SCANGRIP CANVIK BASIC Operating Instructions Manual page 6

GB
CONICAL SPRINGS
• Use the raised jaw 90.0060 to ensure that the centre line of the spring is parallel to the
compressing device. Do not use the coil spring compressor for conical springs if this is not
the case. Fit the raised jaw 90.0060 at the spring end with the smallest diameter.
• It is very important for your safety that the jaws are fitted correctly and that the bolts are
firmly tightened before use
BALL SPRINGS
• Use the raised jaw 90.0060 to ensure that the centre line of the spring is parallel to the
compressing device. Do not use the coil spring compressor for ball springs if this is not the
case. Fit raised jaws 90.0060 at both spring ends.
• It is very important for your safety that the jaws are fitted correctly and that the bolts are
firmly tightened before use.
Conical Springs Ball Springs
