- Page 1 User Manual Digital Multimeter PCE-HDM 7 User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 28 November 2018 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Contents Safety notes ................... 1 International safety symbols ..................... 2 Input limits ........................2 Safety category ratings ..................... 3 Specifications ..................4 Device description ................6 Delivery contents ......................7 On / off ....................7 Measuring functions ................8 AC/DC voltage measurements ..................8 Low Z AC/DC voltage measurements ................ -
Page 3: Safety Notes
Safety notes Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty. -
Page 4: International Safety Symbols
We do not assume liability for printing errors or any other mistakes in this manual. We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. -
Page 5: Safety Category Ratings
Safety category ratings Category rating Brief description Typical applications Cat II Single phase receptacles • Household appliances, and connected loads power tools • Outlets more than 30 ft (10 m) from a Cat III source • Outlets more than 60 ft (20 m) from a Cat IV source Cat III Three phase circuits and... -
Page 6: Specifications
Specifications Insulation Class 2, double insulation Case Double molded, IP 67 waterproof and dust- proof Diode test Test current max. 1.5 mA, open circuit voltage 3 V typical Continuity test Audible signal if the resistance is approx. 50 or less Low battery indication “... - Page 7 AC Response: 50 … 60 Hz Function Range Resolution Accuracy ±(% of reading + digits) DC voltage 400.0 mV 0.1 mV ±(1.0 % + 8) 4.000 V 1 mV ±(1.0 % + 3) 40.00 V 10 mV 400.0 V 0.1 V 600 V ±(1.2 % + 3) Input protection: 600 V DC or 600 V AC RMS...
-
Page 8: Device Description
Function Range Resolution Accuracy ±(% of reading + digits) Frequency 9.999 Hz 0.001 Hz ±(1.0 % + 5) 99.99 Hz 0.01 Hz 999.9 Hz 0.1 Hz 9.999 kHz 1 Hz 99.99 kHz 10 Hz 999.9 kHz 100 Hz ±(1.2 % + 5) 9.999 MHz 1 kHz Input protection: 600 V AC RMS or 600 V DC... -
Page 9: Delivery Contents
Display hold Low Z (impedance) MAX/MIN Maximum/Minimum Bluetooth Delivery contents 1 x multimeter PCE-HDM 7 1 x test lead 1 x storage bag 1 x K-type thermocouple 1 x temperature adaptor 1 x user manual 2 x AAA 1.5 batteries... -
Page 10: Measuring Functions
Measuring functions AC/DC voltage measurements WARNING: Observe all safety precautions when working on live voltages. Set the rotatory function switch to the V position. To select AC or DC voltage, press the MODE-button until the AC “~” or DC “ ”symbol appears on the LCD. -
Page 11: Ac Current Measurements
AC current measurements WARNINGS: Observe all safety precautions when working on live circuits. Do not measure current on circuits that exceed 600 V. Measurements in the 10 A range should be limited to 30 seconds maximum every 15 minutes. Set the rotary function switch to the 10 A~ position. Insert the black test lead into the COM input-jack and the red test lead into the 10 A input jack. -
Page 12: Frequency And % Duty Cycle Measurements
Frequency and % duty cycle measurements WARNING: Observe all safety precautions when working on live circuits. Set the rotary function switch to the Hz % position. To select Frequency or % Duty Cycle, press the MODE button until the “Hz” or “%” symbol appears on the LCD. Insert the black test lead into the COM input jack and the red test lead into the V input jack. -
Page 13: Diode Test
Diode test WARNING: Never test diodes in a live circuit. Set the rotary function switch to the Ω position. Press the MODE button until the symbol appears on the LCD display. Insert the black test lead into the COM input jack and the red test lead into the ? input jack. -
Page 14: Capacitance Measurements
Capacitance measurements WARNING: Safely discharge capacitors before taking capacitance measurements. Set the rotary function switch to the Ω position. Insert the black test lead into the COM input jack and the red test lead into the Ω input jack. Press the MODE button until the “nF” symbol appears on the LCD. -
Page 15: Operation
Operation Auto Power Off The meter automatically turns off after 15 minutes of activity. To reset the meter after it shuts off, turn rotary function switch to the off position and then set the switch to the desired function. To disable Auto Power Off, turn the rotary function switch to the off position. -
Page 16: Battery And Fuse Replacement
Battery and fuse replacement Battery replacement WARNING: To avoid electric shock, remove the test leads from the meter before removing the battery/fuse cover. Lift up the tilt stand. Loosen the two Phillips screws on the battery/fuse cover. Remove the battery/fuse cover. Replace the batteries with three AAA batteries. -
Page 17: Warranty
Warranty You can read our warranty terms in our General Business Terms which you can find here: https://www.pce-instruments.com/english/terms. Disposal For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament applies. Due to the contained pollutants, batteries must not be disposed of as household waste. They must be given to collection points designed for that purpose. - Page 18 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17 Tel.
