-00214 RL-00234 0.18... -
Page 18: Rl Line/Load Reactors 208 Volts, 60Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 208 Volts, 60Hz Part Number Selection Tables Table 4-3: RL Reactors 208V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-10001 RL-10011... -
Page 19: Rl Line/Load Reactors 240 Volts, 60Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 240 Volts, 60Hz Part Number Selection Tables Table 4-4: RL Reactors 240V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-00204 RL-00214 RL-00234 0.18... -
Page 20: Rl Line/Load Reactors 240 Volts, 60Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 240 Volts, 60Hz Part Number Selection Tables Table 4-5: RL Reactors 240V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-10001 RL-10011... -
Page 21: Rl Line/Load Reactors 400 Volts, 50Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 400 Volts, 50Hz Part Number Selection Tables Table 4-6: RL Reactors 400V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-00103 RL-00113 RL-00133 0.18... -
Page 22: Rl Line/Load Reactors 400 Volts, 50Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 400 Volts, 50Hz Part Number Selection Tables Table 4-7: RL Reactors 400V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-08002 RL-08012 RL-08032 37.5... -
Page 23: Rl Line/Load Reactors 480 Volts, 60Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 480 Volts, 60Hz Part Number Selection Tables Table 4-8: RL Reactors 480V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-00103 RL-00113 RL-00133 0.18... -
Page 24: Rl Line/Load Reactors 480 Volts, 60Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 480 Volts, 60Hz Part Number Selection Tables Table 4-9: RL Reactors 480V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-08002 RL-08012 RL-08032 37.5... -
Page 25: Rl Line/Load Reactors 600 Volts, 60Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 600 Volts, 60Hz Part Number Selection Tables Table 4-10: RL Reactors 600V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-00102 RL-00112 RL-00132 0.18... -
Page 26: Rl Line/Load Reactors 600 Volts, 60Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 600 Volts, 60Hz Part Number Selection Tables Table 4-11: RL Reactors 600V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-05502 RL-05512 RL-05532 37.5... -
Page 27: Rl Line/Load Reactors 690 Volts, 50Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 690 Volts, 50Hz Part Number Selection Tables Table 4-12: RL Reactors 690V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-00403 RL-00413... -
Page 28: Rl Line/Load Reactors 690 Volts, 50Hz
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors 690 Volts, 50Hz Part Number Selection Tables Table 4-13: RL Reactors 690V – 3-Phase MTE Part Number & Motor Enclosure Type Impedance Open NEMA 1/2 NEMA 3R RL-08002 RL-08012... -
Page 29: Rl Line/Load Reactors
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors Open Dimension Reference Use the reactor outline below for reference with the Technical and Mechanical Specification tables on the following pages. Dimensions A, B, and C show overall Width, Height, and Depth respectively. Dimensions D, E, and F are the mounting pattern. -
Page 30: Rl Line/Load Reactors
3.2/ 2.1/ RL-01202 149.9 81.3 76.2 5.9/ 3.8/ 2.8/ RL-01203 149.9 96.5 76.2 5.9/ 5.1/ 3.2/ 2.1/ RL-01801 149.9 129.5 81.3 76.2 For detailed drawings of each reactor, click on the “MTE Part Number”. Form: RL-TRM-E April 2019 REV. 001... -
Page 31: Rl Line/Load Reactors
6.6/ 3.7/ 3.63/ 4.3/ RL-10002 226.1 177.8 167.6 16.8 10.8/ 8.4/ 7.8/ 4.2/ 3.63/ 5.6/ RL-10003 0.45 274.3 213.4 198.1 141.7 30.4 For detailed drawings of each reactor, click on the “MTE Part Number”. Form: RL-TRM-E April 2019 REV. 001... -
Page 32: Rl Line/Load Reactors
5.6/ RL-50001B14 0.025 274.3 215.9 238.8 141.7 42.2 14.3/ 11.1/ 10.6/ 6.8/ 4.6/ 7.2/ 160/ RL-50002 0.05 363.2 281.9 269.2 182.9 72.6 For detailed drawings of each reactor, click on the “MTE Part Number”. Form: RL-TRM-E April 2019 REV. 001... -
Page 33: Rl Line /Load Reactors
7.2/ 390/ RL-120003B14 1200 0.03 1530 431.8 373.4 449.6 182.9 176.9 16.6/ 15.2/ 500/ RL-140001 1400 0.008 1235 533.4 421.6 386.1 226.8 For detailed drawings of each reactor, click on the “MTE Part Number”. Form: RL-TRM-E April 2019 REV. 001... -
Page 34: Rl Line /Load Reactors
16.8/ 15.5/ 460/ RL-150002 1500 0.015 1100 457.2 426.7 393.7 208.7 16.6/ 19.9/ 760/ RL-150003 1500 0.025 2621 533.4 421.6 505.5 344.7 For detailed drawings of each reactor, click on the “MTE Part Number”. Form: RL-TRM-E April 2019 REV. 001... -
Page 35: Rl Line /Load Reactors
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors Technical and Mechanical Specifications Table 4-15: RL Reactors NEMA 1/2 Technical Specifications Cabinet Dimensions Approx. Amps MTE Part Cabinet Part Inductance (H x W x D) Weight Rating Number... -
Page 36: Rl Line /Load Reactors
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors Technical and Mechanical Specifications Table 4-15: RL Reactors NEMA 1/2 Technical Specifications (continued) Cabinet Dimensions Approx. Amps MTE Part Cabinet Part Inductance (H x W x D) Weight Rating Number... -
Page 37: Rl Line /Load Reactors
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors Technical and Mechanical Specifications Table 4-15: RL Reactors NEMA 1/2 Technical Specifications (continued) Cabinet Dimensions Approx. Amps MTE Part Cabinet Part Inductance (H x W x D) Weight Rating Number... -
Page 38: Rl Line /Load Reactors
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors Technical and Mechanical Specifications Table 4-16: RL Reactors NEMA 3R Technical Specifications Cabinet Dimensions Approx. Amps MTE Part Cabinet Part Inductance (H x W x D) Weight Rating Number... -
Page 39: Rl Line /Load Reactors
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors Technical and Mechanical Specifications Table 4-16: RL Reactors NEMA 3R Technical Specifications (continued) Cabinet Dimensions Approx. Amps MTE Part Cabinet Part Inductance (H x W x D) Weight Rating Number... -
Page 40: Rl Line /Load Reactors
RL Reactors Technical Reference Manual 208V – 690V RL Line/Load Reactors Technical and Mechanical Specifications Table 4-16: RL Reactors NEMA 3R Technical Specifications (continued) Cabinet Dimensions Approx. Amps MTE Part Cabinet Part Inductance (H x W x D) Weight Rating Number... -
Page 41: How To Install
NEMA 1/2 & 3R Installation Guidelines: MTE line/load reactors mounted in CAB-8 and CAB-13V enclosures are designed for wall mounting. All other enclosures are designed for floor mounting. Allow a minimum side, front, and back clearances of twelve (12) inches and vertical clearances of eighteen (18) inches for proper heat dissipation and access. -
Page 42: Grounding
RL Reactors Technical Reference Manual 208V – 690V Grounding The reactor must always be grounded with a grounding conductor connected to ground terminals. For open reactors, ensure a 2” x 2” area is cleaned of paint and varnish on WARNING lower mounting bracket for ground connection. -
Page 43: Power Wiring Connection
RL Reactors Technical Reference Manual 208V – 690V Power Wiring Connection Input and output power wiring to the reactor should be performed by authorized personnel in accordance with the NEC and all local electrical codes and regulations. Cable lugs and mounting hardware are provided by the customer. WARNING Any extremely low or high resistance readings indicate a mis-wire and may result in damage to reactor if not corrected. -
Page 44: Typical Connection Diagrams
Figure 5-4: Single Phase Line Reactors Standard three phase reactors may be used for single phase applications. Visit the MTE website for more information. -
Page 45: Torque Ratings
RL Reactors Technical Reference Manual 208V – 690V Torque Ratings Table 5-1: RL Reactors Torque Ratings Amps MTE Part Wire Range Terminal Torque Rating Amps Number (AWG) (in-lbs.) RL-00101 22 – 10 RL-00102 22 – 10 RL-00103 22 – 10 RL-00104 22 –... -
Page 46: Torque Ratings
RL Reactors Technical Reference Manual 208V – 690V Torque Ratings Table 5-1: RL Reactors Torque Ratings (continued) Amps MTE Part Wire Range Terminal Torque Rating Amps Number (AWG) (in-lbs.) RL-05501 6 – 0 6 – 4 (45) & 2 – 0 (50) 82.5... -
Page 47: Torque Ratings
RL Reactors Technical Reference Manual 208V – 690V Torque Ratings Table 5-1: RL Reactors Torque Ratings (continued) Amps MTE Part Wire Range Terminal Torque Rating Amps Number (AWG) (in-lbs.) RL-60001 Copper Tab Not Applicable RL-60002 Copper Tab Not Applicable RL-60003... -
Page 48: Start-Up
RL Reactors Technical Reference Manual 208V – 690V 6. START-UP Safety Precautions Before start-up, observe the following warnings and instructions: Use extreme caution to avoid contact with line voltage when checking for power. INJURY OR DEATH MAY RESULT IF SAFETY PRECAUTIONS ARE NOT OBSERVED. -
Page 49: Troubleshooting
RL Reactors Technical Reference Manual 208V – 690V 7. TROUBLESHOOTING When properly installed, this equipment has been designed to provide maximum safety for operating personnel. However, hazardous voltages and elevated temperatures exist within the confines of the enclosure. Servicing should therefore be performed by qualified personnel only and in accordance with OSHA Regulations. - Page 50 RL Reactors Technical Reference Manual 208V – 690V Table 7-1: Troubleshooting Guide PROBLEM: Line voltage is not present at the reactor output terminals. Possible cause: Power to the reactor is turned off. Solution: Turn power on. Possible cause: One or more external line fuses are blown. Solution: Verify the continuity of line fuses in all phases.
