Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new 4Runner. A word about safe vehicle operations This Quick Reference Guide is not a full description of 4Runner operations.
Page 3
Doors-Child safety locks Seat belts Seat belts-Shoulder belt anchor Spare tire & tools Tire Pressure Warning System Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. ®...
OVERVIEW Instrument panel Steering wheel switches (if equipped) Rear console box Driving position memory switches Headlight, turn signal and front fog light control Wiper and washer controls Power back window switch Audio system or navigation system Front passenger seat belt reminder light Engine immobilizer/Theft deterrent system indicator Front passenger occupant classification indicator...
Page 5
Hood release Fuel tank door opener “RSCA OFF”(Roll Sensing of Curtain shield Airbags “OFF”) switch “AUTO LSD” switch Center differential lock switch 115V AC Power outlet ON/OFF switch Instrument panel light control Steering wheel audio controls Telephone switches Navigation voice command button 12V DC Power outlet/Cigarette lighter 115V AC Power outlet AUX adapter...
OVERVIEW Instrument cluster Limited model only Tachometer Speedometer Service indicator and reminder Fuel gauge Low fuel level warning Engine coolant temperature Trip meter reset knob Odometer and two trip meters Height control indicator Indicator symbols Brake system warning Driver/Front passenger seat belt reminder Charging system warning Low engine oil pressure warning...
Page 7
Engine immobilizer/Theft deterrent system indicator Roll Sensing of Curtain shield Airbag “OFF” indicator Front passenger occupant classification indicator Headlight high beam indicator Turn signal indicator Front fog light indicator Automatic Transmission indicator Low speed four-wheel drive indicator Center differential lock indicator Vehicle Stability Control “OFF”...
OVERVIEW Fuel tank door release and cap Pull up Turn Store NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Keyless entry (if equipped) Beep sound can be switched “ON” or “OFF.” Refer to the Owner’s Manual for more details.
Hood release Pull Pull up latch and raise hood Engine maintenance 6 cylinder (1GR-FE) engine 8 cylinder (2UZ-FE) engine Windshield and back window washer fluid tank Power steering fluid reservoir Engine oil level dipstick Engine coolant reservoir Engine oil filler cap Note: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance.
FEATURES/OPERATIONS Auto lock functions Automatic door locks can be programmed to operate in four different modes, or turned OFF. -Doors lock when shifting from “Park.” -Doors lock when the vehicle speed goes above approximately 12 mph. -Doors unlock when shifting into “Park.” -Doors unlock when the engine switch is set from “ON”...
Four-wheel drive (if equipped) Part-time four-wheel drive models High speed (2WD) High speed (4WD) Turn to “H4” with speed below 62 mph. Low speed (4WD) Shift to “N” position, then push and turn to “L4.” Full-time four-wheel drive models High speed Turn to “H4”...
FEATURES/OPERATIONS Tilt and telescopic (if equipped) steering wheel To change the angle Hold the steering wheel, pull the lock release lever, tilt to the desired angle, and release the lever. To change the column length Push the lock release lever down, set the desired length, and return the lever to its locked position.
Seats-Head restraints Front Lock release button Second row seat Without third seat With third seat Lock release button Lock release button Third row Lock release button Parking brake Set: Depress Release: Depress again...
Page 14
FEATURES/OPERATIONS Seat adjustments-Rear (vehicles with third row seats) Second row seats Seatback angle Seatback angle Third row seats Seatback angle Seatback angle Seat adjustments-Rear (vehicles without third row seats) (3) Pull up (2) Lower (1) Push (4) Push down (5) Fold down...
Windshield wipers & washers Front Adjust interval Interval wipe Pull to wash and wipe Slow Fast Rear Wash and wipe Wipe Interval wipe Wash and wipe NOTE: Rear wiper and washer operate only when rear window is fully closed. If battery is disconnected, rear washer will not function until rear window is reinitialized by being fully opened and then closed.
FEATURES/OPERATIONS Lights & turn signals Headlights AUTO* Headlights Parking lights High beam Low beam High beam flasher * If equipped -Daytime Running Light system (if equipped) Automatically turns on the headlights at a reduced intensity. -Automatic light cut off system Will automatically turn lights off after a delay of 30 seconds, or the lock switch on remote may be pushed.
Page 17
Windows Driver side Window lock switch Down Down Automatic operation (driver side only) Push the switch completely down or pull it completely up and release to fully open or close. To stop window midway, lightly push the switch in the opposite direction.
FEATURES/OPERATIONS Cruise control Turning system ON/OFF System ON/OFF Functions Resume /Increase speed Cancel Set/Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed exceeds 25 mph. Refer to the Owner’s Manual for more details. Seat heaters (if equipped) Right front seat Left front seat...
Air Conditioning/Heating With “DUAL” button Without “DUAL” button Fan speed Temperature Automatic climate control ON/OFF “DUAL” button Indicator ON: Separate temperature settings for driver and passenger. Indicator OFF: Synchronize temperature settings for driver and passenger. Airflow vent In “ ” or “ ”...
Page 20
FEATURES/OPERATIONS Audio Preset buttons - functions in other Type 1 modes indicated above number. Eject CD Push to Push to turn adjust ON/OFF tone & balance Seek station/ Push to CD track skip select Mode up/down View radio/CD Station/CD folder information track scan Type 2 additional functions...
Page 21
RADIO To preset stations Tune in the desired station and hold down a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select. To scan stations Push “SCAN.” Push and hold to scan preset stations. Push again to hold selection. Steering wheel controls (if equipped) “...
FEATURES/OPERATIONS Door locks Lock Unlock Rear seat entertainment system (if equipped) Front audio system DVD player DVD screen Remote control A/V input adapter 115V AC Power outlet 115V AC Power outlet ON/OFF switch...
* can be programmed to operate garage doors, estate gates, security lighting, etc. Refer to the Owner’s Manual for more details. For programming assistance, contact the Toyota Customer Experience Center at 1-800-331-4331, or visit http://www.homelink.com * HomeLink ® is a registered trademark of Johnson Controls, Inc.
FEATURES/OPERATIONS Moonroof (if equipped) Sliding operation Tilting operation Open Close Close Tilt NOTE: If battery is disconnected, the moonroof will need to be reinitialized. Refer to the Owner’s Manual for more details. Cup holders Center console Rear (without third seats) Rear (with third seats) Second row seat Third row side trim...
Bottle holders Rear doors Front doors Power outlets 12V DC Luggage compartment Auxiliary box NOTE: Designed for car accessories. Engine switch must be in the “ACC” or “ON” position to be used. 115V AC (if equipped) Inside center console ON/OFF switch Push NOTE: Engine switch must be in the “ON”...
SAFETY AND EMERGENCY FEATURES Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seat belts Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again.
Spare tire & tools Tool location Tool bag Jack Removing the spare tire (1) Assemble the jack handle. (2) Insert the jack handle end through the opening in the bumper, and into the lowering screw. (3) Turn the jack handle counterclockwise. Refer to the Owner’s Manual for tire changing and jack positioning procedures.
Page 28
Customer Experience Center 1-800-331-4331 MN 00505-QRG08-4RUN Printed in the USA 7/07...
