Assembly Material And Tools - Maxxus GRAVITY PRO 2.0 Installation & Operating Manual

Allen Key
5 mm
Tools may be supplemented or replaced with your own. Ensure that they are an accurate fit.

Assembly Material and Tools

Allen Key
6 mm
5
Part No. Description
10 Bolt M8x20
13 Washer Ø8.5xØ20xt1.5
14 Curve Washer Ø8.5xØ16xt2.0
15 Lock Nut M8
27 Washer Ø12xØ6.5x1.0
38 Allen Bolt M8x60
43 Bolt M8x12
51 Raised Head Bolt M6x15
63 Spring Washer
Ø8.1xØ12.3x2.1mm
76 Locking Pin
81 Flat Head Bolt M4x20
82 Cap
Spanners /
Phillips screwdriver
Qty
4
6
2
4
4
2
2
4
2
ENG
1
1
4
