Page 1 Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 2 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 3 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 4 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 5 1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 6 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 7 1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 8 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (→P. 144, 146) CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 9 1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 10 If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 11 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 12 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Adjustable shoulder anchor Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 13 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 14 1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 15 1-1. For safe use SRS airbag system components Side airbags Front passenger occupant classification system (ECU “AIR BAG ON” and “AIR and sensors) BAG OFF” indicator lights Side impact sensors (rear) Curtain shield airbags SRS warning light Front passenger airbag Safing sensor (rear) Knee airbags Driver airbag...
Page 16 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 17 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 18 1-1. For safe use CAUTION ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
Page 19 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 20 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 21 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 22 1-1. For safe use The SRS curtain shield airbags may also deploy under the situations shown in the illustration. ● The angle of vehicle tip-up is marginal. ● The vehicle skids and hits a curb stone. ■ Types of collisions that may not deploy the SRS airbags (SRS front air- bags) The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal...
Page 23 Pitching end over end ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 24 1-1. For safe use ● The pad section of the steering wheel, dashboard near the front passenger air- bag or lower portion of the instrument panel is scratched, cracked, or other- wise damaged. ● The surface of the seats with the side airbag is scratched, cracked, or other- wise damaged.
Page 25 1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. SRS warning light Seat belt reminder light “AIR BAG OFF”...
Page 26 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seat Curtain shield airbag in the front...
Page 27 1-1. For safe use ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” Not illuminated indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag in the front passenger side Devices Front passenger knee airbag...
Page 28 1-1. For safe use ■ There is a malfunction in the system “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag in the front Devices...
Page 29 1-1. For safe use CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 30 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the second seat should not contact the front seatbacks.
Page 31 1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 32 1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the lap portion of the lap/ shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 33 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing ⎯ Infant seat/con- Forward facing ⎯ Convertible vertible seat seat Booster seat ■...
Page 34 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 35 1-1. For safe use CAUTION ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 36 1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH (Lower Anchors and Tethers for Children) anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH system.
Page 37 1-1. For safe use Vehicles without third row seats Anchor brackets (for top tether strap) An anchor bracket is provided for each rear seat. Vehicles with third row seats Anchor brackets (for top tether strap) An anchor bracket is provided for each second row seat.
Page 38 1-1. For safe use Installation with LATCH system (rear/second row seats only) ■ Installing on the rear seats (vehicles without third row seats) Fold the seatback while pull- seatback angle adjustment lever. Return the seatback and secure it at the first lock position.
Page 39 1-1. For safe use Type B Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: symbol child restraint system indicates the presence of a lower connec-...
Page 40 1-1. For safe use Type A Latch the hooks of the lower straps onto LATCH anchors. If the child restraint has a top tether strap, the top tether strap should latched onto the top tether strap anchor. For owners in Canada: symbol child restraint system indicates the...
Page 41 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯ Infant seat/convertible seat ■ Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 42 1-1. For safe use While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 43 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 44 1-1. For safe use ■ Booster seat Place the child restraint sys- tem on the seat facing the front of the vehicle. Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the...
Page 45 1-1. For safe use Child restraint systems with a top tether strap Secure the child restraint sys- tem using the seat belt or the lower anchors, and remove the head restraint. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap.
Page 46 1-1. For safe use CAUTION ■ When installing a booster seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (→P. 31) ■...
Page 47 1-1. For safe use CAUTION ■ When installing a child restraint system ● Vehicles with third row seats: When using the LATCH anchors for a child restraint system, move the seat as far back as possible, with the seatback close to the child restraint system. ●...
Page 48 Keep the back door closed. ● If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 49 1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 50 1-2. Theft deterrent system ■ Certifications for the engine immobilizer system (vehicles without a smart key system) For vehicles sold in the U.S.A. FCC ID:MOZRI-33BTY This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 51 1-2. Theft deterrent system ∗ Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key.
Page 52 1-2. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ● Nobody is in the vehicle. ●...
Page 53 1-2. Theft deterrent system 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 54 2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 55 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Brake system warning Cruise control indicator light (→P. 418) light (→P. 419) (U.S.A.) Brake system warning Slip indicator (→P. 419) light (→P. 418) (Canada) Charging system warn- Four-wheel drive indica-...
Page 56 There may be a malfunction in a system if the lights do not come on, or do not turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate a malfunction.
Page 57 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. 1, 2 Turn signal indicator Slip indicator (→P. 261) (→P. 203) Headlight indicator VSC OFF indicator (→P. 205) (→P. 262) (U.S.A.) 1, 4 Tail light indicator “AIR BAG ON/OFF”...
Page 58 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 59 2. Instrument cluster Gauges and meters The displayed content may differ depending on the type of meter. Tachometer Displays the engine speed in revolutions per minute Engine coolant temperature gauge Displays the engine coolant temperature Shift position and shift range Displays the selected shift position or selected shift range (→P.
Page 60 2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Brighter Darker ■ The meters and display illuminate when Vehicles without a smart entry & start system The engine switch is in the “ON” position. Vehicles with a smart entry &...
Page 61 2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of driv- ing-related data. Driving monitor (→P. 84) Eco Driving Indicator Zone Display (→P. 87) Warning messages (→P. 426) Outside temperature display (→P. 312) Trip information (→P.
Page 62 2. Instrument cluster Driving monitor ■ Switching the display Items displayed switched pressing “DISP” switch. ■ Average fuel consumption Displays the average fuel consumption since the function was reset • Press and hold the “DISP” switch to reset when the average fuel con- sumption is displayed.
Page 63 2. Instrument cluster ■ Front tire angle Displays the direction of the front tires The tire direction is displayed in 3 stages for both left and right, in accor- dance with the angle of the tire. ■ Customization Language, units and Eco Driving Indicator Light settings can be changed.
Page 64 2. Instrument cluster Customizing vehicle features It is possible to customize the language, units and Eco Driving Indica- tor Light settings using the “DISP” switch. When customizing vehicle features, ensure that the vehicle is parked in a safe place with the shift the shift lever to P and the parking brake set.
Page 65 2. Instrument cluster ● Items that can be changed Function Default setting Customized setting French Language English Spanish Units “miles” “km (L/100km)” “ECO LAMP” (Eco ON (Self-lighting) Driving Indicator Light) : The default setting varies according to countries. ■ Eco Driving Indicator Eco Driving Indicator Light During Eco-friendly acceleration (Eco driving), Eco Driving Indicator Light will...
Page 66 2. Instrument cluster ■ Liquid crystal display Small spots or light spots may appear on the display. This phenomenon is characteristic of liquid crystal displays, and there is no problem continuing to use the display. ■ Setting display automatic suspension In the following situations, the setting display will be suspended.
Page 67 2. Instrument cluster ∗ Accessory meter The accessory meter presents the driver with a variety of driv- ing-related data including the current outside air temperature. “MODE/ ” button “SET/ ” button Trip information (→P. 90) Displays driving range and average fuel consumption Outside temperature display (→P.
Page 68 2. Instrument cluster Trip information Items displayed can be switched by pressing the “MODE/ ” button. ■ Cruising range Displays the estimated maximum distance that can be driven with the quantity of fuel remaining • This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.
Page 69 2. Instrument cluster ■ Adjusting the brightness of the accessory meter ● If left idle for approximately 6 seconds or more while adjusting, the display will revert to the trip information display. ● When the parking lights are on, the brightness of the accessory meter can be adjusted only with the instrument panel light control.
Page 70 2. Instrument cluster 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 71 3-1. Key information Keys The keys Vehicles without a smart key system Master keys Operating the wireless remote con- trol function Valet key Key number plate Vehicles with a smart key system The following keys are provided with the vehicle. Electronic keys •...
Page 72 Opens the windows and moon roof (press and hold) : This setting must be customized at your Toyota dealer. Vehicles with a smart key system Locks all the doors (→P. 100) Unlocks all the doors (→P. 100) Pressing the button unlocks the driver’s door.
Page 73 3-1. Key information Using the mechanical key (vehicles with a smart key system) To take out the mechanical key, push the release button and take the key out. The mechanical key can only be inserted in one direction, as the key only has grooves on one side.
Page 74 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using the other key (vehicles without a smart key system) or mechanical key (vehicles with a smart key system) and the key number stamped on your key number plate.
Page 75 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ If a wrong key is used (vehicles with a smart key system) The key cylinder rotates freely to isolate inside mechanism.
Page 76 When an electronic key is lost (vehicles with a smart key system) If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.
Page 77 3-1. Key information Side doors Unlocking and locking the doors from the outside ◆ Smart key system (if equipped) Carry the electronic key to enable this function. Grip the driver’s door handle to unlock the door. Grip the passenger’s door handle to unlock all the doors.
Page 78 3-1. Key information ◆ Turning the key operates the doors as follows: Vehicles without a smart key system Locks all the doors Unlocks all the doors Driver’s side only: Turning the key unlocks the driver’s door. Turning the key again unlocks the other doors.
Page 79 3-1. Key information ■ Door lock buzzer If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds continuously. Fully close the door to stop the buzzer, and lock the vehicle once more. ■...
Page 80 3-1. Key information Locking the doors from the outside without a key Move the inside lock button to the lock position. Close the door. Vehicles without a smart key system The door cannot be locked if either of the front doors is open and the key is in the engine switch.
Page 81 3-1. Key information Automatic door locking and unlocking systems The following functions can be set or canceled: For instructions on customizing, refer to P. 485. Function Operation All doors are automatically locked Speed linked door locking function when vehicle speed is approxi- mately 12 mph (20 km/h) or higher.
Page 82 3-1. Key information Shift the shift lever to P or N, and press and hold the driver's door lock switch approxi- mately 5 seconds and then release. The shift lever and switch posi- tions corresponding desired function to be set are shown in the following table.
Page 83 3-1. Key information CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant throwing out of the vehicle, resulting in death or serious injury. ●...
Page 84 3-2. Opening, closing and locking the doors ∗ Smart key system Function summary The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) ●...
Page 85 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) either of the outside front door handles and back door.
Page 86 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warning messages shown on the multi-information display are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate mea- sures in response to any warning message on the multi-information display.
Page 87 3-2. Opening, closing and locking the doors Alarm Situation Correction procedure The engine switch was pressed after the doors were unlocked with the Touch electronic mechanical key. Interior alarm sounds engine The engine switch was once. switch while depressing pressed two consecu- the brake pedal.
Page 88 3-2. Opening, closing and locking the doors ● When the electronic key is in contact with, or is covered by the following metallic objects • Cards to which aluminum foil is attached • Cigarette boxes that have aluminum foil inside •...
Page 89 3-2. Opening, closing and locking the doors ■ Note for locking the doors ● Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again. ● When the lock operation is performed using the lock sensor, recognition sig- nals will be shown up to two consecutive times.
Page 90 (→P. 107) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
Page 91 3-2. Opening, closing and locking the doors ∗ Automatic running boards The Automatic running boards are linked to the side door opera- tions, extending and retracting when a side door is opened and closed. When a door is opened or closed, the board on the same side extends or retracts.
Page 92 If the Automatic running boards indicator light flashes There may be a malfunction in the Automatic running boards system. Have the vehicle inspected by your Toyota dealer immediately. ■ When snow or mud is attached to the board or the board is frozen The Automatic running boards may not operate correctly.
Page 93 3-2. Opening, closing and locking the doors CAUTION ■ Jam protection function Observe the following precautions. Failure to do so may cause serious injury. Never use any part of your body to intentionally activate the jam protection function. The jam protection function may not work depending on the shape of the object that is caught.
Page 94 3-2. Opening, closing and locking the doors Back door Unlocking and locking the back door from the outside ◆ Smart key system (if equipped) Carry the electronic key to enable this function. Press the button to unlock the door. Press the button to lock the door.
Page 95 3-2. Opening, closing and locking the doors Unlocking and locking the back door from the inside Locks all the doors Unlocks all the doors Opening the back door from outside the vehicle Raise the back door while pushing up the back door opener switch. Rear step bumper The rear step bumper is intended for rear end protection and easier...
Page 96 3-2. Opening, closing and locking the doors ■ Luggage compartment lights Each luggage compartment light has the following 3 positions: Turns the light off Turns the light on Turns the light on/off linked to back door position If the luggage compartment lights remain on, the lights will go off automati- cally after 20 minutes.
Page 97 3-2. Opening, closing and locking the doors CAUTION ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 98 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. NOTICE ■...
Page 99 3-2. Opening, closing and locking the doors 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 100 3-3. Adjusting the seats Front seats Adjustment procedure Power seat Seat position adjustment switch Vertical height adjustment switch (driver’s side only) Seatback angle adjustment switch Lumbar support adjustment switch (driver’s side only) Seat cushion (front) angle adjustment switch (driver’s side only) Manual seat Seat position adjustment lever...
Page 101 3-3. Adjusting the seats Active head restraints When the occupant’s lower back presses against the seatback dur- ing a rear-end collision, the head restraint moves slightly forward and upward to help reduce the risk of whiplash to the seat occu- pant.
Page 102 3-3. Adjusting the seats CAUTION ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
Page 103 3-3. Adjusting the seats Rear seats Adjustment procedures Vehicles without third row seats ■ Rear seat Pull up the seatback angle adjustment lever until the lock is released. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 104 3-3. Adjusting the seats Vehicles with third row seats ■ Second row seats Seat position adjustment lever Seatback angle adjustment lever ■ Third row seats The third row seats do not have a seat adjustment function. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 105 3-3. Adjusting the seats Folding down the rear seats (vehicles without third row seats) ■ Before folding down the rear seats Adjust the head restraints to the downmost position. Fold down head restraints. When returning head restraints to their original posi- tions, make sure they are locked securely.
Page 106 3-3. Adjusting the seats ■ Folding down the rear seats Swing the bottom cushions up by pulling the lock release strap. When returning the rear seat cushions to their original posi- tions, make sure they are locked securely. Push the lock release button and fold down the seatbacks.
Page 107 3-3. Adjusting the seats Folding down the second row seats (vehicles with third row seats) ■ Before folding down the second row seats Adjust the head restraints to the downmost position. Stow the second row seat belt buckles. ■ Folding down the second row seats Pull the seatback lock release lever and fold the seatback down.
Page 108 3-3. Adjusting the seats Moving a second row seat for access to the third row seats (vehicles with third row seats) ■ Getting in the vehicle (right side only) Pull up the lever and fold down the seatback. The seat will slide forward.
Page 109 3-3. Adjusting the seats Folding down the third row seats (vehicles with third row seats) ■ Before folding down the third row seats Pass the seat belts through the seat belt hangers and secure the seat belt plates. This prevents the shoulder belts from being damaged.
Page 110 3-3. Adjusting the seats From outside Pull the strap to fold down the head restraint. Pull the lever up. The seat cushion will slide back- ward and the seatback will be unlocked. Fold the seatback down. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 111 3-3. Adjusting the seats ■ Returning the third row seats As the seat cushions cannot be pulled forward from outside, this operation can only be performed from inside. Raise the seatbacks to their original positions. Make sure they are locked securely.
Page 112 3-3. Adjusting the seats CAUTION ■ When folding the rear seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to P.
Page 113 3-3. Adjusting the seats ∗ Driving position memory This feature automatically adjusts the driver’s seat to suit your preferences. Driving position memory Your preferred driving position (the position of the driver’s seat) can be recorded and recalled by pressing a button. Two different driving positions can be recorded into memory.
Page 114 3-3. Adjusting the seats ■ To stop the position recall operation part-way through Perform any of the following: ● Press the “SET” button. ● Press button “1” or “2”. ● Operate any of the seat adjustment switches (only cancels seat position recall).
Page 115 3-3. Adjusting the seats While pressing the recalled button, press and hold the door lock switch (either lock or unlock) until the buzzer sounds. If the button could not be regis- tered, the buzzer sounds contin- uously approximately seconds. ■ Recall procedure Carry the electronic key that has been registered to the driving position, and then unlock and open the driver’s door using the...
Page 116 3-3. Adjusting the seats CAUTION ■ Seat adjustment caution Take care during seat adjustment so that the seat does not strike the rear passenger or squeeze your body against the steering wheel. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 117 3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Second seats Vertical adjustment Pull the head restraints up.
Page 118 3-3. Adjusting the seats Third seats (vehicle with third row seats) To use Lift up the head restraint until it locks. To fold Pull the strap to fold the head restraint. ■ Removing the head restraints (except third row seats) Pull the head restraint up while pressing the lock release button.
Page 119 3-3. Adjusting the seats CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...
Page 120 3-4. Adjusting the steering wheel and mirrors Steering wheel The steering wheel can be adjusted to a comfortable position. Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.
Page 121 3-4. Adjusting the steering wheel and mirrors CAUTION ■ Caution while driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ■...
Page 122 3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 123 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode ON/OFF When the automatic anti-glare function is in on mode, the indica- tor illuminates.
Page 124 3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 125 3-4. Adjusting the steering wheel and mirrors ■ Mirror angle can be adjusted when Vehicles without a smart key system The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system The engine switch is in ACCESSORY or IGNITION ON mode. ■...
Page 126 3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening :To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 127 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. 4RUNNER (U)_(OM35A83U)
Page 128 3-5. Opening, closing the windows and moon roof ■ Customization Settings (e.g. key linked operation) can be changed. (Customizable features →P. 485) CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ●...
Page 129 3-5. Opening, closing the windows and moon roof Power back window The power back window can be opened and closed using the switch or key. Opening and closing procedures From inside the vehicle Closing One-touch closing Opening One-touch opening : To stop the window partway, operate the switch in the oppo- site direction.
Page 130 3-5. Opening, closing the windows and moon roof From outside the vehicle (vehicles with a smart key system) Opening (push and hold) Closing (push and hold) This operation can only be per- formed when the electronic key is within the detection range. ■...
Page 131 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■...
Page 132 3-5. Opening, closing the windows and moon roof CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ Caution while driving Keep the back door and back window closed while driving. If the back door or the back window is left open, the back door may hit nearby objects while driving or luggage may be unexpectedly thrown out, causing an accident.
Page 133 3-5. Opening, closing the windows and moon roof ∗ Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 134 3-5. Opening, closing the windows and moon roof ■ The moon roof can be operated when Vehicles without a smart key system The engine switch is in the “ON” position. Vehicles with a smart key system The engine switch is in IGNITION ON mode. ■...
Page 135 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. ■ Moon roof open reminder function An alarm will sound when the driver’s door is opened with the moon roof not...
Page 136 3-5. Opening, closing the windows and moon roof CAUTION Observe the following precautions. Failure to do so may cause death or serious injury. ■ Opening the moon roof ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 137 4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine →P. 195 Driving With the brake pedal depressed, shift the shift lever to D. (→P. 200) Release the parking brake. (→P. 204) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 138 The vehicle is judged to be driving uphill or downhill ● When the accelerator pedal is released ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ● For the first 200 miles (300 km): Avoid sudden stops.
Page 139 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 140 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● During normal driving, do not turn off the engine. Turning the engine off while driving will not cause loss of steering or braking control, but the power assist to these systems will be lost.
Page 141 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ●...
Page 142 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 143 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 144 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 145 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 146 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 147 4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ●...
Page 148 4-1. Before driving Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) — (Total weight of occupants) Steps for Determining Correct Load Limit⎯ (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
Page 149 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (→P. 460) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 150 To use the roof rails as a roof luggage Roof rails carrier, you must fit the roof rails with Cross rails two or more genuine Toyota cross rails or their equivalent. ● When there is no luggage on the roof...
Page 151 4-1. Before driving CAUTION ■ Capacity and distribution ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
Page 152 4-1. Before driving Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. ◆ Total load capacity (vehicle capacity weight): (→P. 460) Total load capacity means the combined weight of occupants, cargo and luggage.
Page 153 To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating conditions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about addi- tional requirements such as a towing kit, etc.
Page 154 4-1. Before driving Towing related terms ■ GCWR (Gross Combination Weight Rating) The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 155 4-1. Before driving ■ GAWR (Gross Axle Weight Rating) The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR ■ TWR (Trailer Weight Rating) The maximum allowable gross (With brakes) trailer weight.
Page 156 4-1. Before driving ■ Unbraked TWR (Unbraked Trailer Weight Rating) The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. ■ Tongue Weight The load placed on the trailer hitch ball. (→P. 181) 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 157 4-1. Before driving Weight limits ● The gross trailer weight must never exceed the TWR described in the table. (→P. 181) ● The gross combination weight must never exceed the GCWR described in the table. (→P. 181) ● The gross vehicle weight must never exceed the GVWR indi- cated on the Certification Label.
Page 158 4-1. Before driving GCWR, TWR and Unbraked TWR Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. ■ GCWR and TWR Trailer Weight Driving system GCWR Rating 11100 lb.
Page 159 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 160 4-1. Before driving Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer cou- pler. Most couplers are stamped with the required trailer ball size.
Page 161 4-1. Before driving Positions for towing hitch receiver and hitch ball Weight carrying ball position: 50.1 in. (1272 mm) Hitch receiver pin hole position: 43.7 in. (1109 mm) Connecting trailer lights Use the wire harness stored in the rear end under body. Please consult your dealer when installing trailer lights, as incorrect installation may cause damage to the vehicle’s lights.
Page 162 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 163 4-1. Before driving ● Avoid jerky starts or sudden acceleration. ● Avoid jerky steering and sharp turns, and slow down before making turn. ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a wider than normal turning radius.
Page 164 4-1. Before driving ● Always place wheel blocks under both the vehicle’s and the trailer’s wheels when parking. Apply the parking brake firmly, and put the transmission in P. Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
Page 165 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 166 4-1. Before driving ● After the trailer swaying has stopped: • Stop in a safe place. Get all occupants out of the vehicle. • Check the tires of the vehicle and the trailer. • Check the load in the trailer. Make sure the load has not shifted.
Page 167 NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
Page 168 4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 169 4-2. Driving procedures Engine (ignition) switch (vehicles without a smart key system) Starting the engine Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal. Turn the engine switch to the “START” position to start the engine. Changing the engine switch positions “LOCK”...
Page 170 ■ If the engine does not start The engine immobilizer system may not have been deactivated. (→P. 70) Contact your Toyota dealer. ■ When the steering lock cannot be released When starting the engine, the engine switch may seem stuck in the “LOCK”...
Page 171 4-2. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver's seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 172 4-2. Driving procedures Engine (ignition) switch (vehicles with a smart key system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is set in P.
Page 173 4-2. Driving procedures Stopping the engine Stop the vehicle. Shift the shift lever to P. Set the parking brake. (→P. 204) Press the engine switch. Release the brake pedal and check that the indicator on the engine switch is off. Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal released.
Page 174 →P. 111 ■ If the engine does not start The engine immobilizer system may not have been deactivated. (→P. 70) Contact your Toyota dealer. ■ Steering lock After turning the engine switch off and opening and closing the doors, the steering wheel will be locked due to the steering lock function.
Page 175 ■ When the engine switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If the electronic key battery is depleted →P. 385 ■...
Page 176 ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 177 4-2. Driving procedures Automatic transmission Shifting the shift lever Vehicles without a smart key system While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 178 4-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the engine Reversing Neutral Normal driving S mode driving (→P. 201) : To improve fuel efficiency and reduce noises, set the shift lever in the D position for normal driving.
Page 179 If the “S” indicator does not come on even after shifting the shift lever to This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 180 4-2. Driving procedures Turn signal lever Operating instructions The lever will return to its original position after operation. Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever. Lane change to the left (push and hold the lever partway) The left hand signals will flash until...
Page 181 4-2. Driving procedures Parking brake To set the parking brake, fully depress the parking brake pedal U.S.A. Canada with your left foot while depress- ing the brake pedal with your right foot. (Depressing pedal again releases the parking brake.) ■ Usage in winter time →P.
Page 182 4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: Type A daytime running lights turn on. The side marker, park- ing, tail, license plate, daytime running lights instrument...
Page 183 4-3. Operating the lights and wipers Type B The headlights, parking lights, daytime running lights and so on turn on automatically (when the engine switch IGNITION mode). The side marker, park- ing, tail, license plate, daytime running lights instrument panel lights turn on.
Page 184 4-3. Operating the lights and wipers Type C daytime running lights turn on. The side marker, park- ing, tail, license plate, daytime running lights instrument panel lights turn on. The headlights and all the lights listed above (except daytime running lights) turn on.
Page 185 4-3. Operating the lights and wipers Type D The headlights, parking lights, daytime running lights and so on turn on automatically (when the engine switch IGNITION mode). The side marker, park- ing, tail, license plate, daytime running lights instrument panel lights turn on.
Page 186 4-3. Operating the lights and wipers ■ Daytime running light system ● To make your vehicle more visible to other drivers, the headlight high beam turn on automatically (at a decreased intensity) whenever the engine is started and the parking brake is released. Daytime running lights are not designed for use at night.
Page 187 4-3. Operating the lights and wipers NOTICE ■ To prevent battery discharge Do not leave the lights on longer than necessary when the engine is not running. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 188 4-3. Operating the lights and wipers Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Type A Turns the front fog lights Turns the front fog lights 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 189 4-3. Operating the lights and wipers Type B Turns the front fog lights Turns the front fog lights ■ Fog lights can be used when The headlights are on in low beam. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 190 4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows. Type A Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent windshield wiper operation Low speed windshield wiper operation...
Page 191 4-3. Operating the lights and wipers Type B Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Wiper intervals can be adjusted when intermittent operation is selected.
Page 192 ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 193 4-3. Operating the lights and wipers Rear window wiper and washer Before operating the rear window wiper and washer switch, make sure the back window is completely closed. (→P. 151) Operating instructions The wiper operation is selected by moving the lever as follows: Type A Intermittent window...
Page 194 4-3. Operating the lights and wipers Type B Intermittent window wiper operation Normal window wiper operation Washer/wiper dual oper- ation Washer/wiper dual oper- ation The wiper will automatically operate a couple of times after the washer squirts. (After operating several times, the wiper operates one more time after a short delay to pre- vent dripping.)
Page 195 ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 196 4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Close all the doors and windows, and turn the engine switch off. ● Confirm the type of fuel. ■...
Page 197 4-4. Refueling CAUTION ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 198 CAUTION ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 199 4-5. Using the driving support systems Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
Page 200 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 201 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 202 4-5. Using the driving support systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 203 4-5. Using the driving support systems ∗ Intuitive parking assist The distance from your vehicle to nearby obstacles when paral- lel parking or maneuvering into a garage is measured by the sensors and communicated via the multi-information display and a buzzer. Always check the surrounding area when using this system.
Page 204 4-5. Using the driving support systems Display When the sensors detect an obstacle, a graphic is shown on the multi- information display depending on the position and distance to the obstacle. Front corner sensor opera- tion Rear corner sensor operation Rear center sensor operation The distance display and buzzer When a sensor detects an obstacle, the direction of and the approxi-...
Page 205 4-5. Using the driving support systems Detection range of the sensors Approximately 2.0 ft. (60 cm) Approximately 4.9 ft. (150 cm) The diagram shows the detection range of the sensors. Note that the sensors cannot detect obstacles that are extremely close to the vehicle.
Page 206 • The area directly under the bumpers is not detected. • If obstacles draw too close to the sensor. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. • People may not be detected if they are wearing certain types of clothing.
Page 207 ■ If a message is displayed on the multi-information display →P. 426 ■ Customization that can be configured at Toyota dealer Settings (e.g. buzzer volume) can be changed. (Customizable features →P. 485) ■ Certification For vehicles sold in the U.S.A.
Page 208 When using intuitive parking assist-sensor In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. ● The intuitive parking assist operation display flashes, and a beep sounds when no obstacles are detected.
Page 209 4-5. Using the driving support systems Four-wheel drive system (part-time 4WD models) Use the front-wheel drive control lever or switch to select the fol- lowing transfer modes: Type A The four-wheel drive indicator comes on when H4, N or L4 mode is selected.
Page 210 4-5. Using the driving support systems Type B The four-wheel drive indicator comes on when H4 or L4 mode is selected. H2 (high speed position, two-wheel drive) Use this for normal driving on dry hard-surfaced roads. This position gives greater economy, quietest ride and least wear. H4 (high speed position, four-wheel drive) Use this for driving only on tracks that permit the tires slide, like off-road, icy or snow-covered roads.
Page 211 4-5. Using the driving support systems Shifting between H2 and H4 ■ Shifting from H2 to H4 Type A Reduce vehicle speed to less than 50 mph (80 km/h). Shift the front-wheel drive control lever to H4. Type B Reduce vehicle speed to less than 62 mph (100 km/h). Push the “UNLOCK”...
Page 212 If the four-wheel drive or low speed four-wheel drive indicator flashes rapidly There may be a malfunction in the four-wheel drive system. Have the vehicle inspected by your Toyota dealer immediately. ■ Four-wheel drive usage frequency You should drive in four-wheel drive for at least 10 miles (16 km) each month.
Page 213 4-5. Using the driving support systems Four-wheel drive system (full-time 4WD models) Use the four-wheel drive control switch to select the following transfer modes: H4F (high speed position) Use this for normal driving on dry hard-surfaced roads. This position gives greater economy, quietest ride and least wear.
Page 214 4-5. Using the driving support systems Shifting between H4F and H4L Push the “UNLOCK” button and turn the four-wheel drive control switch to H4L or H4F. This can be done at any speed. The center differential lock indica- tor will turn on (H4L) or go off (H4F).
Page 215 4-5. Using the driving support systems ■ Shifting from L4L to H4L Stop the vehicle completely and continue to depress the brake pedal. Shift the shift lever to N. Push the “UNLOCK” button and turn the four-wheel drive control switch to H4L. Maintain this condition until the low speed four-wheel drive indi- cator goes off.
Page 216 If the low speed four-wheel drive indicator or the center differential lock indicator flashes rapidly There may be a malfunction in the four-wheel drive system. Have the vehicle inspected by your Toyota dealer immediately. CAUTION ■ Operating the four-wheel drive control switch Never operate the four-wheel drive control switch if the wheels have lost traction.
Page 217 4-5. Using the driving support systems ∗ Active traction control system The active traction control system automatically helps prevent the spinning of 4 wheels when the vehicle is started or acceler- ated on slippery road surfaces. ■ System operation Part-time 4WD models: Stop the vehicle, shift the shift lever to N and shift the front-wheel drive control lever into L4.
Page 218 4-5. Using the driving support systems When the active traction control system is operating If all wheels spin, the slip indicator flashes to indicate that the active traction control system has been engaged. ■ When the rear differential is locked (vehicles with a rear differential lock system) The active traction control system is activated only when vehicle speed is less than 4 mph (6 km/h).
Page 219 4-5. Using the driving support systems AUTO LSD system (2WD models) The AUTO LSD system aids traction by using the traction con- trol system to control engine performance and braking when one of the rear wheels begins to spin. The system should be used only when wheel spinning occurs in a ditch or rough surface.
Page 220 4-5. Using the driving support systems When the AUTO LSD system is operating If the rear wheels spin, the slip indicator flashes to indicate that the AUTO LSD system has con- trolled the spinning of the rear wheels. ■ If the engine is turned off and restarted The AUTO LSD system and the indicators are automatically turned off.
Page 221 4-5. Using the driving support systems ∗ Rear differential lock system The rear differential lock system is provided for use only when wheel spinning occurs in a ditch or on a slippery or rugged sur- face. The rear differential lock system is effective in case one of the rear wheels is spinning.
Page 222 If the rear differential lock indicator flashes rapidly There may be a malfunction in the rear differential lock system. Have the vehicle inspected by your Toyota dealer immediately. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 223 4-5. Using the driving support systems CAUTION ■ To avoid an accident ● Do not use the rear differential lock system except when wheel spinning occurs in a ditch or on a slippery or rugged surface. Large steering effort and careful cornering control will be required. ●...
Page 224 4-5. Using the driving support systems ∗ Downhill assist control system With the downhill assist control system, the vehicle is able to descend a steep hill while maintaining a constant low speed of about 3 mph (5 km/h) without brake pedal operation. ■...
Page 225 4-5. Using the driving support systems While the downhill assist control system is operating The slip indicator will flash to indi- cate that the downhill assist con- trol system is operating, and the stop lights and high mounted stoplight will turn on. ■...
Page 226 “ON” position (vehicles without a smart key system) or the engine switch is turned to IGNITION ON mode (vehicles with a smart key system). Have your vehicle inspected by your Toyota dealer. CAUTION ■...
Page 227 4-5. Using the driving support systems ∗ Crawl Control Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Mini- mizes loss of traction or vehicle slip when driving on slippery road surfaces, allowing for stable driving.
Page 228 4-5. Using the driving support systems ■ Speed modes following table shows some typical terrains and the recommended speed modes. Mode Road condition L (Low) Rock, mogul (downhill) and gravel (downhill) Between L and M Mogul (uphill) M (Medium) Between M and H Snow, mud, gravel (uphill), sand, dirt, mogul (uphill) and grass H (High)
Page 229 4-5. Using the driving support systems ■ Automatic system cancelation In the following situations, the system will cease operation and a buzzer will sound to alert the driver. The Crawl Control indicator will flash until the system is turned off completely. ●...
Page 230 4-5. Using the driving support systems ∗ Multi-terrain Select The Multi-terrain Select system has 4 terrain modes. When a ter- rain mode is selected in accordance with terrain conditions, engine power and active traction control system is controlled to enhance off-road drivability. Additionally, guidance messages such as transfer mode selec- tion advice are displayed on the accessory meter to assist the driver in operating the vehicle.
Page 231 4-5. Using the driving support systems ■ Multi-terrain Select modes Symbol Mode MUD & SAND LOOSE ROCK MOGUL ROCK 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 232 4-5. Using the driving support systems The following table shows some typical terrains and the recom- mended Multi-terrain Select modes. Mode LOOSE MUD & ROCK MOGUL Road ROCK SAND condition Rock Mogul Bump, groove Slope/ V-ditch Uphill/ downhill Riverbed Gravel Bush Deep snow Sand...
Page 233 4-5. Using the driving support systems Selecting modes Press the “ON/OFF” switch. All the mode indicators will come on and then go off except the indi- cator for the present mode. The applicable road conditions will be displayed on the accessory meter. Turn the dial to select the desired mode.
Page 234 4-5. Using the driving support systems Messages displayed on the accessory meter Depending on switch operation, one of the following messages may appear on the accessory meter to provide guidance on transfer mode selection etc: Message Details Procedure SHIFT TO 4WD Indicates that the trans- Shift front-wheel...
Page 235 This may indicate a malfunction in the Multi-terrain Select system. In this case, Multi-terrain Select is automatically canceled. Have your vehicle inspected by your Toyota dealer. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 236 ● One of the vehicle systems related to Multi-terrain Select may be malfunc- tioning. Have your vehicle inspected by your Toyota dealer. ● The brake actuator may be at risk of overheating. A buzzer will sound, the “A-TRAC” indicator will go off and the “TRAC OFF”...
Page 237 4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 238 4-5. Using the driving support systems ◆ Hill-start assist control (if equipped) Helps to prevent the vehicle from rolling backward when starting on an incline or slippery slope ◆ LSD (Limited Slip Differential) (if equipped) Transfers drive power to the rear tires when front tires spin, and vice versa, in order to improve traction ◆...
Page 239 4-5. Using the driving support systems Disabling the TRAC/VSC/Trailer Sway Control systems (2WD models) If the vehicle gets stuck in fresh snow or mud, the TRAC/VSC/Trailer Sway Control systems may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
Page 240 4-5. Using the driving support systems ■ Turning off TRAC, VSC and Trailer Sway Control systems To turn the TRAC, VSC and Trailer Sway Control systems off, press and hold the switch for more than 3 seconds while the vehicle is stopped. The “TRAC OFF”...
Page 241 4-5. Using the driving support systems Disabling the TRAC/VSC/Trailer Sway Control systems (4WD models) If the vehicle gets stuck in fresh snow or mud, the TRAC/VSC/Trailer Sway Control systems may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
Page 242 4-5. Using the driving support systems ■ Turning off TRAC, VSC and Trailer Sway Control systems To turn the TRAC, VSC and Trailer Sway Control systems off, press and hold the switch for more than 3 seconds while the vehicle is stopped. The “TRAC OFF”...
Page 243 When the “TRAC OFF” indicator light comes on even if the VSC off switch has not been pressed TRAC, hill-start assist control, downhill assist control and Crawl Control can- not be operated. Contact your Toyota dealer. ■ Hill-start assist control operation conditions ●...
Page 244 4-5. Using the driving support systems ■ Reactivation of the VSC and Trailer Sway Control system linked to vehi- cle speed (2WD models) When the TRAC system is turned off and the AUTO LSD system is turned on, the VSC and Trailer Sway Control system will turn on when vehicle speed increases.
Page 245 The ABS, Multi Terrain ABS, VSC and Trailer Sway Control will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■...
Page 246 4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 247 4-6. Driving tips Before driving the vehicle Perform the following according to the driving conditions: ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
Page 248 4-6. Driving tips Selecting tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain (0.20 in. [5 mm] in diameter) Cross chain (0.20 in. [5 mm] in diameter) Regulations on the use of tire chains Regulations regarding the use of tire chains vary depending on loca- tion and type of road.
Page 249 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 250 4-6. Driving tips Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications. Off-road vehicle feature ●...
Page 251 4-6. Driving tips CAUTION ■ Off-road vehicle precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 252 4-6. Driving tips Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the clo- sure of areas to off-road vehicles: ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 253 4-6. Driving tips CAUTION ■ Off-road driving precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 254 4-6. Driving tips NOTICE ■ To prevent water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
Page 255 4-6. Driving tips 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 256 5-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Air conditioning controls ■ Adjusting the temperature setting To adjust the temperature setting, turn clockwise (warm) or counterclockwise (cool). is not pressed, the system will blow ambient temperature air or heated air.
Page 257 5-1. Using the air conditioning system and defogger ■ Fan speed setting To adjust the fan speed, turn clockwise (increase) or coun- terclockwise (decrease). Turning the knob to “OFF” turns off the fan. ■ Change the airflow mode To select the air outlets, set to the desired position.
Page 258 5-1. Using the air conditioning system and defogger ■ Defogging the windshield Defoggers are used to defog the windshield and front side win- dows. Set the air outlet selector dial to position. If the recirculated air mode is used, it will automatically switch to outside air mode.
Page 259 5-1. Using the air conditioning system and defogger Air outlets ■ Location of air outlets The air outlets and air volume changes according selected airflow mode. ■ Adjusting the position of and opening and closing the air out- lets Front center outlets Front side outlets Rear outlets Direct air flow to the left or right, up or down.
Page 260 There may be a problem in the air conditioning system if the indicator light continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 261 5-1. Using the air conditioning system and defogger ■ When the outside temperature falls to nearly 32°F (0°C) The dehumidification function may not operate even when is pressed. ■ Air conditioning odors ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 262 5-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls ■ Adjusting the temperature setting To adjust the temperature setting, turn clockwise to increases the temperature and turn counterclockwise to...
Page 263 5-1. Using the air conditioning system and defogger ■ Change the airflow mode To change the air outlets, press ■ Other functions ● Switching between outside air and recirculated air modes (→P. 288) ● Defogging the windshield (→P. 288) ● Defogging the rear window and outside rear view mirrors (→P.
Page 264 5-1. Using the air conditioning system and defogger Other functions ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (the indicator is off) and recirculated air mode (the indicator is on) each time the button is pressed.
Page 265 5-1. Using the air conditioning system and defogger ■ Windshield wiper de-icer (if equipped) This feature is used to prevent ice from building up on the wind- shield and wiper blades. Turns the windshield wiper de- icer on/off The windshield wiper de-icer will automatically turn after...
Page 266 5-1. Using the air conditioning system and defogger Rear outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions.
Page 267 There may be a problem in the air conditioning system if the indicator light continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ Air conditioning odors ●...
Page 268 5-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, block- ing your vision.
Page 269 5-1. Using the air conditioning system and defogger ∗ ∗ Seat heaters /seat ventilators The seat heaters warm the seats and the seat ventilators main- tain good airflow by blowing air through the seats. CAUTION ● Care should be taken to prevent injury if anyone in the following categories comes in contact with the seats when the heater is on: •...
Page 270 5-1. Using the air conditioning system and defogger Seat heaters/ventilators Vehicles with ventilator Press the knob to release it, and turn the knob to the desired temperature setting. Press the knob to lock it when not in use. Ventilation Heat Vehicles without ventilator The indicator light comes on.
Page 271 5-2. Using the interior lights Interior lights list Rear interior light (→P. 296) Front interior light/front personal lights (→P. 296) Shift lever light (when the engine switch is in the “ACC” or “ON” position [without a smart key system] or the engine switch is in ACCESSORY or IGNITION ON mode [with a smart key system]) Inside door handle lights (if equipped) Outer foot lights (if equipped)
Page 272 5-2. Using the interior lights Interior lights ■ Front Turns the lights off Turns the door position on ■ Rear Turns the door position on Turns the light off Turns the light on Personal lights Turns the lights on/off 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 273 5-2. Using the interior lights ■ Illuminated entry system Vehicles without a smart key system The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are open/ closed. Vehicles with a smart key system The lights automatically turn on/off according to engine switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed.
Page 274 5-3. Using the storage features List of storage features Auxiliary box (→P. 302) Cup holders (→P. 303) Glove box (→P. 299) Pen holder (→P. 303) Bottle holders (→P. 304) Console box (→P. 299) Tissue pocket (→P. 303) Coin holder (→P. 303) CAUTION ●...
Page 275 5-3. Using the storage features Glove box The glove box can be opened by pressing the lock release button and can be locked and unlocked by using the master key (vehicles without a smart key system) or the mechanical key (vehicles with a smart key system).
Page 276 5-3. Using the storage features Cup holders Front seats Rear seats (without third row seats) Pull down the rear seat center armrest. Second row seats (with third Third row seats (if equipped) row seats) Pull down the second row seat center armrest and press down the button on the armrest.
Page 277 5-3. Using the storage features ■ Adjusting the size of the cup holders Front seats Remove the adapter. Rear seats (without third row seats) Remove the adapter. CAUTION ■ Items unsuitable for the cup holders Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
Page 278 5-3. Using the storage features Auxiliary box (If equipped) Push the lid. CAUTION ■ Items unsuitable for storing Do not store items heavier than 0.4 lb. (0.2 kg). Doing so may cause the auxiliary box to open and the items inside may fall out, resulting in an accident.
Page 279 5-3. Using the storage features Coin holder/tissue pocket/pen holder Lift the lid while pulling up the knob to release the lock. Coin holder Tissue pocket Pen holder 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 280 5-3. Using the storage features Bottle holders Front seats Rear seats (without third row seats)/second row seats (with third row seats) ■ When using the bottle holder ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. CAUTION ■...
Page 281 5-3. Using the storage features Luggage compartment features ■ Cargo hooks Vehicles with third seats Fold down the third seats. (→P. 131) Raise the hook to use. The cargo hooks are provided for securing loose items. Vehicles without third seats Raise the hook to use.
Page 282 5-3. Using the storage features ■ Cargo net hooks The cargo net itself is not included as original equipment. Vehicles with third seats (pattern 1) Raise the rear cargo hook to use. Vehicles with third seats (pattern 2) Fold down the third seats. (→P. 131) Raise the cargo hook to use.
Page 283 5-3. Using the storage features Vehicles without third seats (pattern 2) Raise the cargo hook to use. ■ Storage compartment Type A (if equipped) Type B (if equipped) Open the storage compartment as shown. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 284 5-3. Using the storage features ■ Slide deck (if equipped) Slide the deck while turning the lock release lever, and then release the lever after sliding the deck to the lock position. Half-slide locked position Full-slide locked position ■ Grocery bag hooks Type A Type B (if equipped) Type B only: To use the grocery bag hooks, slide the slide deck to...
Page 285 5-3. Using the storage features CAUTION ■ When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their stowed positions. ■ Slide deck operating precaution (if equipped) ● Be careful not to get hands or feet pinched by the slide deck. ●...
Page 286 5-4. Other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 287 5-4. Other interior features Clock The clock can be adjusted by pressing the buttons. Adjusts the hours Adjusts the minutes ■ For quicker adjustment of the clock (Vehicles with Multi-terrain Select only) To advance the minutes and hours quickly, press and hold the “M” or “H” but- ton.
Page 288 5-4. Other interior features Outside temperature display The temperature display shows temperatures within the range of -40°F (-40°C) to 122°F (50°C). If equipped ■ The outside temperature is displayed when Vehicles without a smart key system The engine switch is in the “ON” position. Vehicles with a smart key system The engine switch is in IGNITION ON mode.
Page 289 5-4. Other interior features ■ Ice indicator If the outside temperature lowers to 37°F (3°C) or below when the engine switch is in the “ON” position (vehicles without a smart key system) or the engine switch is in IGNITION ON mode (vehicles with a smart key system), the indicator will come on to warn the driver that roads may be icy.
Page 290 5-4. Other interior features Power outlets (120 V AC) (If equipped) The power outlet can be used for electrical appliances. Main switch To use the power outlet, turn on the main switch. The power supply starts a few seconds after the main switch is pressed.
Page 291 5-4. Other interior features ■ The power outlet can be used when The engine is running. ■ The indicator light changes according to the maximum available capac- ity as follows: 120 V AC/400 W 120 V AC/100 W ■ When the power outlet is in operation The sound of the cooling fan may be heard from the right side of the luggage compartment.
Page 292 If the power supply does not resume even after the above procedure has been performed, have the vehicle inspected by your Toyota dealer. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 293 Do not modify, disassemble or repair the power outlet or its inverter in any way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact your Toyota dealer for any necessary repairs. ■...
Page 294 5-4. Other interior features NOTICE ■ To avoid damaging the power outlet and the plug ● Close the power outlet lid when not in use. ● Do not allow foreign objects or liquids to enter the power outlet, as this may cause a short circuit.
Page 295 ■ If the power outlet is loose when an electrical appliance plug is con- nected Replace the outlet. Contact your Toyota dealer for any necessary replace- ments. ■ If the power outlet gets dirty Turn the main switch off and use a soft, clean cloth to wipe it gently.
Page 296 5-4. Other interior features Console box (inside) Lift the lid while pulling up the knob to release the lock. Open the lid. Luggage compartment (vehi- Luggage compartment (vehi- cles without the 120 V AC) cles with the 120 V AC) Open the lid.
Page 297 5-4. Other interior features ■ The power outlets can be used when Vehicles without a smart key system The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system The engine switch is in ACCESSORY or IGNITION ON mode. NOTICE ■...
Page 298 5-4. Other interior features Assist grips An assist grip (type A) installed on the ceiling can be used to support your body while sitting on the seat. An assist grip (type B) installed on the pillar can be used when get- ting in or out of the vehicle and others.
Page 299 5-4. Other interior features ∗ Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manu- ®...
Page 300 5-4. Other interior features ® ■ Programming HomeLink Point remote control transmitter for the device 1 to 3 in. (25 to 75 mm) from the ® HomeLink buttons. ® Keep the HomeLink indicator light in view while programming. For U.S.A. owner’s Press hold ®...
Page 301 5-4. Other interior features ® Test the HomeLink operation by pressing the newly pro- grammed button and observing the indicator light: ● If the indicator light is solid/continuous, programming has been completed and your device should activate when the ® HomeLink button is pressed and released.
Page 302 5-4. Other interior features Press and hold the pro- ® grammed HomeLink button (located inside the vehicle) for 2 seconds and release it. Repeat this sequence (press/ hold/release) up to 3 times to complete programming. If the garage door opener motor ®...
Page 303 5-4. Other interior features ® Operating HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator light should turn on. Garage door operation indicators The status of the opening and closing of a garage door is shown by the indicators. Opening Closing This function is only available if the...
Page 304 5-4. Other interior features ® Erasing the entire HomeLink memory (all three programs) Press and hold the 2 outside but- tons for 10 seconds until the ® HomeLink indicator light changes from continuously lit (orange) rapidly flashing (green). If you sell your vehicle, be sure to erase the programs stored in the ®...
Page 305 5-4. Other interior features CAUTION ■ When programming a garage door or other remote control device The garage door may operate, so ensure people and objects are out of dan- ger to prevent potential harm. ■ Conforming to federal safety standards ®...
Page 306 Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Connect service is subject to such then-applicable Terms and Conditions.
Page 307 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection availabil- ity, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 308 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunction (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services ■...
Page 309 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. ■ Emergency Assistance Button (“SOS”) In the event of an emergency on the road, push the “SOS”...
Page 310 5-4. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. ■ Exposure to radio frequency signals The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 311 5-4. Other interior features ∗ Compass The compass on the accessory meter display indicates the direction in which the vehicle is heading. “MODE/ ” button “SET/ ” button Direction display ■ Displays and directions Display Direction “N” North “NE” Northeast “E”...
Page 312 5-4. Other interior features Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies depending on the geographic position of the vehicle. If you cross over one of the map boundaries shown in illustration, the com- pass will deviate.
Page 313 5-4. Other interior features ■ Deviation calibration Stop the vehicle. Change the accessory meter display to deviation calibration mode by doing the following. When the parking lights are turned on: Press and hold the “MODE/ ” button. A number (1 to 15) will appear on the display.
Page 314 5-4. Other interior features ■ Circling calibration If “•” appears on the left side of the direction display, circling calibration needs to be per- formed. Stop the vehicle in a place where it is safe to drive in a circle. In deviation calibration mode (→P.
Page 315 5-4. Other interior features ■ Conditions unfavorable to correct operation The compass may not show the correct direction in the following conditions: ● The vehicle is stopped immediately after turning. ● The vehicle is on an inclined surface. ● The vehicle is in a place where the earth's magnetic field is subject to inter- ference by artificial magnetic fields (underground car park/parking lot, under a steel tower, between buildings, roof car park/parking lot, near an intersec- tion, near a large vehicle, etc.).
Page 316 5-4. Other interior features NOTICE ■ To avoid compass malfunctions Do not place magnets or any metal objects near the accessory meter dis- play. Doing this may cause the compass sensor to malfunction. ■ To ensure normal operation of the compass ●...
Page 317 6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 318 6-1. Maintenance and care ■ Bumpers and side moldings Do not scrub with abrasive cleaners. CAUTION ■ When washing the vehicle Do not apply water to the inside of the engine compartment. Doing so may cause the electrical components etc. to catch fire. ■...
Page 319 6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 320 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 321 6-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 322 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 323 Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 324 “Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 325 6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Automatic transmis- • When parked on a slope and the shift lever is in P, sion “Park” mecha- is the vehicle securely stopped? nism •...
Page 326 6-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? Engine hood • Does the engine hood lock system work properly? • There should not be any signs of fluid leakage Fluid leaks after the vehicle has been parked. •...
Page 327 The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 328 (→P. 364) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non-amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology For the U.S.A.:...
Page 329 6-3. Do-it-yourself maintenance Items Parts and tools Fuses (→P. 388) • Fuse with same amperage rating as original • Bulb with same number and wattage rating as original Light bulbs (→P. 391) • Phillips-head screwdriver • Flathead screwdriver • Wrench ®...
Page 330 6-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 331 6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Push the auxiliary catch lever to the left and lift the hood. CAUTION ■...
Page 332 6-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (→P. 370) Brake fluid reservoir (→P. 364) Power steering fluid reservoir (→P. 366) Fuse box (→P. 388) Engine oil level dipstick Battery (→P. 367) (→P. 359) Condenser (→P. 363) Engine coolant reservoir Radiator (→P.
Page 333 6-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment cover ■ Installing the clips Push up center portion Insert Press NOTICE ■ After installing an engine compartment cover Make sure that the cover is securely installed in its original position. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 334 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 335 6-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 336 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 337 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. 4RUNNER (U)_(OM35A83U)
Page 338 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION ■...
Page 339 6-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. “MAX” line “MIN” line ■ Adding fluid Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items...
Page 340 6-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the brake fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. CAUTION ■ When filling the reservoir Take care as brake fluid can harm your hands and eyes and damage painted surfaces.
Page 341 6-3. Do-it-yourself maintenance Power steering fluid ■ Fluid level The fluid level should be within the appropriate range. Full (when cold) Add fluid (when cold) Full (when hot) Add fluid (when hot) Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 min- utes, or slightly longer in frigid temperatures.
Page 342 6-3. Do-it-yourself maintenance CAUTION ■ When checking the reservoir Take care as the reservoir may be hot. NOTICE ■ When adding fluid Avoid overfilling, or the power steering may be damaged. ■ After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
Page 343 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer. CAUTION ■...
Page 344 6-3. Do-it-yourself maintenance CAUTION ■ Where to safely charge the battery Always charge the battery in an open area. Do not charge the battery in a garage or closed room where there is insufficient ventilation. ■ How to recharge the battery Only perform a slow charge (5 A or less).
Page 345 6-3. Do-it-yourself maintenance Washer fluid Type A If any washer does not work or the low washer fluid warning light comes on, the washer tank may be empty. Add washer fluid. Type B If the washer fluid level is at “LOW”, add washer fluid.
Page 346 6-3. Do-it-yourself maintenance CAUTION ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■ Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid.
Page 347 Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the Front same interval as tire inspection. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 348 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 349 6-3. Do-it-yourself maintenance ■ Routine tire inflation pressure checks The tire pressure warning system does not replace routine tire inflation pressure checks. Make sure to check tire inflation pressure as part of your routine of daily vehicle checks. ■ Maximum load of tire Check that the number given by dividing the maximum load by 1.10 of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater.
Page 350 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 351 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 352 6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (→P. 473) 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 353 ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 354 6-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 355 ● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 356 6-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 357 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 358 6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch off. Open glove remove the cover. Remove the filter cover. Remove the air conditioning fil- ter and replace it with a new one.
Page 359 6-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Schedule maintenance guide”...
Page 360 6-3. Do-it-yourself maintenance Wireless remote control/electronic key bat- tery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2016 (vehicles without a smart key system), or CR1632 (vehicles with a smart key system) Replacing the battery (vehicles without a smart key system) Remove the cover.
Page 361 6-3. Do-it-yourself maintenance Replacing the battery (vehicles with a smart key system) Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a rag. Remove the depleted battery. Insert a new battery with the “+” terminal facing up.
Page 362 Use a CR2016 (vehicles without a smart key system) or CR1632 (vehicles with a smart key system) lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer.
Page 363 6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch off. Open the Fuse box cover. Engine compartment Push the tab in and lift the lid off.
Page 364 Type A, B, C, D, E: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type F: Contact your Toyota dealer. Type A Type B Type C...
Page 365 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (→P. 391) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 366 Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (→P. 469) 4RUNNER (U)_(OM35A83U)
Page 367 6-3. Do-it-yourself maintenance Bulb locations ■ Front Headlight low beam Front turn signal/parking light Headlight high beam/day- time running light Front side marker light Fog light ■ Rear Rear turn signal light Back-up light License plate light 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 368 6-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight low beams Turn the cover counterclock- wise and remove it. Turn the bulb base counter- clockwise. Unplug the connector while pulling the lock release. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 369 6-3. Do-it-yourself maintenance Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting and insert. Turn and secure the bulb base. Shake the bulb base gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting.
Page 370 6-3. Do-it-yourself maintenance ■ Headlight high beam/daytime running lights Turn the bulb base counter- clockwise. Pull the bulb out while press- ing the lock release of the connector. Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting and insert.
Page 371 6-3. Do-it-yourself maintenance ■ Front turn signal/parking light Turn the steering wheel in the opposite direction of the front turn signal light and parking light that you wish to replace. For example, if you wish to replace the front turn signal light and parking light on the right side, turn the steering wheel to the left.
Page 372 6-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 373 6-3. Do-it-yourself maintenance ■ Front side marker lights Turn the steering wheel in the opposite direction of the front side marker light that you wish to replace. For example, if you wish to replace the front side marker light on the right side, turn the steering wheel to the left.
Page 374 6-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 375 6-3. Do-it-yourself maintenance ■ Fog light (left side) Turn the steering wheel in the opposite direction of the fog light that you wish to replace. For example, if you wish to replace the fog light on the left side, turn the steering wheel to the right.
Page 376 6-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Install a new light bulb. Align the 3 tabs on the light bulb with the mounting and insert. Turn clockwise and secure the bulb base. Install the connector. Shake the connector gently to check that it is not loose, turn the front fog lights on once and visually confirm that no light is...
Page 377 6-3. Do-it-yourself maintenance ■ Rear turn signal lights Open the back door and remove the cover. To prevent damage to the vehi- cle, cover the tip of the screw- driver with a rag. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 378 6-3. Do-it-yourself maintenance ■ Back-up lights Open the back door and remove the cover. To prevent damage to the vehi- cle, cover the tip of the screw- driver with a rag. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 379 6-3. Do-it-yourself maintenance ■ License plate lights Remove the screws and lens. Remove the light bulb. When installing, reverse the steps listed. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 380 The side turn signal lights, stop/tail lights, rear side marker lights, high mounted stoplight and outer foot lights consist of a number of LEDs. If any LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 381 6-3. Do-it-yourself maintenance 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 382 7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signals will flash. To turn them off, press the switch once again.
Page 383 7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 384 7-1. Essential information CAUTION ■ If the engine has to be turned off while driving ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 385 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 386 7-2. Steps to take in an emergency Vehicles with front covers only: Before using the front emergency towing eyelet(s), remove cover(s). Removing the clips Installing the clips Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 387 7-2. Steps to take in an emergency Towing with a wheel-lift type truck From the front Use a towing dolly under the rear wheels. From the rear (2WD models) Vehicles without a smart key system: Turn the engine switch to the “ACC” position so that the steering wheel is unlocked.
Page 388 7-2. Steps to take in an emergency Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be dam- aged.
Page 389 7-2. Steps to take in an emergency CAUTION ■ Caution while towing ● Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelets and the cables or chains. Always be cautious of the surroundings and other vehicles while towing.
Page 390 7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 391 7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 392 • The electronic engine control system; (U.S.A.) • The electronic throttle control system; or • The electronic automatic transmission control sys- → Have the vehicle inspected by your Toyota dealer (Canada) immediately. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 393 Indicates a malfunction in: • The SRS airbag system; • The front passenger occupant classification system; • The seat belt pretensioner system → Have the vehicle inspected by your Toyota dealer immediately. ABS warning light Indicates a malfunction in: (U.S.A.) •...
Page 394 Warning light/Details/Actions Low speed four-wheel drive indicator light (if equipped) Indicates a malfunction in the four-wheel drive system → Have the vehicle inspected by your Toyota dealer (Flashes rapidly) immediately. Center differential lock indicator light (if equipped) Indicates a malfunction in the four-wheel drive system →...
Page 395 When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system (→P. 423) → Have the system checked by your Toyota dealer. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 396 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. 4RUNNER (U)_(OM35A83U)
Page 397 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings ● If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 398 Check the tires. If a tire is flat, change it with the spare tire and have the flat tire repaired by the nearest Toyota dealer. ● Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
Page 399 7-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warn- ing system) malfunction indicator to indicate when the system is not operating properly. The TPMS (tire pressure warning system) malfunc- tion indicator is combined with the low tire pressure telltale (tire pressure warning light).
Page 400 Multi-information display If any of the warning message or indicator comes on again after the following actions have been performed, contact your Toyota dealer. Warning message and warning buzzer list Warning message Details/Actions Indicates a malfunction in the steering lock sys- A buzzer also sounds.
Page 401 IGNITION ON mode and then back to IGNITION ON mode, the buzzer will sound and this message will be displayed again. → Have the vehicle inspected by your Toyota dealer. Indicates that one or more of the doors is not fully...
Page 402 7-2. Steps to take in an emergency Warning message Details/Actions Indicates that an intuitive parking assist-sensor is dirty or covered with ice The site of the malfunction flashes and stays A buzzer will sound for several seconds and this warning message will disappear after sev- eral seconds.
Page 403 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer electronic detected when an attempt is ⎯ Once made to start the engine. → Start the engine with the (Flashes) electronic key present. The electronic key was carried outside the vehicle and a door other than the driver’s door was opened and closed while the...
Page 404 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The driver’s door was opened and closed while the electronic key was not in the vehicle, the Con- Con- shift lever was not in P and the (Displayed alternately) tinu- tinu-...
Page 405 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to start the engine with the shift lever in ⎯ Once an incorrect position. → Shift the shift lever to P and start the engine. (Flashes) Power was turned off due to the automatic power off function.
Page 406 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The steering lock could not be released within 3 seconds of engine switch being pressed. ⎯ → Press the engine switch Once while depressing the brake pedal moving (Flashes)
Page 407 7-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare tire provided. For details about tires: →P. 372 CAUTION ■ If you have a flat tire Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair, which could result in an accident.
Page 408 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Spare tire Jack Tool bag 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 409 7-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 410 7-2. Steps to take in an emergency Taking out the jack and tool bag Remove the cover. Unhook and take out the tool bag. Take out the jack. For loosening For tightening 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 411 7-2. Steps to take in an emergency Taking out the spare tire Assembling the jack handle. Remove the jack handle and the jack handle extension bar from the tool bag and assembly by following these steps. Loosen the bolt and the screw using either the jack handle or a screwdriver.
Page 412 7-2. Steps to take in an emergency Insert the end of the jack han- dle extension into the lowering screw and turn it counterclock- wise. Lower the spare tire completely to the ground. Pull out the spare tire and remove the holding bracket. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 413 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 414 7-2. Steps to take in an emergency Assembling the jack handle. Remove the jack handle, jack handle extension bar and jack handle bar from the tool bag and assemble by following these steps. Loosen the bolts and the screw using either the jack handle or a screwdriver.
Page 415 7-2. Steps to take in an emergency Position the jack at the jack points as shown. Front - Under the chassis frame side rail Rear - Under the rear axle housing Raise the vehicle until the tire is slightly raised off the ground. When positioning the jack under the rear axle housing, make sure the groove on the top of the jack...
Page 416 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 417 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 418 7-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 81 ft•lbf (110 N•m, 11.2 kgf•m) Stowing the flat/spare tire, jack and tools Lay down the tire with the outer side facing up, and install the holding bracket.
Page 419 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 420 7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (→P. 192, 195), consider each of the fol- lowing points: The engine will not start even though the starter motor operates normally.
Page 421 ● There may be a malfunction in the steering lock system (vehicles with a smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with a smart key system)
Page 422 (a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.
Page 423 If the back door opener does not operate, there may be a prob- lem with the back door opener system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the back door can be opened from the inside.
Page 424 Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 425 7-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to P and press the engine switch as you normally do when stopping the engine. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 426 The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 427 IGNITION ON mode (vehicles with a smart key system). Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. ■...
Page 428 7-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 429 (radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir.
Page 430 Start the engine and check that the radiator cooling fan operate and to check for coolant leaks from the radiator or hoses. If the fan are not operating: Stop the engine immediately and contact your Toyota dealer. If the fan are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 431 7-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine. ■...
Page 432 7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the stuck tire.
Page 433 8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 189.8 in. (4820 mm) Overall width 75.8 in. (1925 mm) Overall height 70.1 in. (1780 mm) Wheelbase 109.8 in. (2790 mm) Front 63.2 in. (1605 mm) Tread Rear 63.2 in.
Page 434 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 435 8-1. Specifications Engine Model 1GR-FE Type 6-cylinder V type, 4-cycle, gasoline 3.70 × 3.74 in. (94.0 × 95.0 mm) Bore and stroke Displacement 241.4 cu.in. (3956 cm Valve clearance Automatic adjustment (engine cold) Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only 87 (Research octane number 91) or Octane rating...
Page 436 ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 437 CTH61AS018 Cooling system Capacity 11.1 qt. (10.5 L, 9.2 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol- based non-silicate, non-amine, non- Coolant type nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 438 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 439 Oil type and viscosity 75W-85 GL-5 or equivalent : Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 440 Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of the transmission accompanied by vibration and, ultimately, damage to the vehicle’s transmission. Brakes Pedal clearance 3.62 in.
Page 441 8-1. Specifications Chassis lubrication Spider Lithium base chassis grease, NLGI No.2 Molybdenum-disulfide lithium base chas- Propeller shafts Slide yoke sis grease, NLGI No.2 or lithium base chassis grease, NLGI No.2 Steering Free play Less than 1.2 in. (30 mm) ® Automatic transmission fluid DEXRON Power steering fluid type or III...
Page 442 8-1. Specifications Light bulbs Light bulbs Bulb No. Type Headlights and daytime run- ning lights ⎯ Low beam High beam 9005 Front turn signal and parking 7444NA 28/8 lights Exterior ⎯ Front side marker lights ⎯ Fog lights ⎯ Rear turn signal lights ⎯...
Page 443 In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 444 ■ Recommendation of the use of gasoline containing detergent additives ● Toyota recommends the use of gasoline that contains detergent additives to avoid the build-up of engine deposits. ● All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or keep clean intake systems, per EPA's lowest additives concen- tration program.
Page 445 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 446 8-1. Specifications Tire information Typical tire symbols Tire size (→P. 475) Summer tires or all season tires (→P. 374) An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire. Uniform tire quality grading For details, see “Uniform Tire Quality Grading”...
Page 447 8-1. Specifications Load limit at maximum cold tire inflation pressure (→P. 479) Maximum cold tire inflation pressure (→P. 479) This means the pressure to which a tire may be inflated. TUBELESS or TUBE TYPE A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire has a tube inside the tire and the tube maintains the air pressure.
Page 448 8-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol (alphabet with one letter)
Page 449 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 450 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
Page 451 8-1. Specifications ■ Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 452 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
Page 453 8-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim A metal support for a tire or a tire and tube...
Page 454 8-1. Specifications Tire related term Meaning A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass rubber which, when inflated, bears the load The breaking away of pieces of the tread or...
Page 455 8-1. Specifications Tire related term Meaning A tire designated by its manufacturer as pri- Light truck (LT) tire marily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry Load rating for a given inflation pressure The load rating for a tire at the maximum per- Maximum load rating...
Page 456 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 457 8-1. Specifications Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
Page 458 Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. ■ Smart key system and wireless remote control (→P. 100, 107)
Page 459 8-2. Customization ■ Wireless remote control (→P. 100) Customized Function Default setting setting Wireless remote control Panic function Operation signal (Buzzer vol- Level 7 OFF to level 6 ume) ■ Door lock (→P. 100, 450) Customized Function Default setting setting Speed-detecting automatic door lock function...
Page 460 8-2. Customization ■ Automatic light control system (→P. 205) Customized Function Default setting setting Light sensor sensitivity Level 3 Levels 1 to 5 Time elapsed before head- lights automatically turn off 30 seconds 60 seconds after doors are closed 90 seconds Ambient light level at which -2 (darker) to instrument illumination begins...
Page 461 8-2. Customization ■ Outer foot lights (if equipped) (→P. 295) Customized Function Default setting setting Vehicles with a smart key sys- tem: Operation when approach the vehicle with the electronic key on your person Operation when the doors are unlocked using the wireless remote control, key or entry function Operation when the doors are...
Page 462 8-2. Customization ■ Rear window wiper and washer (→P. 216) Customized Function Default setting setting Wiper operates automatically when washer is operated Drip prevention function 2 seconds Wiper operation interval 3 seconds 4 seconds 5 seconds 4 seconds Time elapsed before the rear wiper storage function acti- 3 seconds 5 seconds...
Page 463 8-2. Customization ■ Intuitive parking assist (→P. 226) Customized Function Default setting setting Buzzer volume Max. Min. to Max. ■ Driving position memory (→P. 135) Customized Function Default setting setting Selecting the door linking driv- ing position memory with door Driver’s door All doors unlock operation...
Page 464 8-3. Items to initialize Items to initialize The following item must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference After the maintenance is per- Maintenance data P.
Page 465 8-3. Items to initialize 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 466 National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800- 331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 467 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 468 CAUTION ■ Détérioration et usure des ceintures de sécurité Inspectez les ceintures de sécurité périodiquement. Contrôlez qu’elles ne sont pas entaillées, effilochées et que leurs ancrages ne sont pas desser- rés. N’utilisez pas une ceinture de sécurité défectueuse avant qu’elle ne soit remplacée.
Page 469 SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. ◆...
Page 470 ◆ Coussins gonflables latéraux et rideaux SRS Coussins gonflables latéraux SRS Participent à la protection du torse des passagers du siège avant Coussins gonflables rideaux SRS ● Participent principalement à la protection de la tête des occu- pants assis aux places extérieures ●...
Page 471 Composition du système de coussins gonflables SRS Coussins gonflables laté- Commutateur de boucle de raux ceinture de sécurité du siège du passager avant Témoins indicateurs “AIR Système de classification BAG ON” et “AIR BAG OFF” de l’occupant du siège pas- sager avant (ECU et cap- Coussins gonflables...
Page 472 Votre véhicule est équipé de COUSSINS GONFLABLES INTELLI- GENTS conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique (ECU) des coussins gonflables régule le déploiement de ces derniers sur la base des informations qu’il reçoit des capteurs, etc., indiqués ci-des- sus dans le schéma illustrant les composants du système.
Page 473 CAUTION ■ Précautions avec le coussin gonflable SRS Respectez les précautions suivantes avec les coussins gonflables SRS. Autrement, des blessures graves, voire mortelles, pourraient s’ensuivre. ● Le conducteur et les passagers du véhicule doivent porter correctement leur ceinture de sécurité. Les coussins gonflables SRS sont des dispositifs supplémentaires à...
Page 474 être grièvement blessés ou tués par le déploiement d’un coussin gonflable. Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Toyota recom- mande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement attachés.
Page 475 CAUTION ■ Précautions avec le coussin gonflable SRS ● Ne vous asseyez pas sur le bord du siège et ne vous appuyez pas contre le tableau de bord. ● Ne laissez pas un enfant se tenir debout devant le coussin gonflable pas- sager avant SRS ou bien s’asseoir sur les genoux du passager avant.
Page 476 CAUTION ■ Précautions avec le coussins gonflable SRS ● Ne rien fixer aux portes, à la vitre du pare-brise, aux vitres latérales, aux montants avant et arrière, au rail latéral de toit et à la poignée d’assistance. ● Véhicules dépourvus système d’accès “mains libres”: ne fixez pas des objets lourds, pointus ou très durs,...
Page 477 Si les parties renfermant les coussins gonflables SRS, telles que la garni- ture du volant et les garnitures de montants avant et arrière, sont abîmées ou craquelées, faites-les remplacer par votre concessionnaire Toyota. ■ Modification et mise au rebut des éléments du système de coussins gonflables SRS Consultez impérativement votre concessionnaire Toyota si vous avez...
Page 478 4RUNNER (U)_(OM35A83U) I n f o r ma t i o n P r o v i d e d b y :...
Page 479 You lose your keys ● If you lose your keys or mechanical keys, new genuine mechanical keys can be made by your Toyota dealer. (→P. 97) ● If you lose your keys or electronic keys, the risk of vehicle theft increases significantly.
Page 480 What to do if... (Troubleshooting) The rear door cannot be opened ● Is the child-protector lock set? The rear door cannot be opened from inside the vehicle when the lock is set. Open the rear door from outside and then unlock the child-protector lock.
Page 481 What to do if... (Troubleshooting) If you think something is wrong The engine does not start (vehicles without a smart key system) ● Is the shift lever in P? (→P. 192) ● Is the steering wheel unlocked? (→P. 192) ● Is the battery discharged? (→P.
Page 482 What to do if... (Troubleshooting) The steering wheel cannot be turned after the engine is stopped ● Vehicles without a smart key system: It is locked to prevent theft of the vehicle if the key is pulled from the engine switch.
Page 483 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and the front passenger wearing the seat belts? (→P. 421) ● The brake system warning light is on Is the parking brake released? (→P.
Page 484 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (→P. 433) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 485 Alphabetical index Alphabetical index Alarm .......... 72 A/C ........280, 286 Alarm ........72 Air conditioning filter ..... 383 Warning buzzer ....418 Anchor brackets ......57 (Anti-lock Brake System)..260 Antennas Function ........ 260 (smart key system) ....107 Warning light......
Page 486 Alphabetical index Back door Care ........342, 344 Back door......117 Aluminum wheels ....342 Back window......151 Exterior ......... 342 Smart key system ....107 Interior ........344 Wireless remote control ..100 Seat belts......345 Back-up lights Cargo capacity......175 Replacing light bulbs.....
Page 487 Alphabetical index Child safety ........ 52 Airbag precautions....37 Daytime running light Back door precautions ..119 system........209 Battery precautions..368, 454 Defogger Child restraint system ..... 53 Front windshield ....288 How your child should Outside rear view wear the seat belt ....
Page 488 Alphabetical index Emergency flashers ....408 Eco Driving Indicator ....83 Engine EDR (Event data recorder)..10 Accessory mode ....196 Electronic key ......94 Compartment......357 Battery-saving function ..110 Engine switch ....192, 195 If the electronic key does not Hood ........
Page 489 Alphabetical index Front turn signal lights ... 203 Flat tire........433 Replacing light bulbs .... 396 Floor mats ........26 Turn signal lever ....203 Fluid Wattage ........ 469 Automatic transmission..467 Fuel ........... 219 Brake ........467 Capacity........ 462 Power steering......
Page 490 Alphabetical index Head restraints ......139 I/M test ........352 Headlights ........ 205 Identification Light switch ......205 Engine ........461 Replacing light Vehicle........461 bulbs....393, 395, 405 Ignition switch Wattage ........ 469 (engine switch)....192, 195 Heaters Illuminated entry system ..297 Air conditioning Immobilizer system ....
Page 491 Alphabetical index License plate lights ....205 KDSS......... 261 Light switch......205 Keyless entry ......107 Replacing light bulbs .... 404 Smart key system ....107 Wattage ........ 469 Wireless remote control ..100 Lights Keys ..........94 Fog light switch..... 211 Battery-saving function ..
Page 492 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance... 353 Noise from under vehicle ... 8 General maintenance ... 349 Maintenance data ....460 Maintenance requirements ... 347 Odometer ........81 Reset the maintenance Off-road precautions....273 data ........348 Malfunction indicator lamp..418 Engine oil......
Page 493 Alphabetical index Parking brake......204 Radiator........363 Operation ......204 Rear differential lock Parking brake engaged system........216 warning buzzer ....418 Rear seats Parking lights......205 Adjustment......125 Light switch ......205 Folding down ..127, 129, 131 Replacing light bulbs..... 396 Rear step bumper....
Page 494 Alphabetical index Seats......... 122, 125 Safety Connect ......330 Adjustment....122, 125 Seat belt reminder light... 421 Adjustment Seat belts........30 precautions....124, 134 Adjusting the seat belt .... 30 Child seats/child restraint Automatic Locking system installation....57 Retractor (ALR) ....31 Cleaning .......
Page 495 Alphabetical index Side mirrors ......146 Stuck Adjusting and folding .... 146 If the vehicle becomes Side turn signal lights ..... 203 stuck........458 Smart key system ....107 Sun visors ........ 310 Antenna location ....107 Switches Entry functions ...... 100 Compass switch ....
Page 496 Alphabetical index Rear window and outside rear view mirror defoggers Tachometer ........ 81 switch ......282, 288 Tail lights........205 Seat heater switches .... 293 Light switch......205 Seat ventilator switches ..293 Telephone switches “SOS” button......330 Theft deterrent system Telephone switches Alarm ........
Page 497 Alphabetical index Tires .......... 372 Turn signal lights ....203 Chains........271 Replacing light bulbs ..396, 402 Checking....... 372 Turn signal lever ....203 If you have a flat tire ..... 433 Wattage ........ 469 Inflation pressure ....468 Information......
Page 498 Alphabetical index Warning messages....426 Warning buzzers Washer ........213 Brake system ......418 Checking....... 370 Downshifting ......202 Preparing and checking Intuitive parking assist ..226 before winter ...... 269 Key reminder ..193, 422, 429 Switch ......213, 216 Open door......
Page 499 GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 356 P. 221 Tire inflation Hood lock release lever pressure P. 468 P. 356 Fuel tank capacity 23.0 gal. (87.0 L, 19.1 Imp. gal.) (Reference) Fuel type Unleaded gasoline only P.

Toyota 4runner 2014 Owner's Manual

Quick Links

Related Manuals for Toyota 4runner 2014

Summary of Contents for Toyota 4runner 2014
